LUXEON CoB

Uniform, High Efficacy and

Easy-to-Design Array

Introduction

LUXEON CoB is a high uniformity array solution that represents a new breakthrough in efficacy for arrays. Due to its

industry leading small Light Emitting Surfaces (LES), LUXEON CoB arrays are very easy to work with and will enable

easier and less expensive designs. All LUXEON CoBs are available in 3-step (80 and 90CRI) as well as 5-step (70CRI)

MacAdam ellipse, ensuring uniform optical performance in general lighting applications. Next to that, LUXEON CoB

LEDs are all hot-tested at 85°C—real world operating conditions—which means that luminaire design is simplified

and testing can be minimized.

This document contains the performance data needed to design and engineer LUXEON CoB based applications.

Features

•

Efficacy: >130 lm/W, 35.5 V

•

Lumen packages from 500 to >10,000 lm Industry

smallest LES (Light Emitting Surface)

•

Tested at T

= 85°C

•

Robust MCPCB solution

•

Mouse-bites available for M2-M3 screws

•

Supported by a comprehensive optical,

mechanical, and electrical ecosystem

•

Recognized under the Component Recognition

Program of Underwriters Laboratories Inc.

•

UL listing E327436

Benefits

•

Breakthrough in LED efficacy

•

Enabling halogen and CDM replacement

•

Enables smaller and less expensive reflectors

•

Enables smaller heatsinks in your system

•

More uniform and crisp light beams

•

Enabling luminaire to luminaire consistency

•

Real world application testing

•

Easy to handle in manufacturing and operations

•

Easy to screw down the arrays

•

Drivers, holders and optics readily available

Table of Contents

General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Part Number Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Average Lumen Maintenance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Environmental Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Product Selection Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Characteristic Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Typical Forward Current Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Typical Relative Luminous Flux vs. Forward Current . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Typical Radiation Patterns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Color Bin Definition. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Package Info and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

General Information

Part Number Nomenclature

LUXEON CoB is tested and binned hot at T

= 85°C with a current pulse duration of 20ms.

The part number designation is explained as follows:

L H C A – B B C C – D D E E (Traditional)

Where:

A — designates the generation of the product family

B B — designates ANSI color point (e.g. 30 for 3000K)

C C — designates minimum CRI level (e.g. 80 for minimum 80 CRI)

D D E E — designates product configuration (e.g. 1203 for the 1000-2000 lm package)

L 2 C A – B B C C D D E E F F G G G (New Part Number Scheme for New Products)

Where:

A — designates the generation of the product family

B B — designates ANSI color point (e.g. 30 for 3000K)

C C — designates minimum CRI level (e.g. 80 for minimum 80 CRI)

D D E E — designates product configuration (e.g. 1202 for the Low Lumen package)

F F — designates LES Lighting Emitting Surface (e.g. 06 for 6mm LES)

G G G — designates manufacturing technology (e.g. AC0 for Crispwhite)

Therefore 3000K, 80 CRI LUXEON CoB products will be:

LHC1–3080–1203

L2C1–3080120206A00

CAT codes of LUXEON CoB:

3S: color within 3 SDCM

5S: color within 5 SDCM

Average Lumen Maintenance Characteristics

Lumen maintenance for solid-state lighting devices (LEDs) is typically defined in terms of the percentage of initial

light output remaining after a specified period of time. Philips Lumileds projects that LUXEON CoB will deliver—on

average—70% lumen maintenance (L70) at 50,000 hours of operation at its nominal, tested conditions. Observation

of design limits included in this data sheet is required in order to achieve this projected lumen maintenance. This

performance is based on independent test data, Philips Lumileds historical data from tests run on similar material

systems, and internal LUXEON reliability testing.

Environmental Compliance

Philips Lumileds is committed to providing environmentally friendly products to the solid-state lighting market.

LUXEON CoB is compliant to the European Union directives on the restriction of hazardous substances in electronic

equipment, namely the RoHS and REACH directives. Philips Lumileds will not intentionally add the following

restricted material to the LUXEON CoB: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls

(PBB) or polybrominated diphenyl ethers (PBDE).
