KUP9314A13-120

Description
Power/Signal Relay, POWER/SIGNAL RELAY, 3PDT, MOMENTARY, 2700mW (COIL), 10A (CONTACT), 28VDC (CONTACT), SOCKET MOUNT
CategoryMechanical and electronic products    relay
File Size138KB，2 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

KUP9314A13-120 Overview

Power/Signal Relay, POWER/SIGNAL RELAY, 3PDT, MOMENTARY, 2700mW (COIL), 10A (CONTACT), 28VDC (CONTACT), SOCKET MOUNT

KUP9314A13-120 Parametric

Parameter NameAttribute value
MakerTE Connectivity
package instructionROHS COMPLIANT
Reach Compliance Codeunknown
Other featuresCOIL OPERATE VOLTAGE(AC): 102 V
body width35.71 mm
body height48.41 mm
Body length or diameter38.89 mm
Coil current (AC) maximum value0.024 A
Coil power2700 mW
Coil resistance1700 Ω
Maximum coil voltage (AC)120 V
Coil/Input Power TypeAC
Contact (AC) maximum rated R load10A@240VAC
Maximum contact current (AC)10 A
Maximum contact current (DC)10 A
Contact (DC) maximum rated R load10A@28VDC
Maximum contact voltage (AC)240 V
Maximum contact voltage (DC)28 V
Contact/Output Power TypeAC/DC
Electrical life100000 Cycle(s)
Manufacturer's serial numberKUP93
Installation featuresSOCKET MOUNT
operating hours15 ms
Maximum operating temperature45 °C
Minimum operating temperature-45 °C
physical size38.89mm x 35.71mm x 48.41mm
GuidelineCSA; UL
Relay actionMOMENTARY
Relay function3PDT
Relay typePOWER/SIGNAL RELAY
release time10 ms
sealDUST PROOF
surface mountNO
Terminal surfaceNOT SPECIFIED
Termination typeQUICK CONNECT
Base Number Matches1

Preview

Download Datasheet
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Relays > Product Feature Selector > Product Details
KUP93­14A13­120 Product Details
Industrial Relays (General Purpose)

Converted to EU RoHS but not ELV Compliant
 (
Find RoHS Compliant
Alternates
/
Statement of Compliance
)
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
KUP93­14A13­120
(8­1393118­1)
TE Internal Number: 8­1393118­1
Product Highlights:
KUP93 Series
Contact ­ Current Class = 5A to 10A Class, Less Than
16A
Contact ­ Rated Current = 10 A
Terminal Type = PCB­THT, Quick Connect, Solder
Contact ­ Arrangement = 3 Form B (NC)
View all Features
 Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
Product Line Information
Additional Product Images:
Schematic
Wiring Diagram
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Electrical Characteristics:
Contact ­ Current Class = 5A to 10A Class, Less Than 16A
Contact ­ Rated Current (A) = 10
Contact ­ Limiting Continuous Current (A) = 10
Contact ­ Limiting Making Current (A) = 10
Contact ­ Limiting Breaking Current (A) = 10
Insulation ­ Initial Dielectric Between Coil/Contact Class = 1000V to
1500VA Class
Insulation ­ Initial Dielectric Between Open Contacts (V rms) = 500
Insulation ­ Initial Dielectric Between Contacts and Coil (V rms) =
1500
Contact ­ Rated Voltage (VAC) = 240
Contact ­ Rated Voltage (VDC) = 28
Contact ­ Limiting Short­Time Current (A) = 10
Contact ­ Switching Recommended Load, Min. = 300mA at 12V
Coil ­ Rated Voltage (VAC) = 120
Coil ­ Resistance (Ω) = 1700
Coil ­ Rated Power, AC (VA) = 3.00
Coil ­ Rated Power Class = 2.0VA to 3.0VA Class
Insulation ­ Initial Dielectric Between Adjacent Contacts (V rms) =
1500
Insulation ­ Initial Insulation Resistance (MΩ) = 100000
Dimensions:
Mechanical ­ Length Class = 35mm to 40mm Class
Length (mm [in]) = 38.90 [1.550]
Mechanical ­ Width Class = 30mm to 40mm Class
Width (mm [in]) = 35.70 [1.405]
Mechanical ­ Height Class = 40mm to 50mm Class
Height (mm [in]) = 48.40 [1.905]
Body Features:
Mount Type = PCB, Socket
Weight (g [oz]) = 86.00 [3.034]
Contact Features:
Terminal Type = PCB­THT, Quick Connect, Solder
Contact Material = AgCdO
Contact ­ Number of Poles = 3
Configuration Features:
Contact ­ Arrangement = 3 Form B (NC)
Coil ­ Magnetic System = Monostable, AC
Industry Standards:
RoHS/ELV Compliance = RoHS/Not ELV Compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Converted to comply with RoHS not
ELV directives
Approved/Registered Standards = UL, CSA
Environmental:
Environmental ­ Category of Protection = RTI
Environmental ­ Ambient Temperature, Max. (°C [°F]) = 45 [113]
Environmental ­ Ambient Temperature Class = 0 to 50°C Class
Packaging Features:
Packaging Method = Tray
Other:
Series = KUP93
Brand = Potter & Brumfield
