3.3Vdc • HCMOS/ TTL COMPATIBLE FULL-SIZE AND HALF-SIZE DIP
CRYSTAL CLOCK OSCILLATORS
ACOL and ACHL
20.2 x 12.6 x 5.08 mm
FEATURES:
APPLICATIONS:
• Tristate Enable / Disable option.
• HCMOS and TTL compatible.
• Low power
• Low voltage 3.3Vdc.
• Tight symmetry option.
• Clock signal sources for digital chips and microprocessors.
• Low power applications.
STANDARD SPECIFICATIONS
PARAMETERS
Package Type
Frequency Range
STANDARD SPECI
ACOL (14 DIP)
I
and
NS
(8 DIP)
FICAT O
ACHL
(F
o
)
32.768 k Hz - 200 MHz
0°C to +70°C
(See Options)
-55°C to +125°C
±100ppm max.
(See Options)
3.3Vdc ±10%
_
20m A max. for F < 20 MHz
_
25m A max. for F < 70 MHz
_
50m A max. for F < 200 MHz
SPECIFICATIONS
Operating Temperature
(T
OPR
)
Storage Temperature
(T
STO
)
Frequency Stability
(DF/ F
o
)
Supply Voltage
(V
dd
)
Input Current
(I
dd
)
ACOL
(14 DIP)
Dimensions: Inches (mm)
Duty Cycle or Symmetry
40 / 60% max. (typical 45 / 55%)
(See Options)
Rise and Fall Times
(T
R
/
T
F
)
10ns max.
Output Load
5TTL or 15pF
Output Voltage
0.9*V
dd
min. (V
OH
) ; 0.1*V
dd
max. (V
OL
)
Start-up Time
(T
OSC
)
10ms max.
> 2.2V
_
Tristate Function
(V
IH
)
“1” or Open: Oscillation
(Option “-A” ONLY)
(V
IL
)
“0”:Output disabled in high impedance (Hi Z) < 0.8V
Output Disable / Enable Time
100ns max. (for Option “- A” ONLY)
* Pin 1 has internal pull-up resistor which allows Pin 1 to be left floating (enable high) opt. A.
Test circuit, waveforms, see appendix B. Recommended handling, see appendix F.
Environmental and mechanical specifications, see appendix C. Group 1.
Marking, see appendix G. Value added, see appendix D.
Application notes, see appendix A.
ORDERING OPTIONS
ORDERINGOPTIONS
ACH L
( 8 DIP)
ACX L - Frequency - Temperature - Overall Frequency Stability
-
Duty Cycle - Tristate - Value Added
-
Packaging
-G Gull Wing*
O or H
-T for Tape and reel
-Y for ± 10 ppm max** -S for 45 / 55%
@
1
/
2 Vdd
-G2 Gull Wing * (ACHL Only) -TY for Tray packing
-J for ± 20 ppm max
-T for 47.5 / 52.5%
@
1
/
2 Vdd
XX.XXXXX MHz or kHz
-QXX (Trimmed Leads) *
-R for ± 25 ppm max
-S1 for 45 / 55%
@
1.4 Vdc
PIN # PIN #
-K for ± 30 ppm max
FUNCTION
-D for -10°C to + 60°C
ACOL ACHL
-H for ± 35 ppm max
- A for Tristate E / D
-E for -20°C to + 70°C
1
1
NC or E/D
-C for ± 50 ppm max
-F for -30°C to + 70°C
7
4
GND / Case
** Standard Operating
-N for -30°C to + 85°C
8
5
Output
Temperature Only
-L for -40°C to + 85°C
Frequency 50 MHz max
14
8
V
dd
ABRACON
®
NOTE: Left blank if standard
•
All specifications and markings subject to change without notice
52
C O R P O R AT I O N
29 Journey • Aliso Viejo, CA 92656 • USA
(949) 448-7070 •
F
AX
: (949) 448-8484
E-
MAIL
:
abinfo
@
abracon.com •
I
NTERNET
A
DDRESS
:
www.abracon.com
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
