50PF(R) Series
STANDARD RECOVERY DIODE
V
RRM
= 400-1200V, I
F(AV)
= 50Amp.
Symbol
A
K
Cathode to Stud Shown
(Anode to Stud add Suffix R)
MAXIMUM RATINGS
Parameter
(Tj = 25 C unless stated otherwise)
50PF(R)
-40
50PF(R)
-80
50PF(R)
-120
Symbol
V
RRM
I
F
(AV)
I
FSM
I
2
T
T
(STG)
Tj
Unit
Volt
Amp
Amp
Repetitive Peak Reverse Voltage
Maximum Average On-State Current
Peak Forward Surge Current 8.3mS
Maximum I
2
T for Fusing 8.3ms
Maximum Storage Temperature Range
Maximum Junction Temperature Range
400
800
1200
50 at T
C
= 140
O
C
700
2050
-55 to +180
-55 to +180
A
2
/S
O
C
C
O
ELECTRICAL CHARACTERISICS at
Parameter
Tj = 25 C Maximum. Unless stated Otherwise
Condition
Symbol
Min
I
FM
=125 Amps T
P
= 400µS rect. wave
V
R
= V
RRM,
tj= 150
O
C
V
FM
I
RRM
R
TH (J-c)
M
T
Wt
Value
Typ
Max
1.40
9.0
0.51
3.4
15.8
Unit
Volt
mA
O
Maximum Forward Voltage
Repetitive Peak Reverse Current
Thermal Resistance (Junction to Case)
Mounting Torque
Weight
C/W
NM
grms
Mechanical Outline
0.90
(0.03)
17.25
(0.68)
0 4.0 (0.16) Min
7.0 (0.27) max
6.1 (0.84) min
10.20 (0.401) min
11.4 (0.45) max
14.86 (0.585) Max
12.80 (0.0.503) Min
C
L
4.0 (0.16) min
25.4 (1.00) max
10.6 (0.42) min
11.4 (0.46) max
1/4" 28 UNF - 2A
Metric M6 x 1
Case: DO-203AB (DO-5)
Case: Metal/ Glass to Metal Seal
All Dimensions in Millimeters (Inches)
