PART NUMBER
LED COLOR (nm)
5988B10102F
5988B10107F
5988B30102F
5988B30107F
5988B40102F
5988B40107F
5988B60102F
5988B60107F
5988B80102F
5988B80107F
5988B90102F
5988B90107F
RED (623)
ORANGE (605)
YELLOW (590)
YELLOW GREEN (570)
GREEN (525)
BLUE (470)
NOTES:
1. PIN NUMBERS ARE FOR REFERENCE ONLY, DESIGNATION NON-EXISTENT
ON PART.
2. LABELING FOR REEL AND OUTSIDE OF ALUMINUM BAG,
DIALIGHT P/N, QUANTITY PER REEL, DATE CODE, INTENSITY BIN CODE,
LOT NUMBER AND COUNTRY OF ORIGIN
3. THIS PRODUCT IS RoHS COMPLIANT. EACH BAG IS TO BE MARKED WITH RoHS
COMPLIANT LABEL OR EQUIVALENT MARKINGS. LED MUST BE Pb FREE.
4. MOISTURE SENSITIVITY LEVEL 3
5. QUANTITY IS 2000 PCS/ REEL
REV
A
REVISIONS
NEW RELEASE
DRN APP
DATE
LD
NO
1-9-19
RECOMMENDED RoHS SOLDER PROFILE
.14
[3,5]
.13
[3,2]
.11
[2,8]
UNITS: mm
TOLERANCE (UNLESS OTHERWISE SPECIFIED): ±0.2mm
POLARITY MARK
MARK
TS
max
TS
min
T
s
T
L
t
L
T
P
t
P
DTr/Dt
DTd/Dt
DEFINITION
Maximum of pre-heating temperature
Minimum of pre-heating temperature
Time form Tsmin to Tsmax
Reference temperature
Retention time for TL
Peak Temperature
Time for peak temperature
Temperature rising rate
Temperature decreasing rate
CONDITION
200 C
150 C
60-120 sec
217 C
within 60s
TAPING SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS AT 25 C
.07
[1,9]
PIN 2
PIN 1
LED COLOR
RED
ORANGE
YELLOW
YELLOW GREEN
GREEN
BLUE
POWER
DISSIPATON
(mW)
72
72
72
72
100
100
FORWARD PEAK FORWARD
CURRENT
CURRENT
(mA)
(mA)
REVERSE
VOLTAGE
(V)
OPERATING
STORAGE
DERATING CURVE
TEMPRATURE TEMPRATURE
FROM 25 C
( C)
( C)
(mA/ C)
.56
.56
.56
.56
.56
.56
260 C
within 10s
under 3 C/sec
under -3 C/sec
30
100
5
-40 TO +85
-40 TO +100
.09
[2,2]
LED COLOR
.03
[0,8]
.07
[1,9]
IF (mA)
RED
ORANGE
YELLOW
YELLOW GREEN
GREEN
.08
[2,14]
.06
[1,6]
BLUE
20
OPERATING CHARACTERISTICS AT 25
LUMINOUS
INTENSITY
(mcd)
MIN.
200
260
200
40
1200
230
TYP.
380
345
315
80
1750
395
MAX.
560
430
430
120
2300
560
DOMINANT
WAVELENGTH
(nm)
MIN
615
600
585
565
520
465
TYP.
623
605
590
570
525
470
MAX
630
610
595
575
530
475
C
REVERSE
CURRENT
MAX
FORWARD
VOLTAGE
IF=5mA
TYP.
1.8
1.8
10µA @ VR=5V
1.8
1.8
2.8
2.8
MAX.
2.4
2.4
2.4
2.4
3.5
3.5
THIS DRAWING AND THE CONTENTS HEREIN ARE CONFIDENTIAL AND THE SOLE
PROPERTY OF DIALIGHT CORP. REPRODUCTION OF THIS DRAWING OR
CONSTRUCTION OF ANY PARTS WITHIN THIS DRAWING ARE FORBIDDEN WITHOUT
THE WRITTEN CONSENT OF DIALIGHT CORP.
ATTENTION:
OBSERVE PRECAUTIONS FOR
HANDLING ELECTROSTATIC
SENSITIVE DEVICES
SCALE: 10.00
ALL DIM's: INCH (mm)
TOLERANCES:
UNLESS OTHERWISE SPECIFIED
DRAWING NUMBER
REV
C-18404
TITLE
A
PIN 2
ANODE
.05
[1,25]
PIN 1
CATHODE
FRACTIONS: 1/64
DECIMALS (.XX): .01
DECIMALS (.XXX): .008
ANGLES:
1
3528 PACKAGE
-
1501 ROUTE 34 SOUTH
FARMINGDALE, NJ 07727
(732) 919-3119
www.dialight.com
MATERIAL
FINISH
LED SCHEMATIC
-
FSCM 83330
SHEET
1
OF
1
RECOMMENDED SOLDER PAD LAYOUT
