5962D9569402VEX datasheet, PDF

Datasheet> All Categories > The signal circuit> 5962D9569402VEX

5962D9569402VEX: Description4-CHANNEL, DIFFERENTIAL MULTIPLEXER, CDIP16; CategoryThe signal circuit; File Size164KB，6 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric Compare View All

5962D9569402VEX Overview

4-CHANNEL, DIFFERENTIAL MULTIPLEXER, CDIP16

5962D9569402VEX Parametric

Parameter Name	Attribute value
Maker	Renesas Electronics Corporation
Parts packaging code	DIP
package instruction	DIP,
Contacts	16
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	DIFFERENTIAL MULTIPLEXER
JESD-30 code	R-GDIP-T16
length	19.05 mm
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of channels	4
Number of functions	1
Number of terminals	16
Nominal off-state isolation	50 dB
On-state resistance matching specifications	126 Ω
Maximum on-state resistance (Ron)	1800 Ω
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
Filter level	MIL-PRF-38535 Class V
Maximum seat height	5.08 mm
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Maximum disconnect time	1000 ns
Maximum connection time	1000 ns
technology	CMOS
Temperature level	MILITARY
Terminal form	THROUGH-HOLE
Terminal pitch	0.95 mm
Terminal location	DUAL
total dose	10k Rad(Si) V
width	7.62 mm
Base Number Matches	1

Preview

Download Datasheet

View All

HS-0548RH, HS-0549RH

Data Sheet

August 1999

File Number

3543.3

Radiation Hardened Single 8/Differential 4

Channel CMOS Analog Multiplexers with

Active Overvoltage Protection

The HS-0548RH and HS-0549RH are radiation hardened

analog multiplexers with Active Overvoltage Protection and

guaranteed r

matching. Analog input levels may greatly

exceed either power supply without damaging the device or

disturbing the signal path of other channels. Active

protection circuitry assures that signal ﬁdelity is maintained

even under fault conditions that would destroy other

multiplexers. Analog inputs can withstand constant 70V

peak-to-peak levels with

±15V

supplies and digital inputs will

sustain continuous faults up to 4V greater than either supply.

In addition, signal sources are protected from short circuiting

should multiplexer supply loss occur: each input presents

1kΩ of resistance under this condition. These features make

the HS-0548RH and HS-0549RH ideal for use in systems

where the analog inputs originate from external equipment

or separately powered circuitry. Both devices are fabricated

with 44V dielectrically isolated CMOS technology. The

HS-0548 is an 8 channel device and the HS-0549 is a

4 channel differential version. If input overvoltage protection

is not needed, the HS-0508 and HS-509 multiplexers are

recommended.

Speciﬁcations for Rad Hard QML devices are controlled

by the Defense Supply Center in Columbus (DSCC). The

SMD numbers listed here must be used when ordering.

Detailed Electrical Speciﬁcations for these devices are

contained in SMD 5962-95694. A “hot-link” is provided

on our homepage for downloading.

http://www.intersil.com/spacedefense/space.htm

Features

• Electrically Screened to SMD # 5962-95694

• QML Qualiﬁed per MIL-PRF-38535 Requirements

• Gamma Dose . . . . . . . . . . . . . . . . . . . . . . 1 x 10

RAD(Si)

• No Latch-Up

• No Channel Interaction During Overvoltage

• Guaranteed r

Matching

• Maximum Power Supply . . . . . . . . . . . . . . . . . . . . . . . 44V

• Break-Before-Make Switching

• Analog Signal Range . . . . . . . . . . . . . . . . . . . . . . . .

±15V

• Access Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.0µs

Applications

• Data Acquisition Systems

• Control Systems

• Telemetry

Pinouts

HS-0548RH GDIP1-T16 (CERDIP)

OR CDIP2-T16 (SBDIP)

TOP VIEW

16 A1

15 A2

14 GND

13 +V

SUPPLY

12 IN 5

11 IN 6

10 IN 7

9 IN 8

ENABLE 2

-V

SUPPLY

IN 1 4

IN 2 5

IN 3 6

IN 4 7

Ordering Information

ORDERING NUMBER

5962D9569401VEA

5962D9569401VEC

5962D9569402VEA

5962D9569402VEC

INTERNAL

MKT. NUMBER

HS1-0548RH-Q

HS1B-0548RH-Q

HS1-0549RH-Q

HS1B-0549RH-Q

TEMP. RANGE

(

-55 to 125

OUT 8

HS-0549RH GDIP1-T16 (CERDIP)

OR CDIP2-T16 (SBDIP)

TOP VIEW

A0 1

ENABLE 2

-V

SUPPLY

IN 1A 4

IN 2A 5

IN 3A 6

IN 4A 7

OUTA 8

16 A1

15 GND

14 +V

SUPPLY

13 IN 1B

12 IN 2B

11 IN 3B

10 IN 4B

9 OUT B

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

http://www.intersil.com or 407-727-9207

Intersil Corporation 1999

5962D9569402VEX Related Products

	5962D9569402VEX	5962D9569401VEX
Description	4-CHANNEL, DIFFERENTIAL MULTIPLEXER, CDIP16	8-CHANNEL, SGL ENDED MULTIPLEXER, CDIP16, CERDIP-16
Maker	Renesas Electronics Corporation	Renesas Electronics Corporation
Parts packaging code	DIP	DIP
package instruction	DIP,	DIP,
Contacts	16	16
Reach Compliance Code	unknown	compliant
Analog Integrated Circuits - Other Types	DIFFERENTIAL MULTIPLEXER	SINGLE-ENDED MULTIPLEXER
JESD-30 code	R-GDIP-T16	R-GDIP-T16
length	19.05 mm	19.05 mm
Nominal Negative Supply Voltage (Vsup)	-15 V	-15 V
Number of channels	4	8
Number of functions	1	1
Number of terminals	16	16
Nominal off-state isolation	50 dB	50 dB
On-state resistance matching specifications	126 Ω	126 Ω
Maximum on-state resistance (Ron)	1800 Ω	1800 Ω
Maximum operating temperature	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C
Package body material	CERAMIC, GLASS-SEALED	CERAMIC, GLASS-SEALED
encapsulated code	DIP	DIP
Package shape	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE
Certification status	Not Qualified	Not Qualified
Filter level	MIL-PRF-38535 Class V	MIL-PRF-38535 Class V
Maximum seat height	5.08 mm	5.08 mm
Nominal supply voltage (Vsup)	15 V	15 V
surface mount	NO	NO
Maximum disconnect time	1000 ns	1000 ns
Maximum connection time	1000 ns	1000 ns
technology	CMOS	CMOS
Temperature level	MILITARY	MILITARY
Terminal form	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	0.95 mm	0.95 mm
Terminal location	DUAL	DUAL
total dose	10k Rad(Si) V	10k Rad(Si) V
width	7.62 mm	7.62 mm
Base Number Matches	1	1
