645235-8 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 645235-8

645235-8: Description60 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, SOLDER; CategoryThe connector The connector; File Size116KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

645235-8 Overview

60 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, SOLDER

645235-8 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Objectid	2129257940
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	POLARIZED
body width	0.368 inch
subject depth	0.61 inch
body length	6.26 inch
Body/casing type	RECEPTACLE
Connector type	CARD EDGE CONNECTOR
Contact to complete cooperation	GOLD (30)
Contact completed and terminated	Tin (Sn)
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact resistance	10 mΩ
Contact style	BELLOWED TYPE
DIN compliance	NO
Dielectric withstand voltage	1000VAC V
Filter function	NO
IEC compliance	NO
maximum insertion force	3.336 N
Insulation resistance	5000000000 Ω
Insulator color	BLACK
insulator material	GLASS FILLED POLYESTER
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	645235
Plug contact pitch	0.1 inch
Match contact row spacing	0.2 inch
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
PCB contact row spacing	5.08 mm
Plating thickness	30u inch
Rated current (signal)	2.5 A
Guideline	UL, CSA
reliability	COMMERCIAL
Terminal length	0.125 inch
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	60
UL Flammability Code	94V-0
Evacuation force-minimum value	.556 N

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

One-Piece C ard Edge C onnectors

Product Feature Selector

> Product Details

645235-8 Product Details

Live Product Chat

Product Photo

Standard Edge II Card Edge & Power Connectors

Not EU R oHS or ELV C om plia nt

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

645235-8

T E I nternal N umber: 6 4 5 2 3 5 - 8

Product Highlights:

C onnector

Product Series = Standard Edge II

C onnector Type = Standard

2.54 mm C enterline

60 Dual Positions

View all Features

Obsolete

Search for Replacement Parts

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

C ONNEC TOR ASSEMBLY, STANDARD EDGE II, 2.54 [.100] C E...

(PDF, English)

Catalog Pages/Data Sheets:

card edge connectors

(PDF, English)

Product Specifications:

C onnector, Standard Edge

(PDF, English)

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = C onnector

Product Series

= Standard Edge II

C onnector Type

= Standard

Number of Dual Positions

= 60

Post Type

= Solder Post

PC B Mount Angle

= Vertical

Mounting Ears

= Without

PC B Retention Feature

= Yes

PC B Retention Location

= 3-6, 55-58, 63-66, 115-118

Electrical Characteristics:

High C urrent = No

Termination Related Features:

Termination Post Length (mm [in])

= 3.18 [0.125]

Solder Tail C ontact Plating = Tin

Body Related Features:

C enterline (mm [in])

= 2.54 [0.100]

Retention Latch

= Without

Positions Unloaded

= None

Keyed Position

= 0

Contact Related Features:

C ontact Mating Area Plating Material

= Gold (30)

C ontact Base Material = Phosphor Bronze

C ontact Underplating = Nickel

Housing Related Features:

Housing Material = Polyester GF

Housing C olor = Black

Housing Flammability Rating = UL 94V-0

Industry Standards:

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

Other:

Brand = AMP

Additional Information:

Product Line Information
