FE1A_07 Overview

1 A, 50 V, SILICON, SIGNAL DIODE, DO-204AP

Preview

Download Datasheet

View All

FE1A ... FE1G

Superfast Switching Silicon-Rectifiers

Superschnelle Silizium-Gleichrichter

Version 2005-11-08

Nominal current

Nennstrom

Ø3

±0.05

1A

50...400 V

DO-15

(DO-204AC)

0.4 g

Repetitive peak reverse voltage

Periodische Spitzensperrspannung

Plastic case

Kunststoffgehäuse

Weight approx.

Gewicht ca.

Plastic material has UL classification 94V-0

Gehäusematerial UL94V-0 klassifiziert

Standard packaging taped in ammo pack

Standard Lieferform gegurtet in Ammo-Pack

62.5

±0.5

Type

Ø 0.8

±0.05

Dimensions - Maße [mm]

Maximum ratings

Type

Typ

FE1A

FE1B

FE1D

FE1F

FE1G

Repetitive peak reverse voltage

Periodische Spitzensperrspannung

V

RRM

[V]

50

100

200

300

400

Surge peak reverse voltage

Stoßspitzensperrspannung

V

RSM

[V]

50

100

200

300

400

T

A

= 75°C

f > 15 Hz

T

A

= 25°C

T

A

= 25°C

I

FAV

I

FRM

I

FSM

i

2

t

T

j

T

S

6.3

±0.1

Grenzwerte

Forward voltage

Durchlass-Spannung

V

F

at/bei I

F

= 1 A

< 0.95

< 1.25

1 A

1

)

10 A

1

)

30/33 A

4.5 A

2

s

-50...+175°C

Max. average forward rectified current, R-load

Dauergrenzstrom in Einwegschaltung mit R-Last

Repetitive peak forward current

Periodischer Spitzenstrom

Peak forward surge current, 50/60 Hz half sine-wave

Stoßstrom für eine 50/60 Hz Sinus-Halbwelle

Rating for fusing, t < 10 ms

Grenzlastintegral, t < 10 ms

Junction temperature – Sperrschichttemperatur

Storage temperature – Lagerungstemperatur

1

Valid, if leads are kept at ambient temperature at a distance of 10 mm from case

Gültig, wenn die Anschlussdrähte in 10 mm Abstand vom Gehäuse auf Umgebungstemperatur gehalten werden

http://www.diotec.com/

1

FE1A_07 Related Products

	FE1A_07	FE1A	FE1D	FE1B	FE1G	FE1F
Description	1 A, 50 V, SILICON, SIGNAL DIODE, DO-204AP	1 A, 50 V, SILICON, SIGNAL DIODE, DO-204AP	1 A, SILICON, SIGNAL DIODE, DO-204AP	1 A, 100 V, SILICON, SIGNAL DIODE, DO-204AP	SILICON, SIGNAL DIODE, DO-204AC	SILICON, SIGNAL DIODE, DO-204AC
Is it Rohs certified?	-	conform to	conform to	conform to	conform to	conform to
Parts packaging code	-	DO-204	DO-204	DO-204	DO-204	DO-204
package instruction	-	ROHS COMPLIANT, PLASTIC, DO-204AC, 2 PIN	ROHS COMPLIANT, PLASTIC, DO-204AC, 2 PIN	O-PALF-W2	O-PALF-W2	O-PALF-W2
Contacts	-	2	2	2	2	2
Reach Compliance Code	-	compli	compli	compli	compli	compli
ECCN code	-	EAR99	EAR99	EAR99	EAR99	EAR99
Shell connection	-	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED
Configuration	-	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Diode component materials	-	SILICON	SILICON	SILICON	SILICON	SILICON
Diode type	-	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	-	0.95 V	0.95 V	0.95 V	0.95 V	0.95 V
JEDEC-95 code	-	DO-15	DO-15	DO-15	DO-15	DO-15
JESD-30 code	-	O-PALF-W2	O-PALF-W2	O-PALF-W2	O-PALF-W2	O-PALF-W2
Humidity sensitivity level	-	1	1	1	1	1
Maximum non-repetitive peak forward current	-	30 A	30 A	30 A	30 A	30 A
Number of components	-	1	1	1	1	1
Number of terminals	-	2	2	2	2	2
Maximum operating temperature	-	175 °C	175 °C	175 °C	175 °C	175 °C
Minimum operating temperature	-	-50 °C	-50 °C	-50 °C	-50 °C	-50 °C
Maximum output current	-	1 A	1 A	1 A	1 A	1 A
Package body material	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	-	ROUND	ROUND	ROUND	ROUND	ROUND
Package form	-	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM
Peak Reflow Temperature (Celsius)	-	260	260	260	260	260
Certification status	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	-	50 V	200 V	100 V	400 V	300 V
Maximum reverse recovery time	-	0.05 µs	0.05 µs	0.05 µs	0.05 µs	0.05 µs
surface mount	-	NO	NO	NO	NO	NO
Terminal form	-	WIRE	WIRE	WIRE	WIRE	WIRE
Terminal location	-	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL
Maximum time at peak reflow temperature	-	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
