SBL1030CT - SBL1060CT
10A SCHOTTKY BARRIER RECTIFIER
L
B
C
D
K
A
M
Features
•
•
•
•
•
•
•
Schottky Barrier Chip
Guard Ring Die Construction for
Transient Protection
Low Power Loss, High Efficiency
High Surge Capability
High Current Capability and Low Forward Voltage Drop
For Use in Low Voltage, High Frequency Inverters, Free
Wheeling, and Polarity Protection Applications
Lead Free Finish, RoHS Compliant (Note 3)
TO-220AB
Dim
Min
Max
A
14.48 15.75
B
10.00 10.40
C
2.54
3.43
D
5.90
6.40
E
2.80
3.93
G
12.70 14.27
H
2.40
2.70
J
0.69
0.93
K
3.54
3.78
L
4.07
4.82
M
1.15
1.39
N
0.30
0.50
P
2.04
2.79
All Dimensions in mm
1
2
3
E
G
J
N
Mechanical Data
•
•
•
•
•
•
•
Case: TO-220AB
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020C
Polarity: As Marked on Body
Terminals: Finish – Bright Tin. Solderable per MIL-STD-202,
Method 208
Marking: Type Number
Weight: 2.24 grams (approximate)
H H
Pin 1 +
Pin 2 -
Pin 3 +
+
Case
P
Maximum Ratings and Electrical Characteristics
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Average Rectified Output Current
@ T
C
= 95°C
(Note 1)
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
V
FM
I
RM
C
j
R
θ
JC
T
j
,
T
STG
@T
A
= 25°C unless otherwise specified
SBL
SBL
SBL
SBL
SBL
SBL
1030CT 1035CT 1040CT 1045CT 1050CT 1060CT
30
21
35
24.5
40
28
10
175
0.55
0.5
50
450
5.5
-65 to +150
0.70
45
31.5
50
35
60
42
Unit
V
V
A
A
V
mA
pF
°C/W
°C
Non-Repetitive Peak Forward Surge Current
8.3ms single half sine-wave superimposed on rated load
Forward Voltage Drop
@ I
F
= 5.0A, T
C
= 25°C
Peak Reverse Current
@ T
C
= 25°C
at Rated DC Blocking Voltage
@ T
C
= 125°C
Typical Junction Capacitance
(Note 2)
Typical Thermal Resistance Junction to Case
(Note 1)
Operating and Storage Temperature Range
Notes:
1. Thermal resistance junction to case mounted on heatsink.
2. Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
3. RoHS revision 13.2.2003. Glass and high temperature solder exemptions applied, see
EU Directive Annex Notes 5 and 7.
DS23048 Rev. 5 - 4
1 of 3
www.diodes.com
SBL1030CT - SBL1060CT
© Diodes Incorporated
DISCONTINUED
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
20
I
(AV)
, AVERAGE FORWARD CURRENT (A)
100
16
SBL1030CT - SBL1045CT
10
12
SBL1050CT - SBL1060CT
8
1.0
4
0
0
50
100
150
T
C
, CASE TEMPERATURE (°C)
Fig. 1 Forward Current Derating Curve
0.1
0.2
0.4
0.6
0.8
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics per Element
4000
T
j
= 25
°
C
300
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
8.3ms single half-sine-wave
250
C
j
, CAPACITANCE (pF)
200
1000
150
100
50
100
0
1
10
NUMBER OF CYCLES AT 60Hz
Fig. 3 Max Non-Repetitive Surge Current
100
0.1
1.0
10
100
V
R
, REVERSE VOLTAGE (V)
Fig. 4 Typical Junction Capacitance per Element
I
R
, INSTANTANEOUS REVERSE CURRENT (mA)
10
T
C
= 125
°
C
1.0
T
C
= 75
°
C
0.1
T
C
= 25
°
C
0.01
0.001
0
40
80
120
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
Fig. 5 Typical Reverse Characteristics
DS23048 Rev. 5 - 4
2 of 3
www.diodes.com
SBL1030CT - SBL1060CT
© Diodes Incorporated
DISCONTINUED
Ordering Information
Device
SBL10xxCT*
(Note 4)
Packaging
TO-220AB
Shipping
50/Tube
* xx = Device type, e.g. SBL1045CT
Notes:
4. For packaging details, visit our website at http://www.diodes.com/datasheets/ap02008.pdf.
