342141-1 Product Details
Live Product Chat
Product View
Ring and Spade Tongue Terminals
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
342141-1
T E I nternal N umber: 3 4 2 1 4 1 - 1
Product Highlights:
l
Terminal Shape = Ring Tongue
l
Receptacle Style = Straight
l
Body Style = PLASTI-GRIP
l
Barrel Type = C losed Barrel
l
Wire/C able Type = Regular Wire
View all Features
Superseded
Search for Replacement Parts
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
TERMINAL, RING TONGUE, PLASTI-GRIP,
(PDF, English)
Catalog Pages/Data Sheets:
l
Automachine and General Products
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Terminal Shape
= Ring Tongue
l
Receptacle Style
= Straight
l
Body Style
= PLASTI-GRIP
l
Barrel Type
= C losed Barrel
l
Wire/C able Type
= Regular Wire
l
Insulation
= Yes
l
Insulation Support
= Non-Insulation Support
l
Insulation Diameter (mm [in])
= 4.29 [.169] Max.
l
Stud Size = M2.5
l
Stud Diameter (mm [in])
= 3.00 [0.118]
l
Shape
= RING-043
l
Heavy Duty
= No
l
Material
= C opper
l
Finish
= Tin
l
C olor = Blue
l
Insulation Material = Vinyl
Electrical Characteristics:
l
Voltage (VAC ) = 600
Body Related Features:
l
Wire Range (mm [AWG])
= 1.00-2.50² [17-13.5]
l
Length (mm [in]) = 18.30 [0.720]
l
Insulation Sleeve Material = PVC
Industry Standards:
l
Government/Industry Qualification = No
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Packaging Related Features:
l
Packaging Method
= Loose Piece
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
