SURFACE MOUNT SILICON RECTIFIER
VOLTAGE RANGE 50 to 1000 Volts CURRENT 1.0 Ampere
FEATURES
*
*
*
*
*
Ideal for surface mounted applications
Low leakage current
Metallurgically bonded construction
Mounting position: Any
Weight: 0.016 gram
SA1
THRU
SA7
SOD-123F
MECHANICAL DATA
* Epoxy : Device has UL flammability classification 94V-0
.035 (0.90)
.028 (0.70)
.114 (2.9)
.106 (2.7)
.077 (1.95)
.069 (1.75)
.008 (0.20)
.053 (1.35)
.047 (1.20)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
resistive or inductive load.
.030 (0.75)
.022 (0.55)
.150 (3.8)
.142 (3.6)
Dimensions in inches and (millimeters)
MAXIMUM RATINGS
(@ T
A
=25
O
C unless otherwise noted)
RATINGS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current at T
A
= 55 C
Peak Forward Surge Current I
FM
(surge): 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Current Squarad Time
Typical Thermal Resistance (Note 3)
Typical Junction Capacitance (Note 1)
Operating and Storage Temperature Range
ELECTRICAL CHARACTERISTICS
(@T
A
=25
O
C unless otherwise noted)
CHARACTERISTICS
Maximum Forward Voltage at 1.0A DC
Maximum DC Average Reverse Current at
Rated DC Blocking Voltage
@T
A
= 25 C
o
@T
A
= 100 C
o
o
SYMBOL
V
RRM
V
RMS
V
DC
I
O
I
FSM
I
2
t
R
JA
R
JL
C
J
T
J
, T
STG
SA1
50
35
50
SA2
100
70
100
SA3
200
140
200
SA4
400
280
400
1.0
30
2.5
85
SA5
600
420
600
SA6
800
560
800
SA7
1000
700
1000
UNITS
Volts
Volts
Volts
Amps
Amps
A /Sec
0
2
C/W
pF
0
25
8
-55 to + 150
30
C
SYMBOL
V
F
I
R
SA1
SA2
SA3
SA4
1.0
1.0
50
SA5
SA6
SA7
UNITS
Volts
uAmps
uAmps
2016-10
REV:C
NOTES : 1. Measured at 1.0 MHz and applied average voltage of 4.0VDC
2. “Fully ROHS compliant”, “100% Sn plating (Pb-free)”.
3. Thernal Resistance: Mounted on PCB.
4. Available in Halogen-free epoxy by adding suffix -HF after the part nbr.
RATING AND CHARACTERISTICS CURVES ( SA1 THRU SA7 )
1.0
AVERAGE FORWARD CURRENT, (A)
0.8
50
8.3ms Single Half Sine-Wave
(JEDED Method)
PEAK FORWARD SURGE CURRENT, (A)
40
30
0.6
0.4
0.2
Single Phase
Half Wave 60Hz
Resistive or
Inductive Load
20
10
0
25
0
50
75
100
125
O
0
0
2
4
8 10
6
20
40
60 80 100
NUMBER OF CYCLES AT 60Hz
150
175
AMBIENT TEMPERATURE, ( C)
INSTANTANEOUS REVERSE CURRENT, (uA)
FIG.1 TYPICAL FORWARD CURRENT
DERATING CURVE
INSTANTANEOUS FORWARD CURRENT, (A)
FIG.2 MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
100
40
10
4
1.0
0.4
0.1
T
A
= 25
O
C
T
A
= 100
O
C
10
1.0
T
A
= 100
O
C
0.1
Pulse Width = 300ms
1% Duty Cycle
0.01
0
0.5
1.0
1.5
2.0
2.5
3.0
INSTANTANEOUS FORWARD VOLTAGE, (V)
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE, (%)
FIG.3 TYPICAL INSTANTANEOUS
FORWARD CHARACTERISTICS
200
JUNCTION CAPACITANCE, (pF)
FIG.4 TYPICAL REVERSE
CHARACTERISTICS
T
A
= 25
O
C
100
60
40
20
10
6
4
2
1
0.2.1 0.4
0
2.0
1
4
10
20
40
100
REVERSE VOLTAGE, (V)
FIG.5 TYPICAL JUNCTION CAPACITANCE
