OX-2001-EAJ-2080-10M0000000

Description
HCMOS Output Clock Oscillator, 10MHz Min, 100MHz Max, 10MHz Nom
CategoryPassive components    oscillator
File Size2MB,5 Pages
ManufacturerVectron International, Inc.
Websitehttp://www.vectron.com/
Environmental Compliance
Download Datasheet Parametric View All

OX-2001-EAJ-2080-10M0000000 Overview

HCMOS Output Clock Oscillator, 10MHz Min, 100MHz Max, 10MHz Nom

OX-2001-EAJ-2080-10M0000000 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Objectid1422276108
package instructionDIP5/6,.75,375
Reach Compliance Codecompliant
Ageing0.5 PPM/FIRST YEAR
Frequency Adjustment - MechanicalNO
frequency stability0.02%
Frequency Stability - Voltage0.01 ppm
input power1 W
Installation featuresTHROUGH HOLE MOUNT
Number of terminals5
Nominal operating frequency10 MHz
Maximum operating temperature70 °C
Minimum operating temperature-20 °C
Oscillator typeHCMOS
Output load15 pF
Oven power supply voltage3.3V
Package body materialMETAL
Encapsulate equivalent codeDIP5/6,.75,375
physical size25.8mm x 25.8mm x 13.35mm
Certification statusNot Qualified
Maximum supply voltage3.465 V
Minimum supply voltage3.135 V
Nominal supply voltage3.3 V
surface mountNO
Preheating power3 W
Maximum warm-up time5 Minute
Oven Controlled Crystal Oscillator
OX-200
OX-200
Features
• Reflow Process Compatible
• AT-Cut and SC-Cut Crystal Options
• Low Profile Compact Package
Applications
Base Stations
Test Equipment
Synthesizers
Military Communication Equipment
Digital Switching
Performance Specifications
Frequency Stabilities
1
(AT-Cut Crystal-Standard)
Parameter
vs. operating temperature range
(referenced to +25°C)
Min
-50
-100
-150
-200
-0.3
-10
-10
-2
-500
-250
Typical
Max
+50
+100
+150
+200
+0.3
+10
+10
+2
+500
+250
5
Unit
ppb
ppb
ppb
ppb
ppm
ppb
ppb
ppb
ppb
ppb
minutes
Condition
0 to +70°C
-20 to +70°C
-40 to +70°C
-40 to +85°C
at time of shipment, nominal EFC
V
S
±5% static
Load ±5% static
after 30 days of operation
after 30 days of operation
after 30 days of operation
to ±100ppb of final frequency (1 hour
reading) @ +25°C
0 to +70°C
-20 to +70°C
-40 to +70°C
-40 to +85°C
at time of shipment, nominal EFC
V
S
±5% static
Load ±5% static
after 30 days of operation
after 30 days of operation
after 30 days of operation
to ±10ppb of final frequency (1 hour read-
ing) @ +25°C
Initial tolerance
vs. supply voltage change
vs. load change
vs. aging/day
vs. aging/1st year
vs. aging/year (following years)
Warm-up time
Frequency Stabilities
1
(SC-Cut Crystal-Option)
vs. operating temperature range
(referenced to +25°C)
-10
-20
-25
-30
-100
-5
-5
-1
-100
-50
+10
+20
+25
+30
+100
+5
+5
+1
+100
+50
5
ppb
ppb
ppb
ppb
ppb
ppb
ppb
ppb
ppb
ppb
minutes
Initial tolerance
vs. supply voltage change
vs. load change
vs. aging/day
vs. aging/1st year
vs. aging/year (following years)
Warm-up time
