6
5
4
3
2
1
L
D
d
l
D
Boot, Black Color (x 2)
PG9 Cable Fitting
e
(Plastic Version)
Plug protective
cover assembly e
(Plastic Version)
PG9 Cable Gland
e
(Plastic Version)
Plug Housing
e
(Plastic Version)
i
Multi mode
Duplex LC Clip
Heatshrink sleeving
e
LC plug (x 4)
(Multi Mode)
50um/125um, OM3
Fiber optic cable
e Dust cap (x 4)
C
Coupling
e
(Plastic Version)
C
Over All
Length L
1 + 0.1/-0 m
h
i
c
g
Strip Wire
Length l
100 ± 5 mm
200 ± 10 mm
300 ± 15 mm
400 ± 20 mm
500 ± 25 mm
600 ± 30 mm
1.00 ± 0.10 m
1.00 ± 0.10 m
1.00 ± 0.10 m
1.00 ± 0.10 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
DOT NOT ALTER CAD DRAWING BY HAND
Customer:
Part Number
17-300300-001
17-300300-002
17-300300-003
17-300300-004
17-300300-005
17-300300-006
17-300300-010
17-300300-015
17-300300-020
17-300300-025
17-300300-030
17-300300-035
17-300300-040
17-300300-050
17-300300-060
Over All
Length L
76 +0.6/-0 m
80 +0.6/-0 m
91 +0.9/-0 m
100 +0.9/-0 m
107 + 0.9/-0 m
120 +0.9/-0 m
122 +0.9/-0 m
130 +0.9/-0 m
152 +1.8/-0 m
155 +1.8/-0 m
168 +1.8/-0 m
175 +1.8/-0 m
200 +1.8/-0 m
221 +1.8/-0 m
300 +2.7/-0 m
Tolerance
Strip Wire
Length l
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
2.66 ± 0.15 m
Part Number
17-300300-076
17-300300-080
17-300300-091
17-300300-100
17-300300-107
17-300300-120
17-300300-122
17-300300-130
17-300300-152
17-300300-155
17-300300-168
17-300300-175
17-300300-200
17-300300-221
17-300300-300
2 + 0.1/-0 m
3 + 0.1/-0 m
4 + 0.1/-0 m
5 + 0.1/-0 m
6 + 0.1/-0 m
10 +0.3/-0 m
15 +0.3/-0 m
20 +0.3/-0 m
25 +0.3/-0 m
30 +0.3/-0 m
35 +0.6/-0 m
40 +0.6/-0 m
50 +0.6/-0 m
60 +0.6/-0 m
THIS DRAWING MAY NOT BE COPIED OR REPRODUCED
IN ANY WAY, AND MAY NOT BE PASSED ON TO A THIRD
PARTY WITHOUT WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC CORPORATION
b
NOTES:
1. MAXIMUM CONNECTOR INSERTION LOSS (IL): 0.5dB,
PLUS CABLE ATTENUATION OF 3.5dB/km AT 850nm
j
k
B
f
2. TERMINATE CABLE AND ASSEMBLE CONNECTOR PER CONEC
ASSMBLY INSTRUCTIONS.
3. PERMANENTLY MARK CABLE ASSEMBLY WITH PART NUMBER
FROM VARIANT TABLE AND "MULTI MODE" AT EACH END OF CABLE.
MARKING SHALL BE LOCATED NO CLOSER THAN 30 CM
FROM CABLE END AND NO FARTHER THAN 60 CM.
MARKING METHOD IS OPTIONAL. MATERIALS USED SHALL BE
SUITABLE FOR OUTDOOR APPLICATIONS.
4. PROTECTIVE COVER SHALL BE INSTALLED WHEN UNMATED.
B
Unless otherwise specified
Scale: NTS
Autodesk
Inventor
Dim. in
Name
Title
Approval Date
Date
Apr. 05
Apr. 05
A
B
A
FIBER PATH DETAIL
h
Material: See Notes
Title:
A
k
j
i
h
g
f
a
Rev.
1xk
1xj
2xi
3xh
1xg
1xf
original
Changes
B
RoHS Compliant
6
5
4
Jun/03/2016 Vincent Ke
2011
Apr/26/2016 Vincent ke
Draw.
Aug/04/2015 Vincent ke
Appd.
Jul/27/2015 Vincent Ke
Norm
Jul/27/2015 Vincent ke
D-old
May/23/2013 Vincent ke
Date
Name
Name
Vincent Ke
J. Chaudry
IP67 Industrial Duplex LC (ODVA)
To Duplex LC Plug Patch Cord
Multi Mode
A
DIN
R
Drawing No.: 17K1A224
Part No.: SEE TABLE
A3
Sheet
1/1
3
2
1
