HD01 - HD06
0.8A SURFACE MOUNT GLASS PASSIVATED BRIDGE
RECTIFIER
Features
·
·
·
·
·
·
·
Glass Passivated Die Construction
Low Forward Voltage Drop
Surge Overload Rating to 30A Peak
Ideally Suited for Automatic Assembly
Miniature Package Saves Space on PC Boards
UL Listed Under Recognized Component Index, File
Number E94661
Lead Free Finish, RoHS Compliant (Note 3)
MiniDIP
Dim
A
B
Min
5.43
3.6
0.15
0.05
¾
0.70
4.5
2.3
2.3
0.50
Max
5.75
4.0
0.35
0.20
7.0
1.10
4.9
2.7
2.7
0.80
L
G
A B
D E
C
D
E
Mechanical Data
·
·
·
·
·
·
·
Case: MiniDIP
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
Moisture sensitivity: Level 1 per J-STD-020C
Terminals: Finish
¾
Tin. Plated Leads, Solderable per
MIL-STD-202, Method 208
e
3
Polarity: As Marked on Case
Marking: Type Number, Date Code & Polarity Markings
Weight: 0.125 grams (approximate)
H
J
K
C
G
H
J
K
L
All Dimensions in mm
Equivalent Schematic
Maximum Ratings and Electrical Characteristics
Single phase, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Forward Rectified Current (Note 1) T
A
= @ 40°C
Non-Repetitive Peak Forward Surge Current, 8.3 ms
Single half-sine-wave Superimposed on Rated Load
Instantaneous Voltage Drop @ 0.4A (per element)
Peak Reverse Current at Rated
DC Blocking Voltage (per element)
Typical Total Capacitance (per element)
Operating and Storage Temperature Range
Notes:
@ T
A
= 25°C unless otherwise specified
Symbol
V
RMM
V
RWM
V
DC
V
RMS
I
O
I
FSM
V
F
I
R
C
T
R
qJA
T
j
, T
STG
HD01
100
70
HD02
200
140
0.8
30
1.0
5.0
500
10
75
HD04
400
280
HD06
600
420
Unit
V
V
A
A
V
mA
pF
°C/W
°C
@ T
A
= 25°C
@ T
A
= 125°C
(Note 2)
Typical Thermal Resistance, Junction to Ambient (Note 1)
-55 to +150
1. Mounted on Ceramic PC Board.
2. Measured at 1.0 MHz and Applied Reverse Voltage of 4.0 V.
3. RoHS revision 13.2.2003. Glass and High Temperature Solder Exemptions Applied, see
EU Directive Annex Notes 5 and 7.
DS17003 Rev. 12 - 2
1 of 3
www.diodes.com
HD01 - HD06
ã
Diodes Incorporated
0.6
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
0.8
10
I
F(AV)
, AVERAGE FORWARD CURRENT (A)
1.0
Ceramic PC Board
0.4
0.1
0.2
Resistive or Inductive Load
0
0
40
80
120
160
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 1 Output Current Derating Curve
0.01
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics (per element)
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
35
30
C
T
, TOTAL CAPACITANCE (pF)
100
T
j
= 25
°
C
f = 1.0MHz
20
10
10
T
A
= 25
°
C
Single Half Sine-Wave
Pulse Width = 8.3ms
0
1.0
10
100
1
1
10
V
R
, REVERSE VOLTAGE (V)
Fig. 4 Typical Total Capacitance (per element)
100
NUMBER OF CYCLES AT 60 Hz
Fig. 3 Maximum Peak Forward Surge Current (per element)
100
10
T
j
= 125
°
C
1.0
0.1
T
j
= 25
°
C
0.01
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
Fig. 5 Typical Reverse Characteristics (per element)
DS17003 Rev. 12 - 2
2 of 3
www.diodes.com
HD01 - HD06
Ordering Information
Device*
HDxx-T
(Note 4)
Packaging
MiniDIP
Shipping
3K/Tape & Reel, 13-inch
*xx = Device type, e.g. HD02-T or HD04-T, etc.
Notes:
4. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
YM
HDXX
YM = Date code marking
Y = Last digit of the year
M = See Month/Code Table Below
HDXX = Product type marking code,
Ex: HD04
Month
Code
Jan
1
Feb
2
March
3
Apr
4
May
5
Jun
6
Jul
7
Aug
8
Sep
9
Oct
O
Nov
N
Dec
D
