10mm SCREW BASED LED LAMP
BLS101SURC/E12V HYPER RED
Features
!
BUILT-IN CURRENT LIMITING RESISTOR FOR DIRECT
Description
The Hyper Red source color devices are made with DH
InGaAlP on GaAs substrate Light Emitting Diode.
APPLICATION OF DIFFERENT ACROSS CURRENT.
!
LONG LIFE.
!
LOW CURRENT, POWER SAVINGS.
!
LOW MAINTENANCE.
!
DIFFERENT COLOR AVAILABLE.
!
SOLID STATE, HIGH VIBRATION RESISTANT.
!
12V
INTERNAL RESISTOR
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Specifications are subject to change without notice.
SPEC NO: DSAB2236
APPROVED: J.LU
REV NO: V.2
CHECKED: Allen Liu
DATE: APR/14/2003
DRAWN:S.J.HOU
PAGE: 1 OF 3
Selection Guide
Par t No .
Dic e
L en s Ty p e
Min .
BLS101SURC/E12V
HYPER RED (InGaAlP)
WATER CLEAR
650
Iv (m c d )
V=12V
Ty p .
1800
V i ew i n g
An g l e
2θ1/2
20 °
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Electrical / Optical Characteristics at T
)
=25°C
°
Sy m b o l
λ
peak
D
∆λ
1/2
I
F
I
R
Par am et er
Peak Wavelength
Dominate Wavelength
Spectral Line Half-width
Forward Current
Reverse Current
D ev i c e
Hyper Red
Hyper Red
Hyper Red
Hyper Red
Hyper Red
Ty p .
640
6 30
25
21.7
10
Max .
Un it s
nm
nm
nm
mA
uA
Tes t Co n d it io n s
V
F
=12V
V
F
=12V
V
F
=12V
V
F
=12V
V
R
= 5V
Absolute Maximum Ratings at T
)
=25°C
°
Par am et er
Power dissipation for 12V
DC Forward Voltage for 12V
Reverse Voltage
Operating Temperature
Storage Temperature
H y p e r R ed
270
14
5
-40
°
C To +70
°C
-40
°
C To +85
°C
Un it s
mW
V
V
SPEC NO: DSAB2236
APPROVED: J.LU
REV NO: V.2
CHECKED: Allen Liu
DATE: APR/14/2003
DRAWN:S.J.HOU
PAGE: 2 OF 3
