1N2384 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> 1N2384

1N2384: DescriptionRectifier Diode, 1 Element, 0.2A, 8000V V(RRM), Silicon; CategoryDiscrete semiconductor diode; File Size56KB，1 Pages; ManufacturerSemitronics Corp.

Download Datasheet Parametric Compare View All

1N2384 Overview

Rectifier Diode, 1 Element, 0.2A, 8000V V(RRM), Silicon

1N2384 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknow
ECCN code	EAR99
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	27 V
JESD-30 code	O-XALF-W2
Maximum non-repetitive peak forward current	6 A
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Maximum output current	0.2 A
Package body material	UNSPECIFIED
Package shape	ROUND
Package form	LONG FORM
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	8000 V
surface mount	NO
Terminal form	WIRE
Terminal location	AXIAL
Base Number Matches	1

Preview

Download Datasheet

View All

1N2384 Related Products

	1N2384	1N1731	1N1413	1N1734	1N2382	1N2383	1N2385	C1812X7R201-822JP6E	1N3055	1N1412
Description	Rectifier Diode, 1 Element, 0.2A, 8000V V(RRM), Silicon	Rectifier Diode, 1 Element, 0.2A, 1500V V(RRM), Silicon	Rectifier Diode, 1 Element, 0.125A, 2400V V(RRM), Silicon,	Rectifier Diode, 1 Element, 0.1A, 5000V V(RRM), Silicon	Rectifier Diode, 1 Element, 0.2A, 4000V V(RRM), Silicon	Rectifier Diode, 1 Element, 0.2A, 6000V V(RRM), Silicon	Rectifier Diode, 1 Element, 0.2A, 10000V V(RRM), Silicon	Ceramic Capacitor, Ceramic, 200V, 5% +Tol, 5% -Tol, X7R, -/+15ppm/Cel TC, 0.0082uF, 1812,	Rectifier Diode, 1 Element, 0.125A, 18000V V(RRM), Silicon	Rectifier Diode, 1 Element, 0.125A, 2000V V(RRM), Silicon,
Reach Compliance Code	unknow	unknow	unknow	unknow	unknow	unknow	unknow	compliant	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Number of terminals	2	2	2	2	2	2	2	2	2	2
Maximum operating temperature	150 °C	150 °C	150 °C	150 °C	150 °C	150 °C	150 °C	125 °C	165 °C	150 °C
Package form	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM	SMT	LONG FORM	LONG FORM
Shell connection	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED	-	ISOLATED	ISOLATED
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	-	SINGLE	SINGLE
Diode component materials	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON	-	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	-	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	27 V	5 V	7.5 V	18 V	18 V	27 V	39 V	-	85 V	6.25 V
JESD-30 code	O-XALF-W2	O-XALF-W2	O-XALF-W2	O-XALF-W2	O-XALF-W2	O-XALF-W2	O-XALF-W2	-	O-XALF-W2	O-XALF-W2
Maximum non-repetitive peak forward current	6 A	2.5 A	6 A	2.5 A	6 A	6 A	6 A	-	8 A	6 A
Number of components	1	1	1	1	1	1	1	-	1	1
Maximum output current	0.2 A	0.2 A	0.125 A	0.1 A	0.2 A	0.2 A	0.2 A	-	0.125 A	0.125 A
Package body material	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	-	UNSPECIFIED	UNSPECIFIED
Package shape	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND	-	ROUND	ROUND
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	-	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	8000 V	1500 V	2400 V	5000 V	4000 V	6000 V	10000 V	-	18000 V	2000 V
surface mount	NO	NO	NO	NO	NO	NO	NO	-	NO	NO
Terminal form	WIRE	WIRE	WIRE	WIRE	WIRE	WIRE	WIRE	-	WIRE	WIRE
Terminal location	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL	-	AXIAL	AXIAL
Base Number Matches	1	1	1	1	1	1	1	-	1	-
