15
+
Gbps 0.5mm pitch Stacking Connectors
FX10 Series
Electrical Interface for the OIF 100G Long-Haul DWDM Transmission Module (MSA-100GLH)
■Mechanical
Features
●
0.5mm Pitch
●
Stacking height : 4 to 8mm (2-piece type)
8 to 13mm (3-piece type)
●
Number of Contacts
With ground plate : 80 / 100 / 120 / 140
Without ground plate : 96 / 120 / 144 / 168
3-piece interposer : 120 / 144 /168
Oct.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
●
OIF MSA-100GLH Electrical Interface
■With
GND Plate Type
FX10A-168P/S-SV(83) assembly is specified for the
OIF 100G Long-Haul DWDM Transmission Module
host line card - MSA-100GLH electrical connector.
Ground
plate
Signal contact
Housing
●
Suited to High-Density Applications
The 0.5 mm signal contact pitch provides a smaller
overall connector, using less mounting area on the board.
5
0.7
m
0.5
m
mm
.75
0
mm
●
Optional Ground Plate
An alternate style without the ground plate is available.
The space provided by the ground plate removal has
been filled with additional signal contacts.
<3-piece type>
●
Smooth floating with high speed transmission
capability supported by unique 3-piece floating
system
●
Multiple connectors are allowed on the same PCB
(Allowable Mis-alignment Range : ± 0.3mm in XY
direction)
Metal fitting
Ground plate and metal
fitting make contact
●Floating
Interposer
ing
Float
Flo
ati
n
g
■Signal
Integrity Features
●Insertion-Loss-to-Crosstalk-Ratio(ICR)
The insertion-loss-to-crosstalk-ratio (ICR) with
five-aggressor differential FEXT meets the
extrapolated IEEE 802.3ap specification for
15
+
Gbps.
ICR (dB)
60
50
40
Z (Ohm)
115
110
105
100
95
30
20
10
0
ICR
ICR spec
0
2
4
6
Frequency (GHz)
8
10
●Differential
Impedance
85ø configuration and 100ø configuration are
available.
90
S(3,3)
85
0
200
400
600
Time (ps)
800
1000
■Stack
Height
●2-piece
type
●With
ground plate
Headers
Receptacles
FX10#-*S/*-SV
FX10#-xP/x-SV
4mm
FX10#–xP/x–SV1
5mm
●Without
ground plate
Headers
Receptacles
FX10#-*S-SV
Interposer
FX10-xIP-xD(Q)-8H
FX10#-xP-SV FX10–xP–SV1 FX10#-xP-SV2
4mm
5mm
6mm
FX10#-xP-SV3
7mm
FX10#-xP-SV4
8mm
●3-piece
type
Stacking Height
8mm
9mm
10mm
11mm
12mm
13mm
Header (Mating side)
FX10#-xP-SV
FX10#-xP-SV
FX10#-xP-SV1
FX10#-xP-SV2
FX10#-xP-SV3
FX10#-xP-SV4
Header(Fixed side)
FX10#-xP-SV
FX10#-xP-SV1
FX10#-xP-SV1
FX10#-xP-SV1
FX10#-xP-SV1
FX10#-xP-SV1
( )
FX10-xIP-xD(Q)-8PH
(H) : Reference dimension
In cases where the application will demand a high level of reliability, such as automotive,
please contact a company representative for further information.
2016.12
r
1
FX10 Series●15
+
Gbps 0.5mm pitch Stacking Connectors
■General
Product Specifications (2 piece type)
Rating
Rated
current
Rated
voltage
0.3 A
50 V AC
Operating temperature
range
Operating humidity
range
-55 to 85ç (Note 1)
Relative humidity 95% max
(No condensation)
Storage
temperature range
Storage humidity
range
-10 to +60ç
(Note 2)
40 to 70%
(Note 2)
Item
1. Insulation resistance
2. Voltage resistance
3. Contact resistance
4. Vibration resistance
5. Shock resistance
Requirements
100Mø min
No flashover or breakdown
60mø max
No electrical discontinuity for 1µs or greater
No damage, cracks, or parts looseness
No electrical discontinuity for 1µs or greater
No damage, cracks, or parts looseness
Oct.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
Conditions
Measured at 100 V DC
150 V AC applied for 1 minute
Measured at 100 mA
Frequency : 10 to 55 Hz, amplitude of 0.75 mm
in 3 axis directions, 10 cycles each.
Acceleration of 490 m/s
2
, 11ms duration, sine
half-wave waveform, for 3 cycles in both directions
of each of the 3 axes
Contact resistance of 70mø max, insulation
resistance of
Temperature of 40ç, humidity of 90 to 95%,
duration 96 h
100Mø min, no damage, cracks, or parts
looseness
7. Temperature cycle Contact resistance of 70mø max, insulation
Temperature : -55ç
→
15 to 35ç
→
85ç
→
15 to 35ç
resistance of
Time : 30 min.
→
2 to 3 min.
→
30 min.
→
2 to 3 min.
100Mø min, no damage, cracks, or parts
for 5 cycles
looseness
8. Mating Cycles
Contact resistance of 70mø max
50 times
No damage, cracks, or parts looseness
9. Resistance to
No melting of resin portion which affects
Reflow : At the recommended temperature profile
soldering heat
performance
Soldering iron temperature : 360ç for 5 seconds
Note 1 : Includes temperature rise caused by current flow.
Note 2 : The term storage refers to unused products kept for a long time prior to board mounting. Operating temperature
and humidity range are applicable to the non-conducting state after board assembly.
Note 3 : Information contained in this catalog represents general requirements for this series. Contact us for the drawings and
specifications for a specific part number shown.
6. Damp heat
(Steady state)
■Materials
/ Finish
Part
Insulator
Contacts
Ground plate
Metal fitting
Material
LCP
Phosphor bronze
Phosphor bronze
Phosphor bronze
Finish
Beige
Contact Area: Gold plating
Header
Lead Area: Tin plating
Contact Area: Gold plating
Receptacle
Lead Area: Flash plating
Tin plating
Tin plating
Notes
UL94V-0
- -
-
- -
-
- -
-
■Product
Number Structure
Refer to the chart below when determining the product specifications from the product number.
Please select from the product numbers listed in this catalog when placing orders.
FX10 # -
*
P /
*
- SV 1 (
**
)
q
w
r
t
y
u
e
q
Series name : FX10
w
A : With guide post
r
Connector type
B : Without guide post
e
Number of contacts
With ground plate
Signal/Ground : 80/8, 100/10, 120/12,
140/14
Without ground plate
Signal : 96, 120, 144, 168
P : Header
S : Receptacle
t
Mounting style
SV : Straight SMT
y
Product height
Blank : Standard
1
: Standard + 1mm
u
Packaging options
Blank, (71) : Tray packaging
(21), (91) : Embossed tape packaging
2
FX10 Series●15
+
Gbps 0.5mm pitch Stacking Connectors
■Headers
without ground plate
●4mm
Stacking Height
5.9±0.3
( 5.7)
D±0.3 2.5±0.2
( 0.5 )
A±0.2
0.2 ±0.05
B±0.3
(0.6)
2-(Ø1)
C±0.1
Guidepost
Unit : mm
Part No.
HRS No.
570-0041-0 **
570-0042-2 **
570-0043-5 **
570-0044-8 **
570-0141-4 **
570-0142-7 **
570-0143-0 **
570-0144-2 **
570-0059-5 **
570-0056-7 **
570-0302-1 **
570-0060-4 **
570-0057-0 **
570-0304-7 **
570-0061-7 **
570-0058-2 **
570-0306-2 **
570-0051-3 **
570-0052-6 **
570-0053-9 **
570-0054-1 **
570-0151-8 **
570-0152-0 **
570-0153-3 **
570-0154-6 **
570-0303-4 **
570-0305-0 **
570-0063-0 **
570-0307-5 **
FX10A-96P-SV(**)
FX10A-120P-SV(**)
FX10A-144P-SV(**)
FX10A-168P-SV(**)
FX10A-96P-SV1(**)
FX10A-120P-SV1(**)
FX10A-144P-SV1(**)
FX10A-168P-SV1(**)
FX10A-120P-SV2(**)
FX10A-144P-SV2(**)
FX10A-168P-SV2(**)
FX10A-120P-SV3(**)
FX10A-144P-SV3(**)
FX10A-168P-SV3(**)
FX10A-120P-SV4(**)
FX10A-144P-SV4(**)
FX10A-168P-SV4(**)
FX10B-96P-SV(**)
FX10B-120P-SV(**)
FX10B-144P-SV(**)
FX10B-168P-SV(**)
FX10B-96P-SV1(**)
FX10B-120P-SV1(**)
FX10B-144P-SV1(**)
FX10B-168P-SV1(**)
FX10B-168P-SV2(**)
FX10B-168P-SV3(**)
FX10B-144P-SV4(**)
FX10B-168P-SV4(**)
No. of Contacts
Signal
96
120
144
168
96
120
144
168
120
144
168
120
144
168
120
144
168
96
120
144
168
96
120
144
168
168
168
144
168
A
23.5
29.5
35.5
41.5
23.5
29.5
35.5
41.5
29.5
35.5
41.5
29.5
35.5
41.5
29.5
35.5
41.5
23.5
29.5
35.5
41.5
23.5
29.5
35.5
41.5
41.5
41.5
35.5
41.5
B
31.1
37.1
43.1
49.1
31.1
37.1
43.1
49.1
37.1
43.1
49.1
37.1
43.1
49.1
37.1
43.1
49.1
31.1
37.1
43.1
49.1
31.1
37.1
43.1
49.1
49.1
49.1
43.1
49.1
C
26.4
32.4
38.4
44.4
26.4
32.4
38.4
44.4
32.4
38.4
44.4
32.4
38.4
44.4
32.4
38.4
44.4
—
—
—
—
—
—
—
—
—
—
—
—
D
3.5
E
31.5
37.5
43.5
49.5
31.5
37.5
43.5
49.5
37.5
43.5
49.5
37.5
43.5
49.5
37.5
43.5
49.5
31.5
37.5
43.5
49.5
31.5
37.5
43.5
49.5
49.5
49.5
43.5
49.5
F
28.3
34.3
40.3
46.3
28.3
34.3
40.3
46.3
34.3
40.3
46.3
34.3
40.3
46.3
34.3
40.3
46.3
28.3
34.3
40.3
46.3
28.3
34.3
40.3
46.3
46.3
46.3
40.3
46.3
Remarks
Oct.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
4.5
5.25
6.25
7.25
With
guideposts
3.5
4.5
5.25
6.25
7.25
Without
guideposts
[Specifications number]-**, (**)
(71) : Tray packaging / AuP 0.1µm
(83) : Embossed tape packaging 1RL : 1000pcs / AuP 0.76µm
(85) : Embossed tape packaging 1RL : 250pcs / AuP 0.76µm
(91) : Embossed tape packaging 1RL : 1000pcs / AuP 0.1µm
(93) : Tray packaging / AuP 0.76µm
Note 1: There is no polarity with respect to board mounting for this product.
Note 2: The coplanarity of this product's SMT leads is 0.1mm or less.
Note 3: Please order embossed tape packaged items by the reel.
B
Recommended PCB Layout
Dimensions (Metal mask)
Recommended metal mask thickness : 0.15mm
E
+0.1
0
0
F
-0.1
C ±0.05
A ±0.05
2 Ø1.1 ±0.05
0.5 ±0.03
2 Ø1.2 ±0.05
0
2
-0.1
1
■Board-to-Board
Distance
HEADER CONNECTOR
FX10A(B)-168P-SV*(83)
2 B
1 (A)
(1.1):MATING LENGTH
SOLDER
PCB
3
PCB
3.1
+0.1
0
RECEPTACLE CONNECTOR
FX10A(B)-168S-SV(83)
0
4.1
-0.1
SOLDER
3
6.3
+0.1
0
1.45±0.05
0.3±0.03(Land)
0.25±0.03(Metal mask)
Note 1 The cross-hatched area
inside the SMT land
may come into contact with the connector contacts
and thus care should be taken that the pattern
does not extend beyond the SMT land width.
2 Not required in products without guideposts.
FX10A(B)-168P-SV(83)
FX10A(B)-168P-SV1(83)
FX10A(B)-168P-SV2(83)
FX10A(B)-168P-SV3(83)
FX10A(B)-168P-SV4(83)
FX10A(B)-168S-SV(83)
1 (A)
2 B
4
4.3±0.127
5.3±0.127
5
6.0±0.127
6
7
7.0±0.127
8
8.0±0.127
Note
1
Stacking height from lead to lead (reference dimensions)
2
Board-to-board distance
3
Stencil (metal mask) shall be based on Hirose's
recommended aperture and thickness.
3
FX10 Series●15
+
Gbps 0.5mm pitch Stacking Connectors
■Receptacles
without ground plate
A±0.2
( 0.5 )
0.2 ±0.05
7.3 ±0.3
2.5 ±0.2
( 7.1 )
Oct.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
3.2±0.3
B±0.3
( 0.6 )
2-(Ø1)
C±0.1
Guidepost
Unit : mm
Part No.
FX10A-96S-SV(**)
FX10A-120S-SV(**)
FX10A-144S-SV(**)
FX10A-168S-SV(**)
FX10B-96S-SV(**)
FX10B-120S-SV(**)
FX10B-144S-SV(**)
FX10B-168S-SV(**)
No. of Contacts
Signal
570-0241-9 **
96
HRS No.
570-0242-1 **
570-0243-4 **
570-0244-7 **
570-0251-2 **
570-0252-5 **
570-0253-8 **
570-0254-0 **
120
144
168
96
120
144
168
A
23.5
29.5
35.5
41.5
23.5
29.5
35.5
41.5
B
31.1
37.1
43.1
49.1
31.1
37.1
43.1
49.1
C
26.4
32.4
38.4
44.4
26.4
32.4
38.4
44.4
D
31.5
37.5
43.5
49.5
31.5
37.5
43.5
49.5
E
28.3
34.3
40.3
46.3
28.3
34.3
40.3
46.3
Without
guideposts
With
guideposts
Remarks
[Specifications number] -½
½,
(½
½)
Blank: Tray packaging / AuP 0.1µm
(21) : Embossed tape packaging 1RL : 1000pcs / AuP 0.1µm
(83) : Embossed tape packaging 1RL : 1000pcs / AuP 0.76µm
(84) : Embossed tape packaging 1RL : 500pcs / AuP 0.76µm
(85) : Embossed tape packaging 1RL : 250pcs / AuP 0.76µm
(93) : Tray packaging / AuP 0.76µm
Note 1 : There is no polarity with respect to board mounting for this product.
Note 2 : The coplanarity of this product's SMT leads is 0.1mm or less.
Note 3 : Please order embossed tape packaged items by the reel.
Note 4 : Using multiple connectors between two boards is not recommended.
B
Recommended PCB Layout Dimensions (Metal mask)
Recommended metal mask thickness : 0.15mm
D
+0.1
0
0
E
-0.1
C±0.05
A±0.05
Ø1.2±0.05
1
1
Ø1.1±0.05
3.1
+0.1
0
0.5±0.03
1.45±0.05
0.3±0.03(Land)
0.25±0.03(Metal mask)
Note 1 Not required in products without guideposts.
4
0
4.5
-0.1
7.7
+0.1
0
FX10 Series●15
+
Gbps 0.5mm pitch Stacking Connectors
■Headers
with ground plate
●4mm
Stacking Height
Oct.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
Unit : mm
Part No.
FX10A-80P/8-SV(
**
)
FX10A-100P/10-SV(
**
)
FX10A-120P/12-SV(
**
)
FX10A-140P/14-SV(
**
)
FX10B-80P/8-SV(
**
)
FX10B-100P/10-SV(
**
)
FX10B-120P/12-SV(
**
)
FX10B-140P/14-SV(
**
)
HRS No.
570-0001-5
**
570-0002-8
**
570-0003-0
**
570-0004-3
**
570-0021-2
**
570-0022-5
**
570-0023-8
**
570-0024-0
**
No.of Contacts
A
Signal Ground
80
8
23.5
100
120
140
80
100
120
140
10
12
14
8
10
12
14
29.5
35.5
41.5
23.5
29.5
35.5
41.5
B
18
24
30
36
18
24
30
36
C
D
E
F
Remarks
31.1 26.4 31.5 28.3
37.1 32.4 37.5 34.3
43.1 38.4 43.5 40.3
49.1 44.4 49.5 46.3
31.1
37.1
43.1
49.1
—
—
—
—
31.5 28.3
37.5 34.3
43.5 40.3
49.5 46.3
Without
guideposts
With
guideposts
[Specifications number] -½
½,
(½
½)
(71) : Tray packaging
(91) : Embossed tape packaging
Note 1 : There is no polarity with respect to board mounting for this product.
Note 2 : The coplanarity of this product's SMT leads is 0.1mm or less.
Note 3 : Please order embossed tape packaged items by the reel. (One reel holds 1,000 pieces.)
Note 4 : Using multiple connectors between identical boards is not recommended.
B
Recommended PCB Layout Dimensions (Metal mask)
Recommended metal mask thickness : 0.15mm
Note 1 Cross-hatched portions, totaling n places, indicate the ground circuits.
2 Cross-hatched portions, 2 places on both sides, indicate the metal fittings.
3 The cross-hatched area
inside the SMT land may come into contact with the connector contacts
and thus care should be taken that the pattern does not extend beyond the SMT land width.
4 Not required in products without guideposts.
5
京公网安备 11010802033920号
EEWORLD
