533656-5 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 533656-5

533656-5: DescriptionCONNECTOR, 160 CONTACT(S), FEMALE, STRAIGHT BOARD STACKING CONNECTOR, PRESS FIT, RECEPTACLE; CategoryThe connector The connector; File Size113KB，2 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

533656-5 Overview

CONNECTOR, 160 CONTACT(S), FEMALE, STRAIGHT BOARD STACKING CONNECTOR, PRESS FIT, RECEPTACLE

533656-5 Parametric

Parameter Name	Attribute value
Objectid	1518702381
Reach Compliance Code	unknown
YTEOL	0
Other features	ACTION PIN
Body/casing type	RECEPTACLE
Connector type	BOARD STACKING CONNECTOR
Contact point gender	FEMALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	4
Options	GENERAL PURPOSE
Terminal pitch	2.54 mm
Termination type	PRESS FIT
Total number of contacts	160

Preview

Download Datasheet

View All

533656-5 Related Products

	533656-5	1-533656-1	1-533656-3	533656-3	533656-9	533656-6	533656-4	533656-2	533656-8
Description	CONNECTOR, 160 CONTACT(S), FEMALE, STRAIGHT BOARD STACKING CONNECTOR, PRESS FIT, RECEPTACLE	280 CONTACT(S), FEMALE, STRAIGHT BOARD STACKING CONNECTOR, PRESS FIT, RECEPTACLE	CONNECTOR, 168 CONTACT(S), FEMALE, STRAIGHT BOARD STACKING CONNECTOR, PRESS FIT, RECEPTACLE	CONNECTOR, 128 CONTACT(S), FEMALE, STRAIGHT BOARD STACKING CONNECTOR, PRESS FIT, RECEPTACLE	240 CONTACT(S), FEMALE, STRAIGHT BOARD STACKING CONNECTOR, PRESS FIT, RECEPTACLE	HEADER CONNECTOR,PCB MNT,PLUG,180 CONTACTS,SKT,0.1 PITCH,WRAP POST TERMINAL,#2-56,BROWN	CONNECTOR, 140 CONTACT(S), FEMALE, STRAIGHT BOARD STACKING CONNECTOR, PRESS FIT, RECEPTACLE	CONNECTOR, 120 CONTACT(S), FEMALE, STRAIGHT BOARD STACKING CONNECTOR, PRESS FIT, RECEPTACLE	CONNECTOR, 220 CONTACT(S), FEMALE, STRAIGHT BOARD STACKING CONNECTOR, PRESS FIT, RECEPTACLE
Reach Compliance Code	unknown	unknown	unknow	unknown	unknown	compliant	unknown	unknown	unknown
Body/casing type	RECEPTACLE	RECEPTACLE	RECEPTACLE	RECEPTACLE	RECEPTACLE	PLUG	RECEPTACLE	RECEPTACLE	RECEPTACLE
Connector type	BOARD STACKING CONNECTOR	BOARD STACKING CONNECTOR	BOARD STACKING CONNECTOR	BOARD STACKING CONNECTOR	BOARD STACKING CONNECTOR	BOARD CONNECTOR	BOARD STACKING CONNECTOR	BOARD STACKING CONNECTOR	BOARD STACKING CONNECTOR
Contact point gender	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE
Installation method	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT	STRAIGHT
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
Number of rows loaded	4	4	4	4	4	4	4	4	4
Terminal pitch	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Termination type	PRESS FIT	PRESS FIT	PRESS FIT	PRESS FIT	PRESS FIT	WIRE WRAP	PRESS FIT	PRESS FIT	PRESS FIT
Total number of contacts	160	280	168	128	240	180	140	120	220
Objectid	1518702381	1518702376	-	-	1518702384	301475607	1518702380	1518702378	1518702383
Other features	ACTION PIN	ACTION PIN	ACTION PIN	ACTION PIN	ACTION PIN	-	ACTION PIN	ACTION PIN	ACTION PIN
DIN compliance	NO	NO	NO	NO	NO	-	NO	NO	NO
Filter function	NO	NO	NO	NO	NO	-	NO	NO	NO
IEC compliance	NO	NO	NO	NO	NO	-	NO	NO	NO
MIL compliance	NO	NO	NO	NO	NO	-	NO	NO	NO
Mixed contacts	NO	NO	NO	NO	NO	-	NO	NO	NO
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	-	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Manufacturer's serial number	-	533656	533656	533656	-	-	-	533656	533656
