PI49FCT20807SE datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> PI49FCT20807SE

PI49FCT20807SE: Description1-10 Clock Buffer for Networking Applications; Categorylogic logic; File Size160KB，6 Pages; ManufacturerPericom Semiconductor Corporation (Diodes Incorporated); Websitehttps://www.diodes.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

PI49FCT20807SE Overview

1-10 Clock Buffer for Networking Applications

PI49FCT20807SE Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Pericom Semiconductor Corporation (Diodes Incorporated)
Parts packaging code	SOIC
package instruction	SOP, SOP20,.4
Contacts	20
Reach Compliance Code	compli
ECCN code	EAR99
series	FCT
Input adjustment	STANDARD
JESD-30 code	R-PDSO-G20
JESD-609 code	e3
length	12.795 mm
Logic integrated circuit type	LOW SKEW CLOCK DRIVER
MaximumI(ol)	0.008 A
Humidity sensitivity level	1
Number of functions	1
Number of inverted outputs
Number of terminals	20
Actual output times	10
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP20,.4
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
power supply	2.5 V
Prop。Delay @ Nom-Su	3.5 ns
propagation delay (tpd)	3.5 ns
Certification status	Not Qualified
Same Edge Skew-Max（tskwd）	0.15 ns
Maximum seat height	2.65 mm
Maximum supply voltage (Vsup)	2.7 V
Minimum supply voltage (Vsup)	2.3 V
Nominal supply voltage (Vsup)	2.5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	40
width	7.5 mm

Preview

Download Datasheet

View All

PI49FCT20807

21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321

1-10 Clock Buffer for

Networking Applications

Features

• High Frequency >150 MHz

• High-speed, low-noise, non-inverting 1-10 buffer

• Low-skew (<150ps) between any two output clocks

• Low duty cycle distortion <300ps

• Low propagation delay <3.5ns

• Multiple V

, GND pins for noise reduction

• 2.5V supply voltage and 3V tolerant input

• Packaging (Pb-free & Green available):

-20-pin SOIC (S)

-20-pin SSOP (H)

-20-pin QSOP (Q)

Description

The PI49FCT20807, a 2.5V compatible, high-speed, low-noise 1-10

non-inverting clock buffer, is designed to target networking appli-

cations that require low-skew, low-jitter, and high-frequency clock

distribution. Providing output-to-output skew as low as 150ps, the

PI49FCT20807 is an ideal clock distribution device for synchronous

systems. Designing synchronous networking systems requires a

tight level of skew from a large number of outputs.

Pin Description

Pin Name

BUF_IN

CLK [0:9]

GND

Input

Outputs

Ground

Power

De s cription

Block Diagram

CLK0

Pin Configuration

BUF_IN

GND

VDD

CLK9

CLK8

GND

CLK7

VDD

CLK6

GND

CLK5

CLK4

CLK1

BUF_IN

CLK2

CLK0

VDD

CLK1

GND

20-Pin

H, Q, S

CLK3

CLK2

VDD

CLK3

CLK9

GND

PS8558B

09/24/04

PI49FCT20807SE Related Products

	PI49FCT20807SE	PI49FCT20807	PI49FCT20807Q	PI49FCT20807S	PI49FCT20807QE	PI49FCT20807H
Description	1-10 Clock Buffer for Networking Applications	1-10 Clock Buffer for Networking Applications	1-10 Clock Buffer for Networking Applications	1-10 Clock Buffer for Networking Applications	1-10 Clock Buffer for Networking Applications	1-10 Clock Buffer for Networking Applications
Is it lead-free?	Lead free	-	-	Contains lead	Lead free	Contains lead
Is it Rohs certified?	conform to	-	-	incompatible	conform to	incompatible
Maker	Pericom Semiconductor Corporation (Diodes Incorporated)	-	-	Pericom Semiconductor Corporation (Diodes Incorporated)	Pericom Semiconductor Corporation (Diodes Incorporated)	Pericom Semiconductor Corporation (Diodes Incorporated)
Parts packaging code	SOIC	-	-	SOIC	QSOP	SSOP
package instruction	SOP, SOP20,.4	-	-	SOP, SOP20,.4	SSOP, SSOP20,.25	SSOP, SSOP20,.3
Contacts	20	-	-	20	20	20
Reach Compliance Code	compli	-	-	compli	compli	compli
ECCN code	EAR99	-	-	EAR99	EAR99	EAR99
series	FCT	-	-	FCT	FCT	FCT
Input adjustment	STANDARD	-	-	STANDARD	STANDARD	STANDARD
JESD-30 code	R-PDSO-G20	-	-	R-PDSO-G20	R-PDSO-G20	R-PDSO-G20
JESD-609 code	e3	-	-	e0	e3	e0
length	12.795 mm	-	-	12.795 mm	8.65 mm	7.2 mm
Logic integrated circuit type	LOW SKEW CLOCK DRIVER	-	-	LOW SKEW CLOCK DRIVER	LOW SKEW CLOCK DRIVER	LOW SKEW CLOCK DRIVER
MaximumI(ol)	0.008 A	-	-	0.008 A	0.008 A	0.008 A
Number of functions	1	-	-	1	1	1
Number of terminals	20	-	-	20	20	20
Actual output times	10	-	-	10	10	10
Maximum operating temperature	85 °C	-	-	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-	-	-40 °C	-40 °C	-40 °C
Package body material	PLASTIC/EPOXY	-	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SOP	-	-	SOP	SSOP	SSOP
Encapsulate equivalent code	SOP20,.4	-	-	SOP20,.4	SSOP20,.25	SSOP20,.3
Package shape	RECTANGULAR	-	-	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	-	-	SMALL OUTLINE	SMALL OUTLINE, SHRINK PITCH	SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260	-	-	NOT SPECIFIED	260	240
power supply	2.5 V	-	-	2.5 V	2.5 V	2.5 V
Prop。Delay @ Nom-Su	3.5 ns	-	-	3.5 ns	3.5 ns	3.5 ns
propagation delay (tpd)	3.5 ns	-	-	3.5 ns	3.5 ns	3.5 ns
Certification status	Not Qualified	-	-	Not Qualified	Not Qualified	Not Qualified
Same Edge Skew-Max（tskwd）	0.15 ns	-	-	0.15 ns	0.15 ns	0.15 ns
Maximum seat height	2.65 mm	-	-	2.65 mm	1.75 mm	2 mm
Maximum supply voltage (Vsup)	2.7 V	-	-	2.7 V	2.7 V	2.7 V
Minimum supply voltage (Vsup)	2.3 V	-	-	2.3 V	2.3 V	2.3 V
Nominal supply voltage (Vsup)	2.5 V	-	-	2.5 V	2.5 V	2.5 V
surface mount	YES	-	-	YES	YES	YES
technology	CMOS	-	-	CMOS	CMOS	CMOS
Temperature level	INDUSTRIAL	-	-	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal surface	Matte Tin (Sn)	-	-	Tin/Lead (Sn/Pb)	Matte Tin (Sn)	Tin/Lead (Sn/Pb)
Terminal form	GULL WING	-	-	GULL WING	GULL WING	GULL WING
Terminal pitch	1.27 mm	-	-	1.27 mm	0.635 mm	0.65 mm
Terminal location	DUAL	-	-	DUAL	DUAL	DUAL
Maximum time at peak reflow temperature	40	-	-	NOT SPECIFIED	40	30
width	7.5 mm	-	-	7.5 mm	3.9 mm	5.3 mm
