SMD Voltage Controlled Crystal Oscillators
DSV753S SERIES
Features
7.3×4.9×1.5mm size miniature SMD-VCXO (0.06cc)
●
3-state function
●
Pb-Free
Applications
●
Actual size
RoHS Compliant
DVD, digital TV, STB, ADSL, BB modem, backbone
transmission equipment
Standard Specification
Item
Output Specification
Output Frequency Range
Supply Voltage
Frequency Control Voltage
Storage Temperature Range
Operating Temperature Range
Frequency Tolerance
Frequency Adjustment Range
Current Consumption
Output Load
Symmetry
Rise and Fall Time
0 Level Output Voltage
1 Level Output Voltage
Output Enable Time
Output Disable Time
Type Legend
−
fo
Vdd
Vcont
T_stg
T_use
f_tol
f_cont
Idd
DSV753SV
CMOS
16∼90MHz
＋3.3±0.3V
＋1.65±1.35V
−40∼＋85℃
−10∼＋70℃
DSV753SB
DSV753SK
LV-PECL
16∼50MHz
＋5.0±0.5V
＋2.5±2.0V
77∼160MHz
＋3.3±0.165V
＋1.65±1.65V
−50∼＋125℃
−20∼70℃, −40∼85℃
±50×10
±90×10
10mA max.
［No Load½
−6
−6
max.
±100×10
−6
min.
70mA max.
50Ω to Vdd
−
2V
40∼60%
（at output crosspoint）
1.5ns max. 20∼80％Output Level）
（
Vdd−1.62V max.
Vdd−1.025V min.
1.0μs max.
1.0μs max.
min.
15mA max.
［No Load½
15pF max.
SYM
tr, tf
Vol
Voh
Ｔpzl
Ｔplz
Vil
Vih
40∼60%（Vdd×0.5V Level）
10ns max.（10∼90% Vdd Level）
Vdd×0.1 max.
Vdd×0.9 min.
150ns max.
150ns max.
Vdd×0.3 max.
Vdd×0.7 min.
1000pcs./reel
（φ254）
OE Pin 0 Level Input Voltage
OE Pin 1 Level Input Voltage
Packing Unit
Consult our sales representative for other specifications.
Dimensions[mm]
7.3±0.2
＃6
4.9±0.2
＃5
＃4
Frequency
DSV753SV DSV753SB（A+kHz）
DSV753SK（kHz）
Recommended Land Pattern
[mm]
〈Top View〉
2.54
2.54
#1 Index
＃1
1.5±0.2
2.54
2.54
4.2
＃2
Logo
＃3
Lot No.
Model Code
DSV753SV→V753SV
DSV753SB→V753SB
DSV753SK→V753SK
Pin Connections
Pin No. Connection
#1
Vcont
OE(Output Enable)
#2
GND
#3
Output
#4
NC
- DSV753SV
#5
DSV753SB
OUTN - DSV753SK
#6
Function
#2 input
H
Open
L
Vdd
＃1
＃2
＃3
3.65
1.8
1.4
1.05
＃6
＃5
＃4
#4,#5 output condition
Oscillation out
Oscillation out
High Z
2.0
