RJ-45
1000 BASE-T Magnetics
8327
• Meets IEEE 802.3 and ANSI X3.263 requirements including 350µH OCL with 8mA DC bias
• For use with Broadcom BCM5400, BCM5401, BCM5402 and the Marvell 88E1000
Gigabit phy transceivers
• Includes integrated LEDs. LED signal leads are isolate from the Ethernet signal leads to
reduce EMI and crosstalk
• Contact Plating: 6u-inch gold flashed
Mechanical and Schematic
(All dimensions in millimetres)
PCB LAYOUT
(component side view)
Unspecified tolerance:
.XX
±0.25
.XXX ±0.13
SCHEMATIC
ELECTRICAL SPECIFICATION @ 25˚C
Insertion Loss
(dB MAX)
8327
Return Loss
(dB MIN)
80.1
to
100
MHz
Crosstalk Attenuation
(dB MIN)
80.1
to
100
MHz
CMRR
(dB MIN)
80.1
to
100
MHz
13/09/02
0.1
to
.999
MHz
1.0
to
15.0
MHz
15.1
to
60.0
MHz
60.1
to
80.0
MHz
0.1
to
.999
MHz
1.0
to
15.0
MHz
15.1
to
60.0
MHz
60.1
to
80.0
MHz
0.1
to
.999
MHz
1.0
to
15.0
MHz
15.1
to
60.0
MHz
60.1
to
80.0
MHz
0.1
to
.999
MHz
1.0
to
15.0
MHz
15.1
to
60.0
MHz
60.1
to
80.0
MHz
80.1
to
100
MHz
-1.0
-0.3
-0.6
-1.1
-1.1
-18
-18
-15
-12
-10
-43
-35
-26
-24
-24
-46
-46
-35
-35
-30
ISSUE: C
Turns Ratio:
(P2-P3):(J1-J2) & (P4-P5):(J3-J6) & (P6-P7):(J4-J5) & (P8-P9):(J7-J8) : 1CT:1CT±3%
Inductance:
(P3-P2) & (P4-P5) & (P6-P7) & (P9-P8) @ 100 kHz, 0.1 V, 8mA DC Bias : 350µH MIN
LED Forward Current:
@ Input 2 VDC : 20mA Max
Hipot:
(Input to Output) @ 1.0 mA, 1 sec : 1500 VAC
229 Colonnade Road, Ottawa, Ontario, Canada K2E 7K3
Tel: (613) 226-1626 Fax: (613) 226-7124
www.filtran.com
An ISO 9001 Registered Company
Industrial Control Electronics
