2SCR512PT100 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> 2SCR512PT100

2SCR512PT100: DescriptionBipolar Transistors - BJT Trans GP BJT NPN 30V 2A; CategoryDiscrete semiconductor The transistor; File Size2MB，8 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

2SCR512PT100 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	2SCR512PT100	-	-	View	Buy Now

2SCR512PT100 Overview

Bipolar Transistors - BJT Trans GP BJT NPN 30V 2A

2SCR512PT100 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT, MPT3, 3 PIN
Contacts	3
Reach Compliance Code	not_compliant
ECCN code	EAR99
Shell connection	COLLECTOR
Maximum collector current (IC)	2 A
Collector-emitter maximum voltage	30 V
Configuration	SINGLE
Minimum DC current gain (hFE)	200
JESD-30 code	R-PSSO-F3
JESD-609 code	e2
Humidity sensitivity level	1
Number of components	1
Number of terminals	3
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Polarity/channel type	NPN
Maximum power dissipation(Abs)	2 W
Certification status	Not Qualified
surface mount	YES
Terminal surface	TIN COPPER
Terminal form	FLAT
Terminal location	SINGLE
Maximum time at peak reflow temperature	10
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	320 MHz
Base Number Matches	1

Preview

Download Datasheet

View All

2SCR512P

Middle Power Transistors (30V / 2V)

Datasheet

Outline

Parameter

Value

SOT-89

SC-62

CEO

30V

Features

1)Low saturation voltage, typically

CE(sat)

=400mV(Max.)

=700mA/35mA)

2)High speed switching

Application

LOW FREQUENCY AMPLIFIER, HIGH SPEED SWITCHING

Packaging specifications

Part No.

ew om

es en

ig de

ns d

MPT3

Inner circuit

Package

SOT-89

(MPT3)

Package

size

4540

Taping

code

T100

Basic

Reel size Tape width ordering

(mm)

unit.(pcs)

180

1000

2SCR512P

www.rohm.com

1/6

Marking

20150731 - Rev.003
