1812173 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 1812173

1812173: DescriptionPluggable Terminal Blocks MSTBT 2,5/ 4-ST RD BDWH:A1 SO; CategoryThe connector; File Size80KB，3 Pages; ManufacturerPHOENIX CONTACT; Websitehttps://www.phoenixcontact.com

Download Datasheet Parametric View All

1812173 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1812173	-	-	View	Buy Now

1812173 Overview

Pluggable Terminal Blocks MSTBT 2,5/ 4-ST RD BDWH:A1 SO

1812173 Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	PHOENIX CONTACT
Product Category	Pluggable Terminal Blocks
Shipping Restrictions	Mouser does not presently sell this product in your region.
Product	Headers
Number of Positions	4 Position
Pitch	5 mm
Connection Method	Screw
Factory Pack Quantity	50
Unit Weight	0.243073 oz

Preview

Download Datasheet

View All

https://www.phoenixcontact.com/hq/products/1812173

MSTBT 2,5/ 4-ST RD BDWH:A1 SO - 1812173

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

Plug component, Nominal current: 12 A, Number of positions: 4, Pitch: 5 mm, Connection method: Screw

connection with tension sleeve, Color: red, Contact surface: Tin

Key Commercial Data

Packing unit

Minimum order quantity

GTIN

Custom tariff number

Note

4046356724173

85366990

Made to Order (non-returnable)

50 STK

500 STK

Technical data

Dimensions

Pitch

Dimension a

5.00 mm

15 mm

General

Range of articles

Type of contact

Number of positions

Connection method

Rated voltage (III/3)

Connection in acc. with standard

Nominal current I

Nominal cross section

MSTBT 2,5/..-ST

Female connector

Screw connection with tension sleeve

250 V

EN-VDE

12 A

2.5 mm²

Connection data

Conductor cross section solid min.

Conductor cross section solid max.

Conductor cross section flexible min.

Conductor cross section flexible max.

Conductor cross section flexible, with ferrule without plastic sleeve min.

Conductor cross section flexible, with ferrule with plastic sleeve min.

0.2 mm²

2.5 mm²

0.2 mm²

2.5 mm²

0.25 mm²

11/14/2016 Page 1 / 3

Conductor cross section flexible, with ferrule without plastic sleeve max. 2.5 mm²
