Schmitt trigger, and a short-circuit protected open-collector output to
sink up to 25 mA. A south pole of sufficient strength will turn the output
on. A north pole is necessary to turn the output off. An on-board regula-
tor permits operation with supply voltages of 4.2 to 24 volts.
Three package styles provide a magnetically optimized package for
most applications. Package type LH is a modified SOT23W surface-
mount package, LT is a miniature SOT89/TO-243AA transistor package
for surface-mount applications; while UA is a three-lead ultra-mini-SIP
for through-hole mounting. Each package type is also available in a lead
(Pb) free version (suffix,
–T)
, with a 100% matte tin plated leadframe.
Data Sheet
27609.20e
X
PTCT
V
CC
1
2
3
GROUND
SUPPLY
Dwg. PH-003-2
Pinning is shown viewed from branded side.
ABSOLUTE MAXIMUM RATINGS
at T
A
= +25°C
Supply Voltage, V
CC
..........................
26.5 V
Reverse Battery Voltage, V
RCC
..........
-30 V
Magnetic Flux Density, B ............
Unlimited
Output Off Voltage, V
OUT
....................
26 V
Continuous Output Current,
I
OUT
.........................................
25 mA*
Reverse Output Current, I
OUT
.........
-50 mA
Package Power Dissipation, P
D
See Graph
Junction Temperature, T
J
................
+165°C
Operating Temperature Range, T
A
Range ‘E’ .....................
-40°C to +85°C
Range ‘L’....................
-40°C to +150°C
Storage Temperature Range,
T
S
..............................
-65°C to +170°C
*Internal current limiting is intended to protect
the device from output short circuits.
OUTPUT
FEATURES
■
■
■
■
■
■
■
■
Symmetrical Switch Points
Resistant to Physical Stress
Superior Temperature Stability
Output Short-Circuit Protection
Operation From Unregulated Supply
Reverse Battery Protection
Solid-State Reliability
Small Size
3280, 3281,
AND
3283
CHOPPER-STABILIZED,
PRECISION
HALL-EFFECT LATCHES
Product Selection Guide
Part Number
Pb-free
1
Packing
2
Mounting
Ambient, T
A
(°C)
B
RP(MIN)
(T
A
= 25°C)
(G)
B
OP(MAX)
(T
A
= 25°C)
(G)
A3280ELHLT-T
A3280ELT-T
A3280ELTTR-T
A3280EUA-T
A3280LLHLT-T
A3280LLT-T
A3280LLTTR-T
A3280LUA-T
A3281ELHLT-T
A3281ELT-T
A3281ELTTR-T
A3281EUA-T
A3281LLHLT-T
A3281LLT-T
A3281LLTTR-T
A3281LUA-T
A3283ELHLT-T
A3283ELT-T
A3283ELTTR-T
A3283EUA-T
A3283LLHLT-T
A3283LLT-T
A3283LLTTR-T
A3283LUA-T
1
Pb-based
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
7-in. reel, 3000 pieces/reel
Bulk, 500 pieces/bag
7-in. reel, 1000 pieces/reel
Bulk, 500 pieces/bag
7-in. reel, 3000 pieces/reel
Bulk, 500 pieces/bag
7-in. reel, 1000 pieces/reel
Bulk, 500 pieces/bag
7-in. reel, 3000 pieces/reel
Bulk, 500 pieces/bag
7-in. reel, 1000 pieces/reel
Bulk, 500 pieces/bag
7-in. reel, 3000 pieces/reel
Bulk, 500 pieces/bag
7-in. reel, 1000 pieces/reel
Bulk, 500 pieces/bag
7-in. reel, 3000 pieces/reel
Bulk, 500 pieces/bag
7-in. reel, 1000 pieces/reel
Bulk, 500 pieces/bag
7-in. reel, 3000 pieces/reel
Bulk, 500 pieces/bag
7-in. reel, 1000 pieces/reel
Bulk, 500 pieces/bag
SOT23W Surface Mount
SOT89 Surface Mount
4-pin SIP through hole
SOT23W Surface Mount
SOT89 Surface Mount
4-pin SIP through hole
SOT23W Surface Mount
SOT89 Surface Mount
4-pin SIP through hole
SOT23W Surface Mount
SOT89 Surface Mount
4-pin SIP through hole
SOT23W Surface Mount
SOT89 Surface Mount
4-pin SIP through hole
SOT23W Surface Mount
SOT89 Surface Mount
4-pin SIP through hole
–40 to 150
–40 to 85
–180
180
–40 to 150
–40 to 85
–90
90
–40 to 150
–40 to 85
–40
40
variants are being phased out of the product line.
a. Certain variants cited in this footnote are in production but have been determined to be LAST TIME BUY. This classification indicates that sale of this device
is currently restricted to existing customer applications. The device should not be purchased for new design applications because obsolescence in the near
future is probable. Samples are no longer available. Status change: October 31, 2006. Deadline for receipt of LAST TIME BUY ORDERS: April 27, 2007.
These variants include: A3281ELTTR, A3283ELT, A3283ELTTR, and A3283EUA.
b. Certain variants cited in this footnote are in production but have been determined to be NOT FOR NEW DESIGN. This classification indicates that sale of
this device is currently restricted to existing customer applications. The variants should not be purchased for new design applications because obsolescence
in the near future is probable. Samples are no longer available. Status change: May 1, 2006. These variants include: A3280ELHLT, A3280ELT, A3280ELTTR,
