2N5662
Silicon NPN Transistor
Data Sheet
Description
Semicoa Semiconductors offers:
•
Screening and processing per MIL-PRF-19500
Appendix E
•
JAN level (2N5662J)
•
JANTX level (2N5662JX)
•
JANTXV level (2N5662JV)
•
QCI to the applicable level
•
100% die visual inspection per MIL-STD-750 method
2072 for JANTXV
•
Radiation testing (total dose) upon request
Applications
•
General purpose
•
Power Transistor
•
NPN silicon transistor
Features
•
•
•
•
Please contact Semicoa for special configurations
www.SEMICOA.com or (714) 979-1900
Hermetically sealed TO-5 metal can
Also available in chip configuration
Chip geometry 1031
Reference document:
MIL-PRF-19500/454
Benefits
•
Qualification Levels: JAN, JANTX, and
JANTXV
•
Radiation testing available
T
C
= 25°C unless otherwise specified
Absolute Maximum Ratings
Parameter
Collector-Emitter Voltage
Collector-Base Voltage
Emitter-Base Voltage
Collector Current, Continuous
Power Dissipation, T
A
= 25°C
Derate linearly above 25°C
Power Dissipation, T
C
= 25°C
Derate linearly above 100°C
Operating Junction Temperature
Storage Temperature
Symbol
V
CEO
V
CBO
V
EBO
I
C
P
T
P
T
T
J
T
STG
Rating
200
250
6
2
1
5.7
15
150
-65 to +200
Unit
Volts
Volts
Volts
A
W
mW/°C
W
mW/°C
°C
Copyright 2002
Rev. D
Semicoa Semiconductors, Inc.
333 McCormick Avenue, Costa Mesa, California 92626 714.979.1900, FAX 714.557.4541
Page 1 of 2
www.SEMICOA.com
2N5662
Silicon NPN Transistor
Data Sheet
ELECTRICAL CHARACTERISTICS
characteristics specified at T
A
= 25°C
Off Characteristics
Parameter
Collector-Emitter Breakdown Voltage
Collector-Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector-Base Cutoff Current
Collector-Emitter Cutoff Current
On Characteristics
Parameter
Symbol
h
FE1
h
FE2
h
FE3
h
FE4
h
FE5
V
BEsat1
V
BEsat2
V
CEsat1
V
CEsat2
Test Conditions
I
C
= 50 mA, V
CE
= 2 Volts
I
C
= 500 mA, V
CE
= 5 Volts
I
C
= 1 A, V
CE
= 5 Volts
I
C
= 2 A, V
CE
= 5 Volts
I
C
= 500 mA, V
CE
= 5 Volts
T
A
= -55°C
I
C
= 1 A, I
B
= 100 mA
I
C
= 2 A, I
B
= 400 mA
I
C
= 1 A, I
B
= 100 mA
I
C
= 2 A, I
B
= 400 mA
Symbol
V
(BR)CEO
V
(BR)CER
V
(BR)EBO
I
CBO1
I
CBO2
I
CES1
I
CES2
Test Conditions
I
C
= 10 mA
I
C
= 10 mA, R
BE
= 100
Ω
I
E
= 10
µA
V
CB
= 200 Volts
V
CB
= 250 Volts
V
CE
= 200 Volts
V
CE
= 200 Volts, T
A
= 150°C
Min
200
250
6
0.1
1.0
0.2
100
Typ
Max
Units
Volts
Volts
Volts
µA
mA
µA
Pulse Test: Pulse Width = 300
µs,
Duty Cycle
≤
2.0%
DC Current Gain
Min
40
40
15
5
15
Typ
Max
120
Units
Base-Emitter Saturation Voltage
Collector-Emitter Saturation Voltage
Dynamic Characteristics
Parameter
Magnitude – Common Emitter, Short
Circuit Forward Current Transfer Ratio
Open Circuit Output Capacitance
Switching Characteristics
Parameter
Saturated Turn-On Time
Saturated Turn-Off Time
1.2
1.5
0.4
0.8
Volts
Volts
Symbol
|h
FE
|
C
OBO
Test Conditions
V
CE
= 5 Volts, I
C
= 100 mA,
f = 10 MHz
V
CB
= 10 Volts, I
E
= 0 mA,
100 kHZ < f < 1 MHz
Min
2
Typ
Max
7
45
Units
pF
Symbol
t
ON
t
OFF
Test Conditions
I
C
= 500 mA, V
CC
= 100 Volts
I
C
= 500 mA, V
CC
= 100 Volts
Min
Typ
Max
250
850
Units
ns
ns
Copyright 2002
Rev. D
Semicoa Semiconductors, Inc.
333 McCormick Avenue, Costa Mesa, California 92626 714.979.1900, FAX 714.557.4541
Page 2 of 2
www.SEMICOA.com
