refer to our Tape and Reel Packaging Specification
Brochure, BRD8011/D.
**These packages are inherently PB--Free.
Publication Order Number:
P6KE200B/D
April, 2006 - Rev. 1
-
1
P6KE200B
MAXIMUM RATINGS
Rating
Peak Power Dissipation (Note 1) @ T
L
≤
25°C
Steady State Power Dissipation
@ T
L
≤
75°C, Lead Length = 3/8″, Derated above T
L
= 75°C
Thermal Resistance Junction--to--Lead
Forward Surge Current (Note 2) @ T
A
= 25°C
Operating and Storage Temperature Range
Symbol
P
PK
P
D
R
θJL
I
FSM
T
J
, T
stg
Value
600
5.0
50
15
100
-- 55 to +150
Unit
W
W
mW/°C
°C/W
A
°C
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the
Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect
device reliability.
1. Nonrepetitive current pulse per Figure 3 and derated above T
A
= 25°C per Figure 2.
2. 1/2 sine wave (or equivalent square wave), PW = 8.3 ms, duty cycle = 4 pulses per minute maximum.
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless
otherwise noted, V
F
= 3.5 V Max. @ I
F
(Note 3) = 50 A)
Symbol
I
PP
V
C
V
RWM
I
R
V
BR
I
T
ΘV
BR
I
F
V
F
Parameter
Maximum Reverse Peak Pulse Current
Clamping Voltage @ I
PP
Working Peak Reverse Voltage
Maximum Reverse Leakage Current @ V
RWM
Breakdown Voltage @ I
T
Test Current
Maximum Temperature Coefficient of V
BR
Forward Current
Forward Voltage @ I
F
V
C
V
BR
V
RWM
I
F
I
I
R
V
F
I
T
V
I
PP
Uni-
-Directional TVS
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise noted, V
F
= 3.5 V Max. @ I
F
(Note 3) = 50 A)
V
RWM
(Note 4)
V
171
Breakdown Voltage
I
R
@ V
RWM
mA
5
V
BR
Min
190
(Note 5)
(Volts)
Nom
200
Max
210
@ I
T
mA
1
V
C
@ I
PP
(Note 6)
V
C
V
274
I
PP
A
2.2
ΘV
BR
%/°C
0.108
Device
P6KE200B
Device
Marking
P6KE200B
3. 1/2 sine wave (or equivalent square wave), PW = 8.3 ms, duty cycle = 4 pulses per minute maximum.
4. A transient suppressor is normally selected according to the maximum working peak reverse voltage (V
RWM
), which should be equal to or
greater than the DC or continuous peak operating voltage level.
5. V
BR
measured at pulse test current I
T
at an ambient temperature of 25°C.
6. Surge current waveform per Figure 3 and derate per Figures 1 and 2.
http://onsemi.com
2
P6KE200B
NONREPETITIVE PULSE
WAVEFORM SHOWN IN
FIGURE 3
PEAK PULSE DERATING IN % OF
PEAK POWER OR CURRENT @ T = 25 C
A
_
100
PPK , PEAK POWER (kW)
10
100
80
60
40
20
0
0
25
50
75
100 125 150 175
200
1
0.1
0.1
ms
1
ms
10
ms
100
ms
1 ms
10 ms
t
P
, PULSE WIDTH
T
A
, AMBIENT TEMPERATURE (_C)
Figure 1. Pulse Rating Curve
Figure 2. Pulse Derating Curve
t
r
≤
10
ms
100
VALUE (%)
PEAK VALUE -- I
PP
PULSE WIDTH (t
p
) IS
DEFINED AS THAT
POINT WHERE THE
PEAK CURRENT
DECAYS TO 50% OF I
PP
.
I
PP
2
PD, STEADY STATE POWER DISSIPATION (WATTS)
3/8″
5
4
3
2
1
0
0
25
50
75 100 125 150 175
T
L
, LEAD TEMPERATURE
_C)
200
3/8″
HALF VALUE --
50
t
P
0
0
1
2
3
t, TIME (ms)
4
Figure 3. Pulse Waveform
Figure 4. Steady State Power Derating
http://onsemi.com
3
P6KE200B
PACKAGE DIMENSIONS
AXIAL LEAD
CASE 59AA--01
(Previously 59--09)
ISSUE O
NOTES:
1. DIMENSIONING AND TOLERANCING PER
ANSI Y14.5M, 1982.
2. CONTROLLING DIMENSION: INCH.
3. ALL RULES AND NOTES ASSOCIATED WITH
JEDEC DO--41 OUTLINE SHALL APPLY.
4. POLARITY DENOTED BY CATHODE BAND.
5. LEAD DIAMETER NOT CONTROLLED WITHIN
F DIMENSION.
6. REPLACES CASE 59--09.
DIM
A
B
D
K
INCHES
MIN
MAX
0.228 0.299
0.102 0.142
0.028 0.034
1.000
------
MILLIMETERS
MIN
MAX
5.80
7.60
2.60
3.60
0.71
0.86
25.44
------
B
K
D
A
K
