SSM3K02T
TOSHIBA Field Effect Transistor Silicon N Channel MOS Type
SSM3K02T
High Speed Switching Applications
•
•
•
Small package
Low on resistance: R
on
= 200 mΩ (max) (V
GS
= 4 V)
: R
on
= 250 mΩ (max) (V
GS
= 2.5 V)
Low gate threshold voltage: V
th
= 0.6~1.1 V (V
DS
= 3 V, I
D
= 0.1 mA)
Unit: mm
Absolute Maximum Ratings
(Ta
=
25°C)
Characteristics
Drain-source voltage
Gate-source voltage
Drain current
DC
Pulse
Symbol
V
DS
V
GSS
I
D
I
DP
P
D
(Note 1)
T
ch
T
stg
Rating
30
±10
2.5
5.0
1250
150
−55~150
Unit
V
V
A
mW
°C
°C
Drain power dissipation (Ta
=
25°C)
Channel temperature
Storage temperature range
JEDEC
JEITA
―
―
Note:
Using continuously under heavy loads (e.g. the application of
TOSHIBA
2-3S1A
high temperature/current/voltage and the significant change in
Weight: 0.01 g (typ.)
temperature, etc.) may cause this product to decrease in the
reliability significantly even if the operating conditions (i.e.
operating temperature/current/voltage, etc.) are within the absolute maximum ratings.
Please design the appropriate reliability upon reviewing the Toshiba Semiconductor Reliability Handbook
(“Handling Precautions”/“Derating Concept and Methods”) and individual reliability data (i.e. reliability test
report and estimated failure rate, etc).
Note 1: Mounted on FR4 board
2
(25.4 mm
×
25.4 mm
×
1.6 t, Cu pad: 645 mm , t
=
10 s)
Note 2: The pulse width limited by max channel temperature.
Marking
3
Equivalent Circuit
3
KU
1
2
1
2
Handling Precaution
When handling individual devices (which are not yet mounted on a circuit board), be sure that the environment
is protected against electrostatic electricity. Operators should wear anti-static clothing, and containers and other
objects that come into direct contact with devices should be made of anti-static materials.
1
2007-11-01
SSM3K02T
Electrical Characteristics
(Ta
=
25°C)
Characteristics
Gate leakage current
Drain-source breakdown voltage
Drain cut-off current
Gate threshold voltage
Forward transfer admittance
Drain-source ON resistance
Input capacitance
Reverse transfer capacitance
Output capacitance
Switching time
Turn-on time
Turn-off time
Symbol
I
GSS
V
(BR) DSS
I
DSS
V
th
⎪Y
fs
⎪
R
DS (ON)
C
iss
C
rss
C
oss
t
on
t
off
Test Condition
V
GS
= ±10
V, V
DS
=
0
I
D
=
1 mA, V
GS
=
0
V
DS
=
30 V, V
GS
=
0
V
DS
=
3 V, I
D
=
0.1 mA
V
DS
=
3 V, I
D
=
1.25 A
I
D
=
1.25 A, V
GS
=
4 V
I
D
=
1.25 A, V
GS
=
2.5 V
V
DS
=
10 V, V
GS
=
0, f
=
1 MHz
V
DS
=
10 V, V
GS
=
0, f
=
1 MHz
V
DS
=
10 V, V
GS
=
0, f
=
1 MHz
V
DD
=
15 V, I
D
=
0.5 A,
V
GS
=
0~2.5 V, R
G
=
4.7
Ω
(Note)
(Note)
(Note)
Min
⎯
30
⎯
0.6
2.2
⎯
⎯
⎯
⎯
⎯
⎯
⎯
Typ.
⎯
⎯
⎯
⎯
⎯
140
180
115
24
60
52
80
Max
±5
⎯
1
1.1
⎯
200
250
⎯
⎯
⎯
⎯
⎯
Unit
μA
V
μA
V
S
mΩ
pF
pF
pF
ns
Note: Pulse test
Switching Time Test Circuit
Precaution
V
th
can be expressed as voltage between gate and source when low operating current value is I
D
=
100
μA
for this
product. For normal switching operation, V
GS (ON)
requires higher voltage than V
th
and V
GS (off)
requires lower
voltage than V
th
.
(Relationship can be established as follows: V
GS (off)
<
V
th
<
V
GS (ON)
)
Please take this into consideration for using the device.
2
2007-11-01
SSM3K02T
