SPECIFICATION CONTROL DRAWING
Product Revision
Product
Name
B-155-03
B-155-05
B-155-06
B-155-07
B-155-09
B-155-11
B-155-13
B-155-17
B-155-23
B-155-33
A
A
A
A
A
A
A
A
A
A
Product Dimensions
øA
øB
L
min
min
max
2.5
[0.098]
4.3
[0.169]
6.0
[0.236]
6.8
[0.267]
8.70
[0.343]
10.8
[0.425]
13.0
[0.512]
17.0
[0.669]
22.5
[0.885]
33.0
[1.299]
3.0
[0.118]
4.8
[0.189]
6.70
[0.264]
7.3
[0.287]
9.20
[0.362]
11.5
[0.452]
15.1
[0.594]
19.0
[0.748]
24.5
[0.964]
35.0
[1.380]
24.5
[0.964]
29.3
[1.153]
32.00
[1.260]
32.5
[1.279]
35.50
[1.398]
35.5
[1.397]
45.5
[1.790]
55.5
[2.165]
80.0
[3.149]
80.0
[3.149]
D
max
3.0
[0.118]
4.8
[0.189]
6.70
[0.264]
7.3
[0.287]
9.20
[0.362]
11.5
[0.452]
15.1
[0.594]
18.0
[0.748]
23.5
[0.925]
34.0
[1.338]
øE
min
1.5
[0.059]
2.0
[0.078]
3.30
[0.130]
3.3
[0.130]
4.50
[0.177]
4.5
[0.177]
7.0
[0.275]
9.0
[0.354]
12.0
[0.472]
19.0
[0.748]
Cable Dimensions
øF
øG
H0.5
min
max
[0.020]
1.0
[0.039]
1.5
[0.059]
2.80
[0.110]
2.8
[0.110]
4.00
[0.157]
4.0
[0.157]
6.5
[0.256]
8.0
[0.315]
11.0
[0.433]
17.0
[0.689]
2.5
[0.098]
4.3
[0.169]
6.00
[0.236]
6.8
[0.267]
8.70
[0.343]
10.8
[0.425]
13.0
[0.512]
16.0
[0.630]
21.5
[0.846]
32.0
[1.259]
6.0
[0.236]
8.0
[0.315]
9.0
[0.354]
10.0
[0.393)
11.0
[0.433]
12.0
[0.472]
16.0
[0.630]
21.0
[0.827]
29.0
[1.142]
29.0
[1.142]
J0.5
[0.020]
7.0
[0.275]
9.0
[0.354]
10.0
[0.394]
11.0
[0.433]
12.0
[0.472]
13.0
[0.512]
17.0
[0.669]
23.0
[0.905]
31.0
[1.220]
31.0
[1.220]
Qty:
Item 2
1
1
1
1
2
2
3
2
2
3
MATERIALS
1. INSULATION SLEEVE: Heat-shrinkable, transparent clear, radiation cross-linked modified polyolefin.
2. SOLDER PREFORM WITH FLUX. Qty: see table (one solder washer shown).
SOLDER:
TYPE Sn42Bi58 per ANSI / J-STD-006.
FLUX:
TYPE ROM1 per ANSI / J-STD-004.
3. MELTABLE SEALING RINGS: Thermally stabilized thermoplastic.
APPLICATION
1. These controlled soldering devices are designed for termination of a bare or tin-plated copper shield on a cable having an
insulation rated for at least +85C.
2. Temperature range: -55C to +125C.
3. When installed properly, it will meet the performance requirements of TE Connectivity / Raychem Specification RT-1404.
4. For installation procedure and application equipment, consult RPIP-688-00.
For best results, prepare
The cable as shown:
TITLE:
TE Connectivity
300 Constitution Drive,
Menlo Park, CA. 94025, U.S.A.
Unless otherwise specified dimensions are in millimeters.
[Inches dimensions are shown in brackets]
TOLERANCES:
0.00 N/A
0.0 N/A
0 N/A
PREPARED BY:
ANGLES: N/A
Raychem
SOLDERSLEEVE DEVICE, LEAD-FREE
LOW-FIRE-HAZARD SHIELD
TERMINATION LOW TEMPERATURE
DOCUMENT NO.:
B-155-XX
PROD. REV.:
DOC. ISSUE:
DATE:
TE Connectivity reserves the right to amend
this drawing at any time. Users should evaluate
ROUGHNESS IN
the suitability of the product for their
MICRON
application.
DCR NUMBER:
REPLACES:
SEE TABLE
CAGE CODE :
2
SCALE:
SIZE:
15-Apr-11
SHEET:
mforonda
D050170
---
06090
---
A
1 of 1
Print Date: 9-May-11
© 2011 Tyco Electronics Corporation, a TE Connectivity Ltd. Company. All Rights Reserved.
If this document is printed it becomes uncontrolled. Check for the latest revision.
