Part No. MAANIN0055
Automotive Telematics
Automotive Roof Mount
Sirius Satellite Digital Radio Antenna
Shape
Dimensions
Cable Protector Length
Weight
Color
Radome Material
Output Connectors
Cable
Materials
Base Construction
Mounting
Elliptical base, low-profile contoured radome
3.0" wide x 4.5" long x 1.56" high
6"
4 ounces
Black
UV,Ozone, Solar stable material
2 x FAKRA (color coded) SMB
1
2 x 15', 0.070" dia. low-loss coaxial
Corrosion resistant
Die cast zinc
Roof mount w/ adhesive strips or roof thru-hole
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Chemical Resistance
Salt
Electrostatic Discharge
-40°C to +85°C
5 to 95% RH (rain resistant)
-45°C to +95°C
Oil, gasoline, detergents
5%NaCl @ 35°C
RC Surge protection on PCB
Electrical
Frequency
Antenna Element Gain, Passive
Polarization
Output VSWR
LNA Gain
LNA Noise Figure
Compression @ L1
Voltage
Current
1
2
Satellite
Terrestrial
2320.0 to 2332.5 MHz
2323.7 to 2328.8 MHz
2
See below
-2 to +2 dBi
3
LHCP
Linear Vertical
2.0:1 max
2.0:1 max
33.5 dB min, 38.5 dB max
25 dB min, 30.5 dB max
0.7 dB typ, 0.9 dB max
2 dB typ, 2.5 dB max
+16 dBm min @ LNA output
+9 dBm min @ LNA output
+5.3 to +8.0 VDC
+5.3 to +8.0 VDC
160 mA typ
3
Sat keycode K, curry; Terr keycode Z, white/natural
2 dBic min from 20° to 90° above horizon;
3 dBic min from 25° to 75° above horizon
From 0° (horizon) to 10° above horizon
51mcu
