two highly precise split springs that ensures long
durability.
●
Using insertion molded terminals
that prevents flux penetration.
●
In addition to self-clinching PCB, left-angled,
right-angled terminals,
2 types of soldering terminals are available.
RoHS Compliant
D
2
F
Model Number Legend
1 2 3 4
D2F -
@ @ @ @
1. Ratings
None : 125 VAC 3A
125 VAC 1A (Low operating force)
01 : 30 VDC 0.1A
2. Maximum Operating Force (OF)
None : 1.47 N {150 gf}
F : 0.74 N {75 gf}
Note. The given values are for pin plunger models only.
4. Terminals
None : PCB terminals (Straight)
-T : Self-clinching PCB terminals
-A : PCB terminals (Right-angled)
-A1 : PCB terminals (Left-angled)
-D3 : Solder terminals
-D : Compact solder terminals
3. Actuator
None : Pin plunger
L : Hinge lever
L2 : Hinge Roller Lever
L3 : Simulated roller lever (R1.3)
L30 : Simulated roller lever (R2.5)
1
D2F
List of Models
Ratings
Maximum Operating Force (OF) *
Actuator
Pin plunger
Terminals
PCB terminals (Standard)
Self-clinching PCB terminals
PCB terminals (Right-angled)
PCB terminals (Left-angled)
Solder terminals
Compact solder terminals
Hinge lever
PCB terminals (Standard)
Self-clinching PCB terminals
PCB terminals (Right-angled)
PCB terminals (Left-angled)
Solder terminals
Compact solder terminals
Hinge roller
lever
PCB terminals (Standard)
Self-clinching PCB terminals
PCB terminals (Right-angled)
PCB terminals (Left-angled)
Solder terminals
Compact solder terminals
Simulated roller
lever (R1.3)
PCB terminals (Standard)
Self-clinching PCB terminals
PCB terminals (Right-angled)
PCB terminals (Left-angled)
Solder terminals
Compact solder terminals
Simulated roller
lever (R2.5)
PCB terminals (Standard)
Self-clinching PCB terminals
PCB terminals (Right-angled)
PCB terminals (Left-angled)
Solder terminals
Compact solder terminals
*
OF are value for Pin plunger.
3A
General Purpose
1.47 N {150 gf}
D2F
D2F-T
D2F-A
D2F-A1
D2F-D3
D2F-D
D2F-L
D2F-L-T
D2F-L-A
D2F-L-A1
D2F-L-D3
D2F-L-D
D2F-L2
D2F-L2-T
D2F-L2-A
D2F-L2-A1
D2F-L2-D3
D2F-L2-D
D2F-L3
D2F-L3-T
D2F-L3-A
D2F-L3-A1
D2F-L3-D3
D2F-L3-D
D2F-L30
D2F-L30-T
D2F-L30-A
D2F-L30-A1
D2F-L30-D3
D2F-L30-D
1A
Ultra Subminiature Basic Switch
0.1 A
General Purpose
1.47 N {150 gf}
D2F-01
D2F-01-T
D2F-01-A
D2F-01-A1
D2F-01-D3
D2F-01-D
D2F-01L
D2F-01L-T
D2F-01L-A
D2F-01L-A1
D2F-01L-D3
D2F-01L-D
D2F-01L2
D2F-01L2-T
D2F-01L2-A
D2F-01L2-A1
D2F-01L2-D3
D2F-01L2-D
D2F-01L3
D2F-01L3-T
D2F-01L3-A
D2F-01L3-A1
D2F-01L3-D3
D2F-01L3-D
D2F-01L30
D2F-01L30-T
D2F-01L30-A
D2F-01L30-A1
D2F-01L30-D3
D2F-01L30-D
Low Operating Force
0.74 N {75 gf}
D2F-01F
D2F-01F-T
D2F-01F-A
D2F-01F-A1
D2F-01F-D3
D2F-01F-D
D2F-01FL
D2F-01FL-T
D2F-01FL-A
D2F-01FL-A1
D2F-01FL-D3
D2F-01FL-D
D2F-01FL2
D2F-01FL2-T
D2F-01FL2-A
D2F-01FL2-A1
D2F-01FL2-D3
D2F-01FL2-D
D2F-01FL3
D2F-01FL3-T
D2F-01FL3-A
D2F-01FL3-A1
D2F-01FL3-D3
D2F-01FL3-D
D2F-01FL30
D2F-01FL30-T
D2F-01FL30-A
D2F-01FL30-A1
D2F-01FL30-D3
D2F-01FL30-D
Low Operating Force
0.74 N {75 gf}
D2F-F
D2F-F-T
D2F-F-A
D2F-F-A1
D2F-F-D3
D2F-F-D
D2F-FL
D2F-FL-T
D2F-FL-A
D2F-FL-A1
D2F-FL-D3
D2F-FL-D
D2F-FL2
D2F-FL2-T
D2F-FL2-A
D2F-FL2-A1
D2F-FL2-D3
D2F-FL2-D
D2F-FL3
D2F-FL3-T
D2F-FL3-A
D2F-FL3-A1
D2F-FL3-D3
D2F-FL3-D
D2F-FL30
D2F-FL30-T
D2F-FL30-A
D2F-FL30-A1
D2F-FL30-D3
D2F-FL30-D
D
2
F
Contact Form
●SPDT
Contact Specifications
Item
Specifications
Contact
Material
Gap (standard value)
Minimum applicable load (see note) *
Silver alloy
0.25 mm
100 mA at 5 VDC
1 mA at 5 VDC
Model
D2F models
D2F-01 models
Gold alloy
Crossbar
COM
NO NC
*
Please refer to "Using
Micro Loads"
in "Precautions" for more information
on the minimum applicable load.
Ratings
Model
Maximum Operating
Force (OF)
Rated voltage
125 VAC
30 VDC
D2F models
1.47N (General-purpose)
0.74N (Low Operating Force)
D2F-01 models
1.47N (General-purpose)
0.74N (Low Operating Force)
Resistive load
3A
2A
1A
0.5 A
-
0.1 A
Note. The above rating values apply under the following test conditions.
(1) Ambient temperature: 20±2°C
(2) Ambient humidity: 65±5%
(3) Operating frequency: 30 operations/min
Approved Safety Standard
The items shown in the
"List
of Models" above are not standard approved models.
Consult your OMRON sales representative for specific models with standard approvals.
UL (UL1054) /CSA (CSA C22.2 No.55)
Rated voltage
125 VAC
30 VDC
Model
D2F (General-purpose)
3A
2A
D2F (Low operating force)
1A
0.5 A
D2F-01
-
0.1 A
2
D2F
Characteristics
Model
Item
Permissible operating speed
Permissible operating
frequency
Insulation resistance
Contact resistance (initial value)
Between terminals of the same
polarity
Dielectric strength
Between current-carrying metal
parts and ground
Between each terminal and
non-current-carrying metal parts
Vibration resistance * 1
Shock resistance
Malfunction
Durability
Malfunction * 1
Mechanical
Durability * 2
Degree of protection
Ambient operating temperature
Ambient operating humidity
Weight
Electrical
100,000 operations min.
(30 operations/min)
Mechanical
Electrical
100 mΩ max.
D2F-01 models
Ultra Subminiature Basic Switch
D2F models
0.74 N (Low operating force)
1.47 N (General-purpose)
Pin plunger models: 1 mm to 500 mm/s,
Lever models: 5 mm to 500 mm/s
Pin plunger models: 200 operations/min,
Lever models: 100 operations/min
30 operations/min
100 MΩ min. (at 500 VDC with insulation tester)
50 mΩ max.
600 VAC 50/60 Hz for 1min
1,500 VAC 50/60 Hz for 1min
1,500 VAC 50/60 Hz for 1min
10 to 55 Hz, 1.5-mm double amplitude
1,000 m/s
2
{approx. 100G} max.
300 m/s
2
{approx. 30G} max.
1,000,000 operations min. (60 operations/min)
30,000 operations min.
(30 operations/min)
IEC IP40
-40°C to +85°C (at ambient humidity 60% max.)
(with no icing or condensation)
85% max. (for +5°C to +35°C)
Approx. 0.5 g (pin plunger models)
30 mΩ max.
D
2
F
Note. The data given above are initial values.
*1. The values are at Free Position and Total Travel Position values for pin plunger, and Total Travel Position value for lever.
Close or open circuit of the contact is 1ms max.
*2. For testing conditions, consult your OMRON sales representative.
Terminals/Appearances
●PCB
terminals (Straight)
(Unit: mm)
●Self-clinching
PCB terminals
<PCB Mounting Dimensions (Reference)>
5.8
±0.15
3-1.2 dia. holes
1.5
3.5
3.15
6.5
±0.1
5.08
5.08
12.8
±0.15
0.9
0.4
5.8
±0.15
3.15
6.5
±0.1
5.08
5.08
12.8
±0.15
1.5
3.4
0.9 0.4
±0.05
1.25
±0.15
5.8
±0.15
1.5
1.6
±0.15
5.08
±0.1
12.8
±0.15
●PCB
terminals (Right-angled)
●PCB
terminals (Left-angled)
1.5
2.6
±0.2
3.15
6.5
±0.1
5.08
5.08
12.8
±0.15
0.9
5.8
±0.15
3.1
±0.2
0.4
3.15
6.5
±0.1
5.08
5.08
12.8
±0.15
1.5
2.6
±0.2
0.9
0.4
5.8
±0.15
3.1
±0.2
●Solder
terminals
●Compact
solder terminals
1.5
2
0.5
3.15
6.5
±0.1
5.08
5.08
12.8
±0.15
3.5
1.2
2.2
0.4
5.8
±0.15
3−0.8 dia. holes
3.15
6.5
±0.1
5.08
5.08
12.8
±0.15
1.5
1.6
2.4
0.4
5.8
±0.15
Mounting Holes
(Unit: mm)
2-2 dia. mounting holes
6.5
±0.15
3
D2F
Dimensions
(Unit: mm)
/Operating Characteristics
Ultra Subminiature Basic Switch
The following illustrations and drawings are for D2F models with PCB terminals (straight). Self-clinching, solder, compact solder, and right-angled, left angled terminals
are omitted from the following drawings. Refer to the
previous page
for these terminals.
When ordering, replace
@
with the code for the terminal that you need. See the
"List of Models"
for available combinations of models.
●Pin
Plunger Models
D2F@
D2F-01@
D2F-F@
D2F-01F@
1.2
2.2
+0.12
0
dia.
A
12.7
5.2
2
+0.12
dia. holes
0
PT
5.7
2.9
Operating
Characteristics
Operating Force
Releasing Force
Model D2F-@
D2F-01@
D2F-F@
D2F-01F@
5
OP
D
2
F
OF Max. 1.47 N {150 gf} 0.74 N {75 gf}
RF Min. 0.20 N {20 gf} 0.05 N {5 gf}
0.5 mm
0.25 mm
0.12 mm
0.5 mm
0.25 mm
0.12 mm
2
+0.12
0
Pretravel
PT Max.
Overtravel
OT Min.
Movement Differential MD Max.
0.4
5.8
±0.15
Operating Position
OP
5.5±0.3 mm
●Hinge
Lever Models
D2F-L@
D2F-01L@
D2F-FL@
D2F-01FL@
12.8
(10.8)
A
t=0.3 *
3
FP
OP
Operating
Characteristics
Operating Force
Releasing Force
Model D2F-L@
D2F-01L@
OF Max.
RF Min.
0.78 N {80 gf}
0.05 N {5 gf}
0.55 mm
0.5 mm
D2F-FL@
D2F-01FL@
0.25 N {25 gf}
0.02 N {2 gf}
0.55 mm
0.5 mm
Overtravel
OT Min.
Movement Differential MD Max.
Free Position
Operating Position
FP Max.
OP
10 mm
6.8±1.5 mm
* Stainless-steel lever
●Simulated
Roller Lever Models (R1.3)
D2F-L3@
12.7
D2F-01L3@
(7.5)
D2F-FL3@
10
D2F-01FL3@
R1.3
Model
A
2.1
t=0.3 *
3
FP
OP
Operating
Characteristics
Operating Force
Releasing Force
OF Max.
RF Min.
D2F-L3@
D2F-01L3@
0.78 N {80 gf}
0.05 N {5 gf}
0.5 mm
0.45 mm
D2F-FL3@
D2F-01FL3@
0.39 N {40 gf}
0.02 N {2 gf}
0.5 mm
0.45 mm
Overtravel
OT Min.
Movement Differential MD Max.
Free Position
Operating Position
FP Max.
OP
13 mm
8.5±1.2 mm
* Stainless-steel lever
●Simulated
Roller Lever Models (R2.5)
D2F-L30@
D2F-01L30@
12.7
D2F-FL30@
D2F-01FL30@
3.3
R2.5 A
3
t=0.3 *
Operating
Characteristics
Operating Force
Releasing Force
Model D2F-L30@
D2F-01L30@
OF Max.
RF Min.
0.54 N {55 gf}
0.04 N {4 gf}
0.5 mm
0.5 mm
D2F-FL30@
D2F-01FL30@
0.3 N {31 gf}
0.02 N {2 gf}
0.5 mm
0.5 mm
OP
FP
Overtravel
OT Min.
Movement Differential MD Max.
Free Position
Operating Position
FP Max.
OP
12.6 mm
9.5±1.0 mm
* Stainless-steel lever
Note 1. Unless otherwise specified, a tolerance of ±0.4 mm applies to all dimensions.
Note 2. The operating characteristics are for operation in the A direction ( ).
4
D2F
●Hinge
Roller Lever Models
D2F-L2@
D2F-01L2@
D2F-FL2@
D2F-01FL2@
Ultra Subminiature Basic Switch
12.8
4
(10)
A
4.8
dia.×2.8
*2
Operating
Characteristics
(4.6)
Model D2F-L2@
D2F-01L2@
OF Max.
RF Min.
0.78 N {80 gf}
0.05 N {5 gf}
0.55 mm
0.5 mm
D2F-FL2@
D2F-01FL2@
0.39 N {40 gf}
0.02 N {2 gf}
0.55 mm
0.5 mm
Operating Force
Releasing Force
t=0.3 *1
4
OP
FP
Overtravel
OT Min.
Movement Differential MD Max.
Free Position
Operating Position
FP Max.
OP
16.5 mm
13±2 mm
D
2
F
*1. Stainless-steel lever
*2. Polyacetal resin roller
Note 1. Unless otherwise specified, a tolerance of ±0.4 mm applies to all dimensions.
Note 2. The operating characteristics are for operation in the A direction ( ).
Precautions
★Please
refer to "Basic Switches Common Precautions" for correct use.
Cautions
●Soldering
• Terminal connection
When soldering, make sure that the temperature of the
soldering iron tip is not higher than 300°C, and complete the
soldering within 3 seconds. Do not apply any external force for
1 minute after soldering. Soldering at an excessively high
temperature or soldering for more than 3 seconds may
deteriorate the characteristics of the Switch.
• Connecting to PCB terminal Boards
When using automatic soldering baths, we recommend
soldering at 260°C ±5°C within 5 seconds. Make sure that the
liquid surface of the solder does not flow over the edge of the
board.
When soldering terminals manually, perform soldering within 3
seconds at iron tip temperature not higher than 350°C. Do not
apply any external force for at least 1 minute after soldering.
When applying solder, keep the solder away from the case of
the Switch and do not allow solder or flux to flow into the case.
Correct Use
●Mounting
Use M2 mounting screws with plane washers or spring washers
to securely mount the Switch. Tighten the screws to a torque of
0.08 to 0.1 N·m {0.8 to 1 kgf·cm}.
●Using
Micro Loads
Using a model for ordinary loads to open or close the contact of
a micro load circuit may result in faulty contact. Use models that
operate in the following range. However, even when using micro
load models within the following operating range, if inrush
current occurs when the contact is opened or closed, it may
increase the contact wear and so decrease durability. Therefore,
insert a contact protection circuit where necessary. The
minimum applicable load is the N-level reference value. This
value indicates the malfunction reference level for the reliability
Functions and requirements of the product: 1. The appearance of the product needs to be basically consistent with the effect diagram. 2. The product needs to provide the corresponding command interfac...
I have read "From MCU Pointers to Hacker Programs" and I feel that the author said that unsigned char code rst[]={0xe4,0xc0,0xe0,0xc0,0xe0,0x32}; // reset code (*((void (*)())(&rst)))(); after disasse...
200-800W Ultra-small CVCC programmable power supply Lightweight desktop type, programmable DC power supply, power level 200W/400W/600W/800W 2U height.Lightweight desktop type, programmable DC power su...
Twelve tips on power supply design written by TI experts are collected together for the convenience of engineer friends to download. These 12 tips are: Power Supply Design Tip 1: Choose the Right Oper...
I use a NiMH battery, the battery parameters are 3.6V (actually these two batteries are made of 3 1.2V button batteries connected in series) 80mAh Ni-MH CHARGE: 8mA 14h The charger parameters are: Out...
[NXP Rapid IoT Review] Rapid IoT Studio Simple Programming Step 2 Counter plus Bluetooth [size=3]1. Open [/size][size=14px] Rapid IoT Studio IDE [/size] [font=Microsoft Yahei, Hei, Tahoma, SimHei, san...
The core of a machine vision system is image acquisition and processing. All information comes from images, and image quality is crucial to the entire vision system. A good image can improve the st...[Details]
The mass production process of the new generation of cockpit platform has started, and the smart cockpit market has entered a new bonus cycle of technology iteration and platform upgrade.
...[Details]
In recent years, with the application of the IEC61850 standard and the development and deployment of optoelectronic transformers, the concept of digital substations has been put into practical use ...[Details]
White light LEDs are voltage-sensitive devices. In actual operation, their upper limit is 20mA. However, the current often increases due to various reasons during use. If no protective measures are...[Details]
According to foreign media reports, secondary battery materials company POSCO Future M announced that it has successfully developed two experimental (prototype) positive electrode materials for the...[Details]
The Automotive Testing and Quality Assurance Expo (ATE 2025) will open on August 27th. At the expo, Rohde & Schwarz (R&S) will showcase six automotive testing solutions, themed "Intelligently Drivi...[Details]
This paper proposes a temperature real-time transmission and display solution based on LED optical data transmission, with Jingwei Yager low-power FPGA HR (Yellow River) series as the main controll...[Details]
As AI accelerates across industries, the demand for data center infrastructure is also growing rapidly.
Keysight Technologies, in collaboration with Heavy Reading, released the "Beyo...[Details]
Electric vehicles' 12V batteries don't rely on a generator to power them. Only gasoline-powered vehicles rely on the engine to drive a generator to generate electricity while driving, which is used...[Details]
With the continuous development of the industrial automation industry, we are seeing an increasing number of intelligent devices using flexible, efficient, and precise robotic arms to p...[Details]
Through AI connection technology supported by Qualcomm X85 5G modem and RF and Qualcomm FastConnect 7900 mobile connection system, seamless switching can be achieved between cellular net...[Details]
According to foreign media reports, Ford Motor has applied to the U.S. Patent and Social Security Office (USPTO) for a patent for a door anti-collision system that may be used in future Ford vehicl...[Details]
Lightweighting of automobiles is still a relatively unfamiliar term for automobiles. With the continuous improvement of environmental protection requirements, relevant regulations have also put for...[Details]
Tires are a very important component for cars. They are related to the driving experience of the vehicle. We are almost inseparable from cars in our daily lives. For tires, according to the role of...[Details]
Renesas Electronics' new ultra-low-power RA4C1 MCU features advanced security and a dedicated peripheral set, making it ideal for metering and other applications.
The new product mee...[Details]
Embedded System
京公网安备 11010802033920号
EEWORLD
