Features
■
Available in E12 series
■
Unit height of 5.2 mm
■
Current up to 4.5 A
■
RoHS compliant*
Applications
■
Input/output of DC/DC converters
■
Power supplies for:
•
Portable communication equipment
•
Camcorders
•
LCD TVs
•
Car radios
*R
oH
S
NT
SRR1005 Series - Shielded Power Inductors
Electrical Specifications
Inductance 1kHz
Bourns Part No.
(µH)
Tol. %
Q
Ref.
Test
Frequency
(MHz)
SRF
Min.
(MHz)
RDC
Max.
(Ω)
I rms
Max.
(A)
I sat
Typ.
(A)
SRR1005-1R0M
SRR1005-1R5M
SRR1005-2R2M
SRR1005-3R0M
SRR1005-3R3M
SRR1005-4R7M
SRR1005-6R8M
SRR1005-7R0M
SRR1005-100M
SRR1005-120M
SRR1005-150M
SRR1005-180Y
SRR1005-220Y
SRR1005-270Y
SRR1005-330Y
SRR1005-390Y
SRR1005-470Y
SRR1005-560Y
SRR1005-680Y
SRR1005-820Y
SRR1005-101K
SRR1005-121K
SRR1005-151K
SRR1005-181K
SRR1005-221K
SRR1005-271K
SRR1005-331K
SRR1005-391K
SRR1005-471K
SRR1005-561K
SRR1005-681K
SRR1005-821K
SRR1005-102K
SRR1005-122K
SRR1005-152K
SRR1005-182K
SRR1005-222K
SRR1005-272K
SRR1005-332K
1.0
1.5
2.2
3.0
3.3
4.7
6.8
7.0
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
20
20
20
20
20
20
20
20
20
20
20
15
15
15
15
15
15
15
15
15
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
25
25
25
25
25
25
22
22
48
45
40
35
42
40
40
40
35
35
35
35
35
30
28
28
30
30
30
25
40
40
37
37
65
58
53
65
55
55
50
7.96M
7.96M
7.96M
7.96M
7.96M
7.96M
7.96M
7.96M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.252M
0.252M
0.252M
0.252M
0.252M
0.252M
0.252M
120
100
90.0
80.0
75.0
50.0
35.0
32.0
30.0
25.0
20.0
19.0
18.0
17.0
15.0
13.0
12.0
11.0
9.0
8.0
7.5
7.2
6.2
5.8
5.2
4.8
4.5
4.2
3.0
2.7
2.6
2.5
2.0
2.0
1.6
1.4
1.4
1.2
1.2
0.017
0.020
0.027
0.030
0.039
0.040
0.075
0.055
0.065
0.080
0.085
0.090
0.100
0.120
0.160
0.180
0.190
0.210
0.340
0.380
0.420
0.460
0.520
0.700
0.800
1.100
1.200
1.400
1.600
1.800
2.300
2.600
3.200
3.600
5.200
5.700
6.500
8.600
10.00
4.50
3.60
3.10
2.90
3.30
2.50
2.20
2.20
2.00
1.80
1.70
1.60
1.40
1.30
1.20
1.05
1.00
0.90
0.82
0.75
0.68
0.60
0.55
0.50
0.45
0.40
0.35
0.33
0.30
0.28
0.26
0.24
0.22
0.20
0.17
0.16
0.14
0.12
0.10
8.00
7.00
6.10
5.00
3.90
3.80
2.80
3.20
3.00
2.30
2.10
2.10
1.90
1.60
1.56
1.40
1.30
1.10
1.10
0.95
0.90
0.80
0.66
0.65
0.63
0.52
0.48
0.45
0.45
0.42
0.38
0.36
0.32
0.29
0.24
0.23
0.21
0.18
0.17
General Specifications
Test Voltage........................................1 V
Reflow soldering.....250 °C; 10 sec max.
(In compliance with JEDEC,
J-STD-020C, Table 4-2)
Operating Temperature ..-40 °C to +125 °C
(Temperature rise included)
Storage Temperature..-40 °C to +125 °C
Resistance to Soldering Heat
............................250 °C, 10 sec. max.
Materials
Core.....................Ferrite DR and RI core
Wire .............................Enameled copper
Base ................................................DAP
Terminal ....................................Cu/Ni/Sn
Rated Current
...................Ind. drop 10 % typ. at Isat
Temperature Rise
......................40 °C max. at rated Irms
Packaging.....................600 pcs. per reel
Product Dimensions
Recommended Layout
DIMENSIONS:
MM
(INCHES)
*RoHS Directive 2002/95/EC Jan 27, 2003 including Annex.
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
SRR1005 Series - Shielded Power Inductors
Soldering Profile
300
<1> Max. of 10 seconds at 250 °C
<2> Max. of 30 seconds > 220 °C
250
250 °C
<1>
200
<2>
Temperature (°C)
150
120 - 150 seconds
100
Ramp-down
5 °C/second maximum
50
Ramp-up
4 °/second maximum
0
0
50
100
150
Time
(seconds)
200
250
300
Packaging Specifications
330
DIA.
(12.99)
2.0
±
0.5
(.079
±
.020)
30.4
(1.20)
13.0
±
0.5
(.512
±
.020)
DIA.
50.0
(1.969)
13.0
±
0.5
DIA.
(.512
±
.020)
26
(1.02)
4
(.157)
21.0
±
0.8
(.827
±
.031)
THICKNESS
0.10
(.004)
MAX.
EMBOSSED
CAVITY
EMBOSSED
CARRIER
END
START
24
(.945)
DIMENSIONS:
5.3
(.209)
16.0
(.63)
NO COMPONENT
COMPONENTS
NO COMPONENT
MM
(INCHES)
200
(7.874)
9600
(378.2)
400
(15.748)
USER DIRECTION OF FEED
QTY: 600 PCS. PER REEL
REV. 09/11
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
