05021
704-15K36
thru
704-15K36T
HIGH POWER AIRCRAFT/ VEHICLE DC BUS VOLTAGE SUPPRESSOR
APPLICATIONS
✔
DC Power Supply Protection
✔
MIL-STD-704 Power Bus Protection
IEC COMPATIBILITY
(EN61000-4)
✔
Meets the Following Military Specifications:
- MIL-STD-704
- MIL-PRF-19500
✔
15 kilowatts Peak Pulse Power per Line (tp=10/1000µs)
✔
Each Device 100% Tested
✔
28 Volt Power Supply Protection
704-15K36
MECHANICAL CHARACTERISTICS
✔
Molded Plastic Case
✔
Weight 38 grams: 704-15K36 & 65 grams: 704-15K36T (Approximate)
✔
Flammability Rating UL 94V-0
✔
Device Marking: Logo, Date Code & Part Number
✔
Positive Terminal Indicated By Polarity Dot
✔
Screening for Military Requirements IAW MIL-PRF-19500 is Available
✔
Screening Available Upon Request - The 704 series can be screened upon request for
military requirements in accordance with MIL-PRF-19500 (applicable test). Standard
screening is available based on the following options:
H1 - Submodule Screening per test plans 05231 & 05232
H2 - Submodule & Module Screening per test plan 05233
H3 - Submodule & Module Screening, Module Group B & C Lot Testing
per test plans 05234 & 05235
704-15K36T
MAXIMUM RATINGS
@ 25°C Unless Otherwise Specified
PARAMETER
Peak Pulse Power (tp = 10/1000µs) - See Fig. 1
Operating Temperature
Storage Temperature
Steady State Power Disspiation @ 50°C
Forward Surge Rating @ 25°C 1/120 seconds
SYMBOL
P
PP
T
L
T
STG
T
A
F
I
VALUE
15
-55 to 150
-55 to 150
10.0
300
UNITS
kilowatts
°C
°C
Watts
Amps
05021.R8 2/07
1
www.protekdevices.com
704-15K36
thru
704-15K36T
DEVICE CHARACTERISTICS
ELECTRICAL CHARACTERISTICS PER LINE
PART
NUMBER
RATED
STAND-OFF
VOLTAGE
MINIMUM
BREAKDOWN
VOLTAGE
MAXIMUM
CLAMPING
VOLTAGE
(See Fig. 2)
@ I
PPM
V
C
VOLTS
53
53
@ 25°C Unless Otherwise Specified
MAXIMUM
LEAKAGE
CURRENT
MAXIMUM
PEAK PULSE
CURRENT
(See Fig. 2)
MAXIMUM
FORWARD
VOLTAGE
@10mA
V
WM
VOLTS
704-15K36
704-15K36T
31.5
31.5
V(BR)
VOLTS
36
36
@V
WM
I
D
µA
100
500
I
PPM
AMPS
300
300
@100A, 8.3ms
V
F
VOLTS DC
3.0
15.0
1000
FIGURE 1
PEAK PULSE POWER VS PULSE TIME
PPP - Peak Pulse Power - killowatts
100
10
15kW 10/1000µs
Waveform
704-15K36T
704-15K36
1
1
10
100
1000
td - Pulse Duration - µs
10000
100000
1M
FIGURE 2
PULSE WAVE FORM
100
IPP - Peak Pulse Current - % of IPP
100
FIGURE 3
POWER DERATING CURVE
Peak Pulse Power
10/1000µs
80
% Of Rated Power
tf
Peak Value IPP
TEST
WAVEFORM
PARAMETERS
t = 10µs
tf = 1000µs
d
60
td = t IPP/2
50
40
20
e-t
0
0
1
t - Time - ms
2
3
0
0
25
Average Power
50
75
100
125
TL - Lead Temperature - °C
150
05021.R8 2/07
2
www.protekdevices.com
704-15K36
thru
704-15K36T
PACKAGE OUTLINE & DIMENSIONS
704-15K36 PACKAGE OUTLINE
704-15K36
A
C
B
F
D
DIMENSIONS
H
E
J
G
DIM
A
B
C
D
E*
F
G
H*
I
J
K
L
MILLIMETERS
MIN
MAX
49.28
43.92
2.79
18.29
3.18 DIA
8.76
13.51
0.66
11.94
2.41
7.70
9.40
51.56
44.96
3.56
19.81
3.18 DIA
10.29
15.04
0.71
13.46
2.92
8.20
10.92
INCHES
MIN
MAX
2.03
1.97
1.77
1.73
0.140
0.110
0.78
0.72
0.125 DIA 0.125 DIA
0.405
0.345
0.592
0.532
0.028
0.026
0.53
0.47
0.095
0.115
0.303
0.323
0.37
0.43
I
K
L
704-15K36T PACKAGE OUTLINE
704-15K36T
A
C
B
F
I
D
G
DIMENSIONS
H
DIM
A
B
C
D
E*
F
G*
H
I*
J
K*
MILLIMETERS
MIN
MAX
62.74
53.34
4.32
10.54
3.18 DIA
8.26
11.43
21.84
5.59
16.51
8.51
64.26
54.48
5.33
12.07
3.18 DIA
9.27
11.43
23.37
5.59
17.53
8.51
INCHES
MIN
MAX
2.47
2.53
2.10
2.145
0.17
0.21
0.415
0.475
0.125 DIA 0.125 DIA
0.325
0.365
0.450
0.450
0.86
0.92
0.220
0.220
0.65
0.69
0.335
0.335
E
J
K
Outline & Dimensions: Rev 1 - 4/04, 06035
Note*:
Dimensions are nominal
COPYRIGHT © ProTek Devices 2007
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that the final judgement concerning selection and specifications is
the buyer’s and that in furnishing engineering and technical assistance, ProTek assumes no responsibility with respect to the selection or specifications of such
products.
