Document 879-1
Shielded Power Inductors – MSS7348
•
•
•
•
Very low DCR – as low as 0.015 Ohms
Current handling as high as 5.7 A
Magnetically shielded
Wide range of inductance values available
Core material
Ferrite
Terminations
RoHS compliant matte tin over nickel over phos
bronze. Other terminations available at additional cost.
Weight
0.58 – 0.72 g
Ambient temperature
–40°C to +85°C with
Irms
current, +85°C to
+125°C with derated current
Storage temperature
Component: –40°C to +85°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
38 per billion hours / 26,315,789 hours, calculated per Telcordia SR-332
Packaging
250/7″ reel; 1000/13″ reel; Plastic tape: 16 mm wide,
0.4 mm thick, 12 mm pocket spacing, 4.9 mm pocket depth
PCB washing
Tested with pure water or alcohol only. For other solvents,
see Doc787_PCB_Washing.pdf.
Part number
1
MSS7348-332ME_
MSS7348-472ME_
MSS7348-682ME_
MSS7348-103ME_
MSS7348-153ME_
MSS7348-223ME_
MSS7348-333ME_
MSS7348-473ME_
MSS7348-683ME_
MSS7348-104ME_
MSS7348-154ME_
MSS7348-224ME_
MSS7348-334ME_
MSS7348-474ME_
MSS7348-684ME_
MSS7348-105ME_
Inductance
2
±20% (µH)
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1000
DCR (Ohms)
typ
max
0.015
0.018
0.024
0.029
0.029
0.035
0.038
0.045
0.047
0.056
0.067
0.080
0.106
0.120
0.132
0.150
0.196
0.225
0.297
0.320
0.461
0.520
0.586
0.624
0.886
0.980
1.28
1.38
1.64
1.82
2.50
2.73
SRF typ
3
(MHz)
131
87
43
27
23
18
13
12
8.1
7.0
5.6
4.8
3.7
3.1
2.6
2.2
Isat
(A)
4
10% drop 20% drop 30% drop
4.3
5.2
5.7
3.2
3.8
4.2
2.8
3.3
3.6
2.2
2.6
2.9
1.7
2.1
2.4
1.5
1.8
2.0
1.2
1.6
1.7
1.0
1.2
1.4
0.83
1.0
1.1
0.71
0.84
0.92
0.58
0.68
0.75
0.50
0.58
0.64
0.39
0.46
0.51
0.35
0.41
0.45
0.28
0.32
0.36
0.22
0.27
0.29
Irms
(A)
5
20°C rise 40°C rise
3.2
4.4
2.5
3.4
2.3
3.1
2.2
3.0
2.0
2.7
1.7
2.3
1.3
1.7
1.2
1.6
0.94
1.2
0.77
1.0
0.63
0.84
0.55
0.74
0.44
0.60
0.37
0.50
0.32
0.42
0.26
0.35
1. When ordering, please specify
termination
and
packaging
codes:
Termination: L
MSS7348-105MEC
= RoHS compliant matte tin over nickel over phos
bronze
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (250 parts per full reel).
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
= 13″ machine-ready reel. EIA-481 embossed plastic
tape. Factory order only, not stocked (1000 parts per
full reel).
Packaging:
C
B
D
2. Inductance measured at 100 kHz, 0.1 Vrms, 0 Adc using a Coilcraft SMD-A
fixture in an Agilent/HP 4263B LCR meter.
3. SRF measured using an Agilent/HP 8753D network analyzer and a
Coilcraft SMD-D test fixture.
4. DC current at which the inductance drops the specified amount from its
value without current.
5. Current that causes the specified temperature rise from 25°C ambient.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Document 879-1
Revised 06/12/13
