Data sheets for SMT types
Chokes for Data and Signal Lines
CAN Bus Choke, EIA 1812
Rated voltage 42 Vac/80 Vdc
Rated current 100 mA
Rated inductance 11 to 51
µH
Construction
s
Current-compensated ring core double choke
B82799
with ferrite core
s
Bifilar winding (B82799-C…)
s
Sector winding (B82799-S…)
Features
s
s
s
s
High performance
Case flame-retardant as per UL 94 V-0
Suitable for reflow soldering and conductive adhesion
Operation up to 150˚C
Applications
s
B82799-C:
Suppression of asymmetrical interference coupled in on lines,
whereas data signals up to some MHz can pass unaffectedly
s
B82799-S:
Suppression of asymmetrical and symmetrical interference
coupled in on lines. The high-frequency portions of the symmetrical
data signal are decreased so far that EMC problems can be
significantly reduced
Marking
Manufacturer, inductance value (coded),
date of manufacture, coded (year, day of week, calender week)
Delivery mode
Blister tape, reel packing
For details on taping, packing and packing units
see page 302
243
04/00
Chokes for Data and Signal Lines
CAN Bus Choke, EIA 1812
General technical data
Rated voltage
V
R
Rated current
I
R
Rated inductance
L
R
42 Vac (50/60 Hz)
80 Vdc
B82799
Referred to 50 Hz and 60
°C
ambient temperature
Measured with HP 4275A
at 100 kHz and 0,1 mA
(specified per winding)
±
30 %
< 10 % at dc magnetic bias with
I
R
Measured with HP 4275A.
Measuring frequency at
L
R
≤
11
µH
= 1 MHz, 5 mA
L
R
> 11
µH
= 100 kHz, 5 mA
Typical values, measured at 20
°C
ambient temperature
(215 3) ˚C, (3 0,3) s
wetting of soldering area
≥
95 %
in accordance with IEC 60068-2-58
40/125/56 (– 40
°C/+
125
°C/56
days damp heat test)
in accordance with EN 60068-1
Approx. 0,08 g
Inductance tolerance
Inductance decrease
∆
L/L
0
Stray inductance
L
S
DC resistance
R
typ
Solderability
Climatic category
Weight
Characteristics and ordering codes
L
R 1)
µH
11
22
33
51
L
S, typ
nH
45
1300
1800
2700
I
R
mA
100
100
100
100
R
typ
mΩ
150
200
250
300
V
T
Vdc, 2 s
250
250
250
250
Ordering code
B82799-C113-N1
B82799-S223-N1
B82799-S333-N1
B82799-S513-N1
1) Types up to 2200
µH
upon request.
245
04/00
Chokes for Data and Signal Lines
CAN Bus Choke, EIA 1812
Insertion loss
α
e
(typical values at
Z
= 50
Ω)
asymmetrical, all branches in parallel (common mode)
symmetrical (differential mode)
B82799-C113-N1
50
dB
α
e
SSB1414-F
B82799
B82799-S223-N1
50
dB
α
e
SSB1416-W
40
40
30
30
20
20
10
10
0
_
1
10
10
0
10
1
10
2
MHz 10
3
10
10
0
10
1
10
2
MHz 10
3
f
B82799-S333-N1
50
dB
α
e
SSB1417-5
f
B82799-S513-N1
50
dB
α
e
SSB1415-N
40
40
30
30
20
20
10
10
0
_
1
10
10
0
10
1
10
2
MHz 10
3
0
_
1
10
10
0
10
1
10
2
MHz 10
3
f
246
04/00
