SPECIFICATION CONTROL DRAWING
Product Revision
Product
Name
S03-01-R-100
G
S03-02-R-100
S03-03-R-100
S03-04-R-100
S03-05-R-100
G
G
G
G
Ident.
Code
Size1R
Size2R
Size3R
Size4R
Size5R
Product Dimensions
øB
øC
L±1.75
min.
min.
(L±0.07)
16.5
1.9
2.65
(0.650)
(0.075)
(0.105)
16.5
2.65
3.68
(0.650)
(0.105)
(0.145)
16.5
4.30
5.08
(0.650)
(0.170)
(0.200)
19.1
5.95
6.45
(0.750)
(0.235)
(0.255)
19.1
7.0
7.6
(0.750)
(0.275)
(0.300)
H
min.
8.25
(0.325)
8.25
(0.325)
8.25
(0.325)
8.25
(0.325)
8.25
(0.325)
Cable Dimensions
øE
øF
øD
max.
min.
max.
2.65
0.90
1.9
(0.105)
(0.035)
(0.075)
3.68
1.40
2.65
(0.145)
(0.055)
(0.105)
5.08
2.15
4.3
(0.200)
(0.085)
(0.170)
6.45
3.30
5.95
(0.255)
(0.130)
(0.235)
7.6
4.30
7.0
(0.300)
(0.170)
(0.275)
MATERIALS
1. INSULATION SLEEVE: Heat-shrinkable, transparent blue, radiation cross-linked modified polyvinylidene fluoride.
2. SOLDER PREFORM WITH FLUX AND THERMAL INDICATOR:
SOLDER:
TYPE Sn63 per ANSI-J-STD-006.
FLUX:
TYPE ROL1 per ANSI-J-STD-004.
THERMAL INDICATOR: Color change violet to colorless.
3. MELTABLE RINGS: Stabilized thermoplastic. Color: blue.
4. PRE-INSTALLED BRAID: Tin plated copper strands. CMA 640.
APPLICATION
1. These parts are designed to provide an environment protected shield termination on cables, rated for 125°C minimum, meeting
the dimensional criteria listed and having tin or silver plated shields and insulation compatible with the insert material.
For compatible insulations, see MIL-S-83519/2 or consult Raychem.
2. When installed per Raychem process standard RCPS-100-70, assemblies will meet those requirements of Raychem Specification
RT-1404 and MIL-S-83519/2 which do not require electrical testing while parts are immersed in water.
3. Temperature range: -55°C to +150°C.
4. Parts shall be marked with identification code per table.
For best results, prepare
the cable as shown:
SolderSleeves a trademark of TE Connectivity.
THERMOFIT
DEVICES
TE Connectivity
300 Constitution Drive
Menlo Park, CA 94025
USA
TITLE:
SOLDERSLEEVE DEVICE
SHIELD TERMINATION WITH BRAID
DOCUMENT NO.:
DCR NUMBER:
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN MILLIMETERS.
INCHES DIMENSIONS ARE BETWEEN BRACKETS.
TOLERANCES:
ANGLES: N/A
TE Connectivity reserves the right to amend
0.00 N/A
this drawing at any time. Users should
0.0 N/A
ROUGHNESS IN
evaluate the suitability of the product for
0 N/A
MICRON
their application.
S03-0X-R-100
REPLACES:
D990968
SIZE:
A
D990118
SHEET:
1 of 1
DRAWN BY:
DATE:
PROD. REV.
DOC ISSUE:
SCALE:
M. FORONDA
11/22/99
SEE TABLE
6
None
Print Date: 11-May-11
If this document is printed it becomes uncontrolled. Check for the latest revision.
