PS2502-1X, PS2502-2X, PS2502-4X
PS2502-1, PS2502-2, PS2502-4
HIGH DENSITY MOUNTING
PHOTODARLINGTON OPTICALLY
COUPLED ISOLATORS
APPROVALS
l
UL recognised, File No. E91231
'X' SPECIFICATION APPROVALS
l
VDE 0884 in 3 available lead form : -
- STD
- G form
-
SMD approved to CECC 00802
l
Certified to EN60950 by the following
Test Bodies :-
Nemko - Certificate No. P01102465
Fimko - Certificate No. FI18162
Semko - Reference No. 0202041/01-25
Demko - Certificate No. 311161-01
l
PS2502-1X
PS2502-1
2.54
7.0
6.0
Dimensions in mm
1
2
4
3
1.2
5.08
4.08
7.62
4.0
3.0
0.5
3.0
0.26
0.5
2.54
7.0
6.0
1.2
10.16
9.16
7.62
4.0
3.0
0.5
3.0
3.35
0.5
1
2
3
4
5
7.0
6.0
1.2
20.32
19.32
4.0
3.0
0.5
3.0
0.5 3.35
0.26
6
7
8
7.62
13°
Max
0.26
16
15
14
13
12
11
10
9
13°
Max
3.35
13°
Max
BSI approved - Certificate No. 8001
DESCRIPTION
The PS2502-1, PS2502-2, PS2502-4 series of
optically coupled isolators consist of infrared light
emitting diodes and NPN silicon photodarlingtons
in space efficient dual in line plastic packages.
FEATURES
l
Options :-
10mm lead spread - add G after part no.
Surface mount - add SM after part no.
Tape&reel - add SMT&R after part no.
l
High Current Transfer Ratio (200%min)
l
High Isolation Voltage (5.3kV
RMS
,7.5kV
PK
)
l
All electrical parameters 100% tested
l
Custom electrical selections available
APPLICATIONS
l
Computer terminals
l
Industrial systems controllers
l
Measuring instruments
l
Signal transmission between systems of
different potentials and impedances
OPTION SM
SURFACE MOUNT
OPTION G
PS2502-2X
PS2502-2
1
2
3
4
8
7
6
5
PS2502-4X
PS2502-4
2.54
7.62
0.6
0.1
10.46
9.86
1.25
0.75
0.26
10.16
ISOCOM COMPONENTS LTD
Unit 25B, Park View Road West,
Park View Industrial Estate, Brenda Road
Hartlepool, Cleveland, TS25 1YD
Tel: (01429) 863609 Fax :(01429) 863581
30/4/03
DB92306m-AAS/A8
ABSOLUTE MAXIMUM RATINGS
(25°C unless otherwise specified)
Storage Temperature
-55°C to + 125°C
Operating Temperature
-30°C to + 100°C
Lead Soldering Temperature
(1/16 inch (1.6mm) from case for 10 secs) 260°C
INPUT DIODE
Forward Current
Reverse Voltage
Power Dissipation
50mA
6V
70mW
OUTPUT TRANSISTOR
Collector-emitter Voltage BV
CEO
Emitter-collector Voltage BV
ECO
Power Dissipation
POWER DISSIPATION
Total Power Dissipation
200mW
(derate linearly 2.67mW/°C above 25°C)
ELECTRICAL CHARACTERISTICS ( T
A
= 25°C Unless otherwise noted )
PARAMETER
Input
Forward Voltage (V
F
)
Reverse Current (I
R
)
Output
Collector-emitter Breakdown (BV
CEO
)
( Note 2 )
40V
6V
150mW
MIN TYP MAX UNITS
1.2
1.4
10
40
6
V
µ
A
TEST CONDITION
I
F
= 10mA
V
R
= 4V
I
C
= 0.5mA
I
E
= 100
µ
A
V
V
Emitter-collector Breakdown (BV
ECO
)
Coupled
Current Transfer Ratio (CTR) (Note 2
)
200
2000
%
1mA I
F
, 2V V
CE
Collector-emitter Saturation VoltageV
CE (SAT)
Input to Output Isolation Voltage V
ISO
5300
7500
1.0
V
V
RMS
V
PK
Ω
µ
s
µ
s
1mA I
F
, 2mA I
C
See note 1
See note 1
V
IO
= 500V (note 1)
V
CE
= 2V ,
I
C
= 10mA, R
L
= 100
Ω
Input-output Isolation Resistance R
ISO
5x10
10
Output Rise Time
Output Fall Time
tr
tf
60
53
300
250
Note 1
Note 2
Measured with input leads shorted together and output leads shorted together.
Special Selections are available on request. Please consult the factory.
30/4/03
DB92306m-AAS/A8
Collector Power Dissipation vs. Ambient Temperature
=1mA
200
Collector power dissipation P
C
(mW)
Collector-emitter saturation voltage V
CE(SAT)
(V)
6
5
4
3
2
1
0
0
Collector-emitter Saturation
Voltage vs. Forward Current
30mA
50mA
1.5
5mA
150
100
50
0
-30
0
25
50
75
100
125
Ambient temperature T
A
( °C )
Forward Current vs. Ambient Temperature
60
Ic
T
A
= 25°C
0.5
1.0
2.0
2.5
3.0
Forward current I
F
(mA)
Collector Current vs. Collector-emitter Voltage
100
10mA
T
A
= 25°C
50
Forward current I
F
(mA)
Collector current I
C
(mA)
80
60
2mA
40
I
F
= 1mA
20
0
-30
0
25
50
75
100
125
0
1
2
3
4
5
Ambient temperature T
A
( °C )
Collector-emitter Saturation
Voltage vs. Ambient Temperature
1.2
1.0
0.8
0.6
0.4
0.2
0
-30
0
25
50
75
100
Ambient temperature T
A
( °C )
30/4/03
40
30
20
10
0
5mA
Collector-emitter voltage V
CE
( V )
Relative Current Transfer Ratio
vs. Ambient Temperature
1.5
Collector-emitter saturation voltage V
CE(SAT)
(V)
Relative current transfer ratio
I
F
= 1mA
I
C
= 2mA
I
F
= 1mA
V
CE
= 2V
1.0
0.5
0
-30
0
25
50
75
Ambient temperature T
A
( °C )
100
DB92306m-AAS/A8
