SAW Components
Low-Loss Filter for Mobile Communication
Data Sheet
B7713
836,5 MHz
Chip Size SAW Package DCS4H
Features
s
Low-loss RF filter for mobile telephone
s
s
s
s
0,1
1
2
AMPS systems, transmit path
High Rx rejection
Usable passband 25 MHz
Package for Surface Mounted
Technology (SMT)
Pb-Free
0,1
bottom view
4
3
0,7
Terminals
0,8
2,5
0,6
side view
s
Gold-plated Ni
2,0
top view
Dimensions in mm, approx. weight 0,015 g
Pin configuration
1
3
2, 4
Input
Output
Ground
1
2
3
4
Type
B7713
Ordering code
B39841-B7713-K710
Marking and Package
according to
C61157-A7-A136
Packing
according to
F61074-V8189-Z000
Electrostatic Sensitive Device
(ESD)
Maximum ratings
Operating temperature range
Storage temperature range
DC voltage
ESD voltage
Input Power max.
T
T
stg
V
DC
V*
ESD
P
IN
– 20/+ 70
– 40/+ 85
5
100*
15
˚C
˚C
V
V
dBm
Machine Model, 10 pulses
source impedance 50
Ω
* - acc. to JESD22-A115A (Machine Model), 10 negative & 10 positive pulses
2
Jan 24, 2005
SAW Components
Low-Loss Filter for Mobile Communication
Data Sheet
Characteristics
Operating temperature range:
Terminating source impedance:
Terminating load impedance:
B7713
836,5 MHz
T
= -20 to +70 ˚C
Z
S
= 50
Ω
Z
L
= 50
Ω
min.
typ.
836,5
max.
—
MHz
Center frequency
Maximum insertion attenuation
824,0 ... 849,0
Amplitude ripple
(p-p)
824,0 ... 849,0
Return loss
824,0 ... 849,0
Attenuation
0,0
869,0
1050,0
2000,0
2600,0
3200,0
4000,0
... 800,0
...1050,0
...2000,0
...2600,0
...3200,0
...4000,0
...6000,0
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
MHz
f
C
α
max
MHz
∆α
—
—
2,5
3,5
dB
—
1,0
2,0
dB
—
α
40,0
30,0
45,0
35,0
30,0
20,0
10,0
12,0
10,0
dB
50,0
32,0
50,0
40,0
40,0
25,0
18,0
—
—
—
—
—
—
—
dB
dB
dB
dB
dB
dB
dB
3
Jan 24, 2005
