200 V - 1,000 V Single Phase Bridge
12.0 A Forward Current
70 ns - 3000 ns Recovery Time
1402 - 1410
1402F - 1410F
1402UF - 1410UF
ELECTRICAL CHARACTERISTICS AND MAXIMUM RATINGS
Part Number
Working
Reverse
Voltage
(Vrwm)
Average
Rectified
Current
@TC
(Io)
55°C
Volts
1402
1406
1410
1402F
1406F
1410F
1402UF
1406UF
1410UF
Amps
100°C
Amps
Reverse
Current
@ Vrwm
(Ir)
25°C
µA
100°C
µA
25°C
Volts
Amps
Forward
Voltage
1 Cycle
Surge
Current
tp=8.3ms
(Ifsm)
25°C
Amps
Repetitive
Surge
Current
(Ifrm)
25°C
Amps
Reverse
Recovery
Time
(1)
(Trr)
25°C
ns
°C / W
Thermal
Impd.
(Vf)
u
J-C
200
600
1000
200
600
1000
200
600
1000
12.0
12.0
12.0
12.0
12.0
12.0
12.0
12.0
12.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
9.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
25
25
25
25
25
25
25
25
25
1.1
1.1
1.1
1.2
1.5
1.5
1.7
1.7
1.7
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
150
150
150
100
100
100
100
100
100
25
25
25
20
20
20
20
20
20
3000
3000
3000
150
150
150
70
70
70
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
3.2
(1)Trr Testing: If=0.5A, Ir=1.0A, Irr=0.25A *Op. Temp. & Stg. Temp. = -55°C to +150°C Isolation Voltage: 1500V
10
_
AC
.75(19.05)
AC
.40(10.16)
+
AC
.147(3.73) THRU .235(5.97)
C'SINK .15(3.81) DP.
Aluminum Case
.40(10.16)
.50(12.7)
MAX.
.25
(6.35)
.75
(19.05)
_
+
AC
Dimensions: In. (mm) • All temperatures are ambient unless otherwise noted. • Data subject to change without notice.
