SQP2-18KJB5 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> SQP2-18KJB5

SQP2-18KJB5: DescriptionFixed Resistor, Metal Oxide Film, 2W, 18000ohm, 250V, 5% +/-Tol, 350ppm/Cel, Through Hole Mount, AXIAL LEADED; CategoryPassive components The resistor; File Size385KB，3 Pages; ManufacturerTT Electronics plc; Websitehttp://www.ttelectronics.com/; Environmental Compliance

Download Datasheet Parametric View All

SQP2-18KJB5 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	SQP2-18KJB5	-	-	View	Buy Now

SQP2-18KJB5 Overview

Fixed Resistor, Metal Oxide Film, 2W, 18000ohm, 250V, 5% +/-Tol, 350ppm/Cel, Through Hole Mount, AXIAL LEADED

SQP2-18KJB5 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1465582797
package instruction	AXIAL LEADED
Reach Compliance Code	compliant
YTEOL	7.75
structure	Rectangular
JESD-609 code	e3
Lead diameter	0.7 mm
Lead length	23 mm
Installation features	THROUGH HOLE MOUNT
Number of terminals	2
Maximum operating temperature	155 °C
Minimum operating temperature	-55 °C
Package height	8 mm
Package length	19 mm
Package form	Axial
Package width	8 mm
method of packing	BULK
Rated power dissipation(P)	2 W
Rated temperature	70 °C
resistance	18000 Ω
Resistor type	FIXED RESISTOR
surface mount	NO
technology	METAL OXIDE FILM
Temperature Coefficient	350 ppm/°C
Terminal surface	Tin (Sn)
Terminal shape	WIRE
Tolerance	5%
Operating Voltage	250 V

Preview

Download Datasheet

View All

Resistors

Ceramic Case Resistors –

Wirewound / Metal Oxide

SQP / CAF / CAW Series

2 watts to 25 watts

Resistance 0R1 to 200K

High overload capability

RoHS compliant

Flameproof ceramic case with inorganic potting material

All parts are Pb-free and comply with EU Directive 2011/65/EU amended by (EU) 2015/863 (RoHS3)

Electrical Data

SQP2 / CA-2 SQP3 / CA-3 SQP5 / CA-5 SQP7 / CA-7

Power rating at 70°C

Limiting element voltage

Resistance range – oxide (CAF)

Resistance tolerance

TCR

Isolation voltage

Standard values

Thermal impedance

Ambient temperature range

°C/W

°C

Resistance range – wirewound (CAW)

watts

volts dc or ac rms

ohms

ppm/°C

volts

250

0R1-27R

300

0R1-39R

40R-150K

350

0R1-47R

48R-150K

500

0R1-680R

SQP7S

350

1R0-100R

<20R: 400

≥20R:

350

1000

E24 preferred

-55 to +155

SQP10 /

CA-10

700

0R1-910R

SQP15 /

CA-15

700

1R0-1K0

1K1-200K

SQP20 /

CA-20

750

2R0-1K2

1K3-200K

CAW25

750

2R0-1K2

ohms 28R-120K

681R-200K 101R-150K 911R-200K

Physical Data

Dimensions (mm) and weight (g)

Type

SQP2 / CA-2

SQP3 / CA-3

SQP5 / CA-5

SQP7 / CA-7

SQP7S

SQP10 / CA-10

SQP15 / CA-15

SQP20 / CA-20

CAW25

L max.

W max.

13.5

15.5

H max.

12.5

14.5

f min.

d (±0.1)

0.7

0.75

Wt. nom.

2.2

3.5

8.2

17.4

26.7

Alternate body shape

(CAW-A / CAF-A)

General Note

TT Electronics reserves the right to make changes in product specification without notice or liability.

All information is subject to TT Electronics’ own data and is considered accurate at time of going to print.

BI Technologies IRC Welwyn

www.ttelectronics.com/resistors

04.21
