LC875816A(64QIP)

Description
IC,MICROCONTROLLER,8-BIT,CMOS,QFP,64PIN,PLASTIC
CategoryThe embedded processor and controller    Microcontrollers and processors
File Size521KB,23 Pages
ManufacturerON Semiconductor
Websitehttp://www.onsemi.cn
Environmental Compliance
Download Datasheet Parametric View All

LC875816A(64QIP) Overview

IC,MICROCONTROLLER,8-BIT,CMOS,QFP,64PIN,PLASTIC

LC875816A(64QIP) Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerON Semiconductor
Reach Compliance Codecompliant
Has ADCYES
Address bus width
bit size8
DAC channelNO
DMA channelNO
External data bus width
JESD-30 codeS-PQFP-G64
length14 mm
Number of I/O lines51
Number of terminals64
Maximum operating temperature70 °C
Minimum operating temperature-30 °C
PWM channelYES
Package body materialPLASTIC/EPOXY
encapsulated codeLQFP
Encapsulate equivalent codeQFP64,.7SQ,32
Package shapeSQUARE
Package formFLATPACK, LOW PROFILE
power supply2.5/3.3 V
Certification statusNot Qualified
RAM (bytes)1024
rom(word)16384
speed20 MHz
Maximum supply voltage3.6 V
Minimum supply voltage3 V
Nominal supply voltage3.3 V
surface mountYES
technologyCMOS
Temperature levelOTHER
Terminal formGULLWING
Terminal pitch0.8 mm
Terminal locationQUAD
width14 mm
uPs/uCs/peripheral integrated circuit typeMICROCONTROLLER
Base Number Matches1
Ordering number : EN8300A
LC875832A
LC875824A
LC875816A
Overview
CMOS IC
ROM 32K/24K/16K byte, RAM 1024 byte on-chip
8-bit 1-chip Microcontroller
The SANYO LC875832A/24A/16A are 8-bit microcomputers that, centered around a CPU running at a minimum bus
cycle time of 100ns, integrate on a single chip a number of hardware features such as 32K/24K/16K-byte ROM
1024-byte RAM, sophisticated 16-bit timers/counters (may be divided into 8-bit timers), a 16-bit timer/counter
(may be divided into 8-bit timers/counters or 8-bit PWMs), four 8-bit timers with a prescaler, a base timer serving as a
time-of-day clock, a high-speed clock counter, a synchronous SIO interface (with automatic block transmission/reception
capabilities), an asynchronous/synchronous SIO interface, a UART interface (full duplex), an 8-bit 11-channel AD
converter, two 12-bit PWM channels, a system clock frequency divider, ROM correction function , and a 23-source
10-vector interrupt feature.
Features
ROM
32768
×
8-bits (LC875832A)
24576
×
8-bits (LC875824A)
16384
×
8-bits (LC875816A)
RAM
1024
×
9 bits (LC875832A/24A/16A)
Minimum Bus Cycle
100ns (10MHz)
VDD=3.0 to 3.6V
125ns (8MHz)
VDD=2.5 to 3.6V
500ns (2MHz)
VDD=2.2 to 3.6V
Note: The bus cycle time here refers to the ROM read speed.
Minimum Instruction Cycle Time
300ns (10MHz)
VDD=3.0 to 3.6V
375ns (8MHz)
VDD=2.5 to 3.6V
1.5µs (2MHz)
VDD=2.2 to 3.6V
Ver.1.05
42706HKIM No.8300-1/23
