RAYCHEM Tubing Products
Tubing Kits and Mini-Spools
Smaller Packaging Options
for Single Wall and
Adhesive-Lined Tubing
Products
Product Facts
VERSAFIT and RNF-100
tubing: 2:1 shrink ratio
I
DWP-125: 3:1 shrink ratio
I
ES1000: 4:1 shrink ratio
I
VERSAFIT tubing’s low full
recovery temperature
reduces installation time
and the risk of damage to
temperature-sensitive
components
I
RNF-100 offers excellent
physical, chemical, and
electrical properties that
meet or exceed commercial,
industrial and military
standards for highly
reliable, general purpose
tubing
I
DWP-125 and ES1000 have
high-shrink-ratios to allow
for insulation and sealing of
irregular shapes; few sizes
cover a wide range of
diameters
I
RoHS compliant
I
1
Heat-shrinkable Tubing
Applications
Single wall VERSAFIT and
RNF-100 tubing provide
electrical insulation and
strain relief of in-line com-
ponents, electrical connec-
tions, wire terminations, and
splices. They can be used
to bundle wires for flexible
light duty harnesses. Also
to identify or color code
wires, cables, terminals and
electronic components.
Adhesive-lined DWP-125
and ES1000 environmen-
tally seal and protect a
wide variety of electrical
applications, including wire
splices, terminations, break-
outs and connector-to-
cable transitions.
Installation
Minimum full recovery
temperature:
VERSAFIT: 90°C [194°F]
RNF-100: 121°C [250°F]
DWP-125: 125°C [257°F]
ES1000: 135°C [275°F]
Operating Temperature Range
VERSAFIT and RNF-100:
-55°C to 135°C
[-67°F to 275°F]
DWP-125:
-40°C to 110°C
[-40°F to 230°F]
ES1000:
-40°C to 130°C
[-40°F to 266°F]
Specifications/Approvals
Series
VERSAFIT
RNF-100
DWP-125
ES1000
UL
E35586 VW-1
600 V, 125°C
E35586
600 V, 125°C
E35586
600 V, 125°C
E85381
600 V, 125°C
CSA
®
Raychem
RW-3009
RT-350
DWP-125 SCD
RT-1113
LR31929 VW-1
600 V, 125°C
LR31929
600 V, 125°C
—
—
Available in:
Americas
I
Europe
Asia Pacific
I
1-125
9-1773447-9
CIS WR 08/2011
te.com
Dimensions are in inches and
millimeters unless otherwise
specified. Values in brackets
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA: 1-800-522-6752
Canada: 1-905-475-6222
Mexico: 52-55-1106-0800
L. & S. America: 54-11-4733-2200
Germany: 49-6251-133-1999
China: 86-400-820-6015
Japan: 81-44-844-8013
UK: 44-800-267-666
RAYCHEM Tubing Products
Tubing Kits and Mini-Spools
(Continued)
Single Wall Tubing
KIT 1 – 2 to 1 Shrink Ratio •
Black • 600V, 125°C,
UL/CSA VW-1
(KIT 1 PN: A55251-000)
Expanded I.D.
VERSAFIT-3/16”
VERSAFIT-1/4”
VERSAFIT-3/8”
VERSAFIT-1/2”
VERSAFIT-3/4”
VERSAFIT-1”
Quantity (6 Inch Pieces)
30
28
24
20
14
10
Fits Wire Gauge Size
18 – 14 AWG
12 – 10 AWG
8 AWG
6 –3 AWG
2 – 1/0 AWG
2/0 – 4/0 AWG
Refill Part Number
D76139-000
F37063-000
D27573-000
C02462-000
A92664-000
C21270-000
KIT 2 – 2 to 1 Shrink Ratio •
7 Colors** • 600V, 125°C,
UL/CSA VW-1 (except clear)
(KIT 2 PN: D54859-000)
Expanded I.D.
VERSAFIT-3/32”
VERSAFIT-1/8”
VERSAFIT-3/16”
VERSAFIT-1/4”
VERSAFIT-3/8”
VERSAFIT-1/2”
Quantity (6 Inch Pieces)
35
28
21
21
14
14
Fits Wire Gauge Size
18 AWG
16 AWG
14 AWG
12 – 10 AWG
8 AWG
6 – 3 AWG
Refill Part Number
E31091-000
349256-000
C53800-000
C87605-000
A82691-000
E10896-000
**Clear tubing in Kit 2 and Kit 2 Refills is RNF-100.
Adhesive-Lined Tubing
KIT 3 – Black/White/Red/Clear
• 600V, 125°C, UL
(KIT 3 PN: E42160-000)
Expanded I.D.
DWP-125-1/8”
DWP-125-3/16”
DWP-125-1/4”
DWP-125-1/2”
DWP-125-3/4”
DWP-125-1”
ES1000-NO.1
ES1000-NO.2
ES1000-NO.3
ES1000-NO.4
Quantity (6 Inch Pieces)
25
25
24
10
5
3
6
5
5
3
Fits Wire Gauge Size
20 – 16 AWG (3 to 1 Shrink Ratio)
14 –10 AWG (3 to 1 Shrink Ratio)
12 –10 AWG (3 to 1 Shrink Ratio)
6 –3 AWG
(3 to 1 Shrink Ratio)
2 – 1/0 AWG (3 to 1 Shrink Ratio)
2/0 – 4/0 AWG (3 to 1 Shrink Ratio)
16 – 12 AWG (4 to 1 Shrink Ratio)
12 – 10 AWG (4 to 1 Shrink Ratio)
10 – 8 AWG
(4 to 1 Shrink Ratio)
6 –3 AWG
(4 to 1 Shrink Ratio)
Refill Part Number
D14889-000
E87367-000
F91864-000
F41454-000
C67617-000
F66623-000
KITS 1, 2 and 3 are comprised of a durable six section plastic box with hinged lid. Inside the lid are product selection
guidelines. Ask your Sales Representative about KIT 4 and KIT 6, our Economy Tubing Kits in a reclosable plastic
bag, also used on “point of sale” racks. Here are Part Numbers for those Kits and their content:
KIT 4: E32151-000 (Three pieces each of 3/16”, 1/4”, 3/8”, 1/2”, 3/4” and 1” Black tubing in 6 inch pieces)
KIT 6: C72402-000 (Three pieces each of 3/64”, 1/16”, 3/32” and 1/8” Black tubing in 6 inch pieces)
VERSAFIT MINI-SPOOLS
2 to 1 Shrink Ratio • Black •
600V, 125°C, UL/CSA VW-1
Expanded I.D.
VERSAFIT-3/64”
VERSAFIT-1/16”
VERSAFIT-3/32
VERSAFIT-1/8”
VERSAFIT-3/16”
VERSAFIT-1/4”
VERSAFIT-3/8”
VERSAFIT-1/2”
VERSAFIT-3/4”
VERSAFIT-1”
Quantity (Feet)
100
75
65
60
50
40
35
30
25
15
Part Number
C16404-000
E40870-000
D70981-000
C17600-000
F27135-000
F64479-000
D57591-000
E37316-000
449582-000
F27156-000
VERSAFIT is a very flexible, highly flame-retardant polyolefin tubing, 90°C full recovery temperature, good fluid
resistance with a UL 224/CSA VW-1 flammability rating.
RNF-100 MINI-SPOOLS
2 to 1 Shrink Ratio • Black •
600V, 125°C, UL/CSA
Expanded I.D.
RNF-100-3/64”
RNF-100-1/16”
RNF-100-3/32
RNF-100-1/8”
RNF-100-3/16”
RNF-100-1/4”
RNF-100-3/8”
RNF-100-1/2”
RNF-100-3/4”
RNF-100-1”
Quantity (Feet)
100
75
65
60
50
40
35
30
25
15
Part Number
D00409-000
A66551-000
D42391-000
F56629-000
E77288-000
F75818-000
D12330-000
A81736-000
E40866-000
E62131-000
RNF-100 is a flexible, flame-retardant polyolefin tubing, 121°C full recovery temperature, excellent fluid resistance
with a UL 224/CSA All Tubing flammability rating.
1-126
9-1773447-9
CIS WR 08/2011
te.com
Dimensions are in inches and
millimeters unless otherwise
specified. Values in brackets
are metric equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA: 1-800-522-6752
Canada: 1-905-475-6222
Mexico: 52-55-1106-0800
L. & S. America: 54-11-4733-2200
Germany: 49-6251-133-1999
China: 86-400-820-6015
Japan: 81-44-844-8013
UK: 44-800-267-666
