SERIES 700 SWITCHES
TACT
SWITCHES
PUSHBUTTON SWITCHES - SNAP-ACTING
SPECIFICATIONS
NAVIGATION
SWITCHES
Contact Ratings:
Life Expectancy:
Contact Resistance:
Insulation Resistance:
Dielectric Strength:
Actuation Force:
Travel:
1A @ 250 VAC
3A @ 120 VAC or 28 VDC
50,000 cycles typical
20mΩ max. typical @ 2-4 VDC
100mA for both silver and gold plated contacts
1,000 MΩ min.
1,000 V RMS @ sea level
200 ± 50 gf
1.20mm Typ
PUSHBUTTON
SWITCHES
Operating Temperature: -30°C to +85°C
TOGGLE
SWITCHES
MATERIALS
FEATURES & BENEFITS
APPLICATIONS/MARKETS
Telecommunications
Networking
Computers/servers
Performance audio
Instrumentation
Low power on/off designs
External hard drives and modems
Case:
Plunger:
Bushing:
Frame:
Contacts:
DAP
Glass filled nylon or glass filled polyester
Nickel plated brass
Stainless steel
Silver or Gold plated copper alloy
SLIDE
SWITCHES
ROCKER
SWITCHES
Snap acting contact design
Gold & silver contact options
Multiple termination options
Snap-in panel mount option
▲
▲
▲
HOW TO ORDER
SERIES
MODEL NO.
BUSHING
TERMINATION
CONTACT
MATERIAL
SEAL
HARDWARE
CAP
CAP COLOR
SNAP-ACTION
SWITCHES
700
SP7
DP7
B10
B11
B20
B21
M1
M2
M51
M52
M53
M6
M7
VS2
VS3
VS4
VS5
Q = Silver
R = Gold
E
E = Epoxy
Sealed at
Base of
Terminal
H=
Hardware
See Cap Options
DIP
SWITCHES
▲
▲
▲
Example Ordering Number
700_ DP7_ B10_ M1_ Q
_
E_ H_ C1_ BLK
Specifications subject to change without notice.
KEYLOCK
SWITCHES
SPDT
ROTARY
SWITCHES
P.C. MOUNTING
DETECTOR
SWITCHES
Model No.
SP-7
Term. Comm
ON
1-3
Type
(ON)
1-2
SCHEMATIC
( ) = Momentary
CAP
OPTIONS
60
Phone: 800-867-2717
Fax: 763-531-8235
DPDT
P.C. MOUNTING
PUSHBUTTON
SWITCHES
SCHEMATIC
TOGGLE
SWITCHES
Model No.
Type
DP-7
ON
(ON)
Term. Comm. 1-3, 4-6 1-2, 4-5
( ) = Momentary
KEYWAY
B10
B20
THD STD
NON-THD
FLAT
B11
B21
THD STD
NON-THD
TERMINATION OPTIONS
M1
SOLDER LUG
M2
P. C. MOUNT
P.C. MOUNTING
DPDT
M5
WIRE WRAP
P.C. MOUNTING
Option Code
M51
M52
M53
Dim. ’A’
.750 (19.05)
.964 (24.48)
.425 (10.80)
www.e-switch.com
info
@
e-switch.com
CAP
OPTIONS
DETECTOR
SWITCHES
ROTARY
SWITCHES
KEYLOCK
SWITCHES
DIP
SWITCHES
SPDT
SNAP-ACTION
SWITCHES
SLIDE
SWITCHES
ROCKER
SWITCHES
BUSHING OPTIONS FOR P.C. MOUNTING
NAVIGATION
SWITCHES
TACT
SWITCHES
61
