Power Capacitor
Discharge Reactor
Preliminary data
Accessories
B44066E9900S001
Characteristics
Fast discharge for fast reconnection of PFC capacitors
Reduced losses
Shockproof case for rail mounting
Technical data
Weight
Dimensions
Case
Voltage
Frequency
Internal configuration
Resistance
Discharge time
0.5 kg
90 mm x 45 mm x 59 mm
shockproof
230 to 525 V
50/60 Hz
2 winding in V arrangement
4 900
Ω
230 V
up to 25 kvar < 10 s
up to 50 kvar < 20 s
up to 100 kvar < 40 s
400 ... 525 V up to 25 kvar < 5 s
up to 50 kvar < 10 s
up to 100 kvar < 20 s
Power loss
Free wheeling current
Accepted discharge number
Temperature class
Cable diameter
Terminals
Installation location
Degree of protection
Ambient temperature
Cooling
< 1.8 W
< 4.5 mA
1 x / (minute and 100 kvar)
ta = 40°C/B
0.75 ... 2 x 2.5 mm
2
fixing torque: 0.5 Nm
indoor
IP40
-25 ... +55 °C
natural
FK PM PFC
Page 1 of 2
August 2004
Power Capacitor
Discharge Reactor
Preliminary data
Accessories
B44066E9900S001
Dimensional drawings
6
Please read information about PFC capacitors and accessories and cautions as well as installation and
maintenance instructions (Power Factor Correction Product Profile, actual version) to ensure optimum performance
and prevent products from failing, and in worst case, bursting and fire, etc.
Information given in the PFC-product profile and values given in the data sheet reflect typical specifications. You
are kindly requested to approve our product specifications or request our approval for your specification before
ordering.
EPCOS AG 2004. Reproduction, publication and dissemination of this data sheet, enclosures hereto and the information
contained therein without EPCOS’ prior express consent is prohibited.
Purchase orders are subject to the General Conditions for the Supply of Products and Services of the Electrical and
Electronics Industry recommended by the ZVEI (German Electrical and Electronic Manufacturers’ Association), unless
otherwise agreed.
FK PM PFC
Page 2 of 2
August 2004
