PRELIMINARY
SOLID STATE DEVICES, INC.
14005 Stage Road * Santa Fe Springs, Ca 90670
Phone: (562) 404-4474 * Fax: (562) 404-1773
SFT6800
2 AMP
500 VOLTS
NPN TRANSISTOR
TO-5
DESIGNER'S DATA SHEET
FEATURES:
BV
CEO
400V.
Fast Switching.
Very Low Leakage.
Low Saturation Voltage.
200
o
C Operating, Gold Eutectic Die Attach.
Designed for Complementary Use with SFT1192.
MAXIMUM RATINGS
Collector-Emitter Voltage
Collector-Base Voltage
Emitter-Base Voltage
Collector Current
Base Current
Total Device Dissipation @ T
C
=100
o
C
Derate above 100
o
C
Operating and Storage Temperature
Thermal Resistance, Junction to Case
CASE OUTLINE: TO-5
SYMBOL
V
CEO
V
CBO
V
EBO
I
C
I
B
P
D
T
J,
T
STG
R
2JC
VALUE
400
500
10
2
0.5
6.67
150
-65 to +200
15
COLLECTOR
UNITS
Volts
Volts
Volts
Amps
Amps
W
mW/
o
C
o
C
o
C/W
BASE
EMITTER
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: TR0005B
SFT6800
ELECTRICAL CHARACTERISTICS
Collector-Emitter Breakdown Voltage
(I
C
= 20mA
DC
)
Collector-Base Breakdown Voltage
(I
C
= 100uA
DC
)
Emitter-Base Breakdown Voltage
(I
E
= 20uA
DC
)
Collector Cutoff Current
(V
CB
= 400V
DC
)
Collector Cutoff Current
(V
CE
= 400V
DC
, V
EB
= 1.5V
DC
)
Emitter Cutoff Current
(V
EB
= 6V
DC
)
DC Current Gain*
(V
CE
= 5V
DC
)
Collector-Emitter Saturation Voltage*
(I
C
= 500mA
DC,
I
B
= 50mA
DC
)
Base-Emitter Saturation Voltage*
(I
C
= 500mA
DC,
I
B
= 50mA
DC
)
Current Gain Bandwidth Product
(I
C
= 50mA
DC ,
V
CE
= 10V
DC,
f = 20MHz)
Output Capacitance
(V
CB
= 30V
DC ,
I
E
= 0A
DC,
f = 2.0MHz)
Turn On Time
Turn Off Time
(V
CC
= 330V
DC ,
I
C
= 500mA
DC
,
I
B1
= I
B2
= 100mA
DC
R
B1
= R
B2
= 330S)
PRELIMINARY
SOLID STATE DEVICES, INC.
SYMBOL
BV
CEO
BV
CBO
BV
EBO
I
CBO
I
CEV
I
EBO
(I
C
= 50mA
DC
)
(I
C
= 500mA
DC
)
(I
C
= 1.0A
DC
)
H
FE
V
CE(SAT)
V
BE (SAT)
fT
C
ob
t
(on)
t
(off)
MIN
400
500
10
-
-
-
50
40
15
-
-
25
-
-
-
MAX
-
-
-
200
200
200
-
-
-
500
1.0
-
40
700
2000
mV
DC
V
DC
MHz
pf
ns
ns
UNITS
V
V
V
nA
nA
nA
14005 Stage Road * Santa Fe Springs, Ca 90670
Phone: (562) 404-4474 * Fax: (562) 404-1773
*Pulse Test: Pulse Width = 300us, Duty Cycle = 2%
