ES1A - ES1J
1.0 AMP. Surface Mount Super Fast Rectifiers
SMA/DO-214AC
Features
Glass passivated junction chip
For surface mounted application
Low profile package
Built-in strain relief,
Ideal for automated placement
Easy pick and place
Super fast recovery time for high efficiency
Glass passivated chip junction
High temperature soldering:
260
O
C/10 seconds at terminals
Plastic material used carries Underwriters
Laboratory Classification 94V-0
Mechanical Data
Cases: Molded plastic
Terminals: Pure tin plated, lead free.
Polarity: Indicated by cathode band
Packing: 12mm tape per EIA STD RS-481
Weight: 0.064 gram
Dimensions in inches and (millimeters)
Maximum Ratings and Electrical Characteristics
Rating at 25
O
C
ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Symbol ES ES ES ES ES ES ES ES
Units
Type Number
1A 1B 1C 1D 1F 1G 1H 1J
Maximum Recurrent Peak Reverse Voltage
V
V
RRM
50 100 150 200 300 400 500 600
Maximum RMS Voltage
V
V
RMS
35 70 105 140 210 280 350 420
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
See Fig. 1
Peak Forward Surge Current, 8.3 ms Single
Half Sine-wave Superimposed on Rated
Load (JEDEC method )
Maximum Instantaneous Forward Voltage
@ 1.0A
Maximum DC Reverse Current @ T
A
=25
o
C
at Rated DC Blocking Voltage @ T
A
=100
o
C
Maximum Reverse Recovery Time ( Note 1 )
Typical Junction Capacitance ( Note 2 )
Maximum Thermal Resistance (Note 3)
Operating Temperature Range
V
DC
I
(AV)
I
FSM
V
F
I
R
50
100 150 200 300 400 500 600
1.0
30
0.95
5.0
100
35
10
85
35
-55 to +150
-55 to +150
8
o
V
A
A
1.3
1.7
V
uA
uA
nS
pF
Trr
Cj
R
θJA
R
θJL
T
J
C
/W
o
o
Storage Temperature Range
T
STG
1. Reverse Recovery Test Conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A
Notes:
2. Measured at 1 MHz and Applied V
R
=4.0 Volts
3. P.C.B. Mounted on 0.2 x 0.2” (5.0 x 5.0mm) Copper Pad Area.
C
C
- 178 -
Version: B07
RATINGS AND CHARACTERISTIC CURVES (ES1A THRU ES1J)
FIG.1- MAXIMUM FORWARD CURRENT DERATING
CURVE
1.2
50
Tj=25 C
PULSE WIDTH-300 S
1% DUTY CYCLE
0
FIG.2- TYPICAL INSTANTANEOUS
FORWARD CHARACTERISTICS
AVERAGE FORWARD CURRENT. (A)
1.0
RESISTIVE OR
INDUCTIVE LOAD
0.2X0.2"(5.0X5.0mm)
COPPER PAD AREAS
0.8
INSTANTANEOUS FORWARD CURRENT. (A)
10
1A
-D
0.4
1
0
80
90
100
110
120
o
130
140
150
0.1
LEAD TEMPERATURE. ( C)
FIG.3- MAXIMUM NON-REPETITIVE PEAK FORWARD
SURGE CURRENT
PEAK FORWARD SURGE CURRENT. (A)
30
8.3ms Single Half Sine Wave
o
(JEDEC Method) at T
L
=120 C
0.01
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
FORWARD VOLTAGE. (V)
20
25
15
10
FIG.5- TYPICAL REVERSE CHARACTERISTICS
1000
5.0
INSTANTANEOUS REVERSE CURRENT. ( A)
1
10
NUMBER OF CYCLES AT 60Hz
100
100
Tj=125
0
C
FIG.4- TYPICAL JUNCTION CAPACITANCE
14
12
10
8.0
6.0
4.0
2.0
0
0
1
Tj=25
0
C
f=1.0MHz
Vsig=50mVp-p
10
Tj=85
0
C
JUNCTION CAPACITANCE.(pF)
ES1
A-
D
ES
1F
-J
Tj=25
0
C
0.1
10
100
0.01
0
20
40
60
80
100
120
140
PERCENT OF RATED PEAK REVERSE VOLTAGE. (%)
REVERSE VOLTAGE. (V)
FIG.6- REVERSE RECOVERY TIME CHARACTERISTIC AND TEST CIRCUIT DIAGRAM
50W
NONINDUCTIVE
10W
NONINDUCTIVE
+0.5A
(-)
DUT
(+)
50Vdc
(approx)
(-)
PULSE
GENERATOR
(NOTE 2)
1W
NON
INDUCTIVE
OSCILLOSCOPE
(NOTE 1)
(+)
0
-0.25A
trr
NOTES: 1. Rise Time=7ns max. Input Impedance=
1 megohm 22pf
2. Rise Time=10ns max. Sourse Impedance=
50 ohms
-1.0A
1cm
SET TIME BASE FOR
5/ 10ns/ cm
ES
1
H
-1
0.2
ES
1F
J
-1
0.6
ES
G
Version: B07
