Data Sheet

1.0 Amp FAST SWITCHING

MEGARECTIFIERS

Mechanical Dimensions

RGL41A . . . 41M Series

Description

Dimensions in inches

and (millimeters)

Features

HIGH TEMPERATURE METALLURGI-

CALLY BONDED CONSTRUCTION

SINTERED GLASS CAVITY-FREE

JUNCTION

1.0 AMP OPERATION @ T

= 55°C, WITH

NO THERMAL RUNAWAY

MEETS UL SPECIFICATION 94V-0

Electrical Characteristics @ 25

Maximum Ratings

Peak Repetitive Reverse Voltage...V

RRM

RMS Reverse Voltage...V

R(rms)

DC Blocking Voltage...V

Average Forward Rectified Current...I

F(av)

Current 3/8" Lead Length @ T

= 75°C

Non-Repetitive Peak Forward Surge Current...I

FSM

½ Sine Wave Superimposed on Rated Load

Forward Voltage @ 1.0A...V

Full Load Reverse Current...I

(av)

Full Cycle Average @ T

= 75°C

DC Reverse Current...I

@ Rated DC Blocking Voltage

= 25°C

= 125°C

RGL41A . . . 41M Series

RGL41A RGL41B RGL41D RGL41G RGL41J RGL41K RGL41M

100

200

140

200

400

280

400

600

420

600

800

560

800

1000

700

1000

Units

Volts

Amps

Volts

............................................. 1.0 ...............................................

............................................. 3 0 ...............................................

< ....................... 1.1 ...................... > < ......... 1.2 ......... >

............................................. 3 0 ...............................................

µAmps

............................................. 5.0 ...............................................

............................................. 5 0 ...............................................

............................................. 8.0 ...............................................

............................................. 7 5 ...............................................

< ....................... 1 5 0 ..................... >

250

< ..... 5 0 0 .... >

......................................... -65 to 175 ..........................................

Gray

Red

Orange

Yellow

Green

Blue

Violet

µAmps

°C

/ W

°C

Typical Junction Capacitance...C

(Note 1)

Typical Thermal Resistance...R

θJC

(Note 2)

Typical Reverse Recovery Time...t

(Note 3)

Operating & Storage Temperature Range...T

, T

STRG

Polarity Color Band (2nd Band)

Page 10-14
