Banana Plugs and Jacks
Do-It-Yourself In-Line Sheathed
(4mm) Banana Plug and Jack
3.01in (76.45mm)
1.44in
(36.58mm)
Safety-rated plugs and jacks for use with any wire from 22 to 18 AWG with flexible insulation.
Attaches to wire by crimp or soldering.
Plugs fit most sheathed DMM jacks and DMM test leads to make up your own banana
plug or jack test lead or jumper.
See mating panel jacks (6387 on page 33).
Model#
6383-*
6383-02
6384-*
6384-02
Plug
15
Jack
Material:
Banana Plug/Jack:
brass;
Spring:
heat treated beryllium copper;
Insulation:
Santoprene
®
.
6383
Rating:
CAT II 300V, 15A, +275°F (+135°C) max.
*Std. Colors:
-0 Black, -2 Red, -02 Black and Red (2 per pkg).
6384
*Sold in pkgs of 10.
Do-It-Yourself Solderless Stackup
Banana Plug with Safety Shield
0.16in (4.06mm)
Max. insulation dia.
0.78in
(19.81mm)
Internal set screw holds wire firmly.
Safety collar insulates exposed wire leads.
Accepts standard banana plug and fits 0.166in (4.22mm)
dia. banana jack.
Material:
Banana Plug/Jack:
brass;
Spring:
heat treated
beryllium copper.
Rating:
For CE compliance
and for personal safety, do
not hold in hand when voltages exceed 33 Vrms/70 Vdc.
Maximum voltage
for hands free use:
5000 Vdc. Do not use
on circuits where transient stresses can exceed the rated
voltage.15A, +122˚F (+50˚C) max. (Model 4899, +302˚F
(+150˚C) max.).
Accepts 18-22 AWG wire.
Model# Plating Insulation
1825-*
Nickel
ABS
Std. Colors
-0 Black, -1 Brown,
-2 Red, -3 Orange,
-4 Yellow, -5 Green,
-6 Blue, -7 Violet,
-8 Gray, -9 White.
Sold in pkgs of 10
-0 Black, -2 Red
-0 Black, -6 Blue
Sold in pkgs of 10
Pkg of 1 ea. of all
10 colors
4897
4899
Gold
Nickel
ABS
Polyphenylene
Sulfide
ABS
0.44in
(11.17mm)
1.55in (39.37mm)
6545
Nickel
Do-It-Yourself Solderless Stackup
Banana Plug
1.55in
(39.37mm)
0.44in
(11.18mm)
x-hole 0.125in
(3.17mm)
Model# Plating Insulation
4914 set screws 8-32 x 0.210 (5.33mm), 100/pk.
Internal set screw holds wire firmly.
Accepts standard banana plug, fits standard 0.166in
(4.22mm) dia. banana jack.
Material:
Banana Plug/Jack:
brass;
Spring:
heat treated
beryllium copper.
5230
Nickel
Polyphenylene
Sulfide
1325-*
Nickel
ABS
Std. Colors
-0 Black, -1 Brown,
-2 Red, -3 Orange,
-4 Yellow, -5 Green,
-6 Blue, -7 Violet,
-8 Gray, -9 White.
-0 Black, -6 Blue
Rating:
For CE compliance
and for personal safety, do
not hold in hand when voltages exceed 33 Vrms/70 Vdc.
5406
Gold
ABS
Maximum voltage for
hands free use:
5000 Vdc. Do not use
6546
Nickel ABS
on circuits where transient stresses can exceed the rated
voltage.15A, +122˚F (+50˚C) max. (Model 5230, +302˚F
(+150˚C) max.).
*Sold in pkgs of 10.
Accepts 18-22 AWG wire.
-0 Black, -2 Red
Pkg of 1 ea. of all
10 colors
Do-It-Yourself
In-Line Sheathed
Banana Plug/
Banana Jack
1.06in
(26.92mm)
1.55in
(14.99mm)
Model# Accepts
Wire Access
wire AWG Hole
4933-*
4934-*
4986-*
22, 20, 18 0.159in
(4.04mm) Dia.
22, 20, 18 0.159in
(4.04mm) Dia.
16, 14
0.200in
(50.8mm) Dia.
Description
Plug
Jack
Plug
Rivet Type Banana
Plug
0.16in
(4.06mm)
Model#
3257
“X”
0.094in
(2.39mm)
Panel
0.062in
(1.57mm)
3258
0.125
0.093in
Rivet
(3.17mm)
(2.36mm)
I.D. - 0.14in (3.56mm)
O.D.- 0.25in (6.35mm)
Excellent for riveting to panels or boards.
Fits standard 0.166in (4.22mm) dia. banana jack.
Material:
Banana Plug Body:
brass;
Spring:
beryllium copper;
Finish:
nickel plating.
These plugs and jacks are designed to fit together and
provide protection from accidental shorting.
0.36in (9.14mm)
4933/4986 Plugs
Material:
Banana Plug/Jack:
brass;
Spring:
beryllium
copper;
Insulation:
nylon.
Rating:
For CE compliance
and for personal safety,
do not hold in hand when voltages exceed
33 Vrms/70 Vdc. Maximum voltage
for hands free use:
1200V ac/dc. Do not use on circuits where transient
stresses can exceed the rated voltage.15A, +176˚F
(+80˚C) max.
*Std. Colors:
-0 Black, -2 Red.
x
0.135in (3.43mm)
0.56in
(14.22mm)
Rating:
For CE compliance
and for personal
safety, do not hold in hand when voltages
exceed 33 Vrms/70 Vdc. Maximum voltage for
hands free use:
5000 Vdc. Do not use on circuits
where transient stresses can exceed the rated
voltage. 15A.
Sold in pkgs. of 10.
0.28in (7.11mm)
4934/4982 Jacks
*Color Code:
-0 Black, -1 Brown, -2 Red, -3 Orange, -4 Yellow,
-5 Green, -6 Blue, -7 Violet, -8 Gray, -9 White
www.pomonaelectronics.com
