13
12
11
10
9
8
7
6
5
4
3
2
1
PART NUMBER DATA
J
A
B
CIRCUITS
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
I
.27
H
PART
NUMBER
397500002
397500003
397500004
397500005
397500006
397500007
397500008
397500009
397500010
397500011
397500012
G
A
F
.138
3.50
ENGINEERING
NUMBER
M351B-00-02-1
M351B-00-03-1
M351B-00-04-1
M351B-00-05-1
M351B-00-06-1
M351B-00-07-1
M351B-00-08-1
M351B-00-09-1
M351B-00-10-1
M351B-00-11-1
M351B-00-12-1
M351B-00-13-1
M351B-00-14-1
M351B-00-15-1
M351B-00-16-1
M351B-00-17-1
M351B-00-18-1
COLOR
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
BLACK
A IN mm
.28
.41
.55
.69
.83
.96
1.10
1.24
1.38
1.52
1.65
1.79
1.93
2.07
2.20
2.34
2.48
7.0
10.5
14.0
17.5
21.0
24.5
28.0
31.5
35.0
38.5
42.0
45.5
49.0
52.5
56.0
59.5
63.0
B IN mm
.138
.276
.413
.551
.689
.827
.965
1.102
1.240
1.378
1.516
1.654
1.791
1.929
2.067
2.205
2.343
3.50
7.00
10.50
14.00
17.50
21.00
24.50
28.00
31.50
35.00
38.50
42.00
45.50
49.00
52.50
56.00
59.50
J
I
H
G
REF. THE LAST 2 DIGITS OF THE PART NUMBER EQUAL CIRCUIT COUNT
F
C
WIRE ENTRY
M351B
.39
E
E
D
D
B
.37
SPECIFICATIONS
1. MATERIAL:
A. SCREW: M2 STEEL, NI PLATED
B. BODY: PA66, UL94V-0
C. CONTACT: PHOS-BRONZE
D. CAGE: BRASS, NI PLATED
2. WIRE SIZE: 16 TO 28AWG
3.RATING: 125V, 8A
4.MAX TORQUE: 2.5 IN. LBS.
5.WIRE STRIP LENGTH: .16 IN. (4.0mm)
7.DIMS SHOWN ARE FOR REFERENCE ONLY
A1
13
12
11
10
9
8
REV
CONTACT FACTORY FOR OPTIONAL COLORS
D
C
C
B
GENERAL TOLERANCES
(UNLESS SPECIFIED)
DESCRIPTION
DIMENSION STYLE
SCALE
DESIGN UNITS
IN/MM
DRAWN BY
DATE
CHECKED BY
DATE
----
TITLE
METRIC
THIRD ANGLE
PROJECTION
B
=
0
C
mm
4 PLACES
3 PLACES
2 PLACES
1 PLACE
---
---
---
---
---
INCH
---
---
---
---
=
0
APPROVED BY
DATE
molex
TERMINAL BLOCK
PLUGGABLE HORIZ.
3.5MM
MOLEX INCORPORATED
SHEET NO.
A
DRAFT WHERE
APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
7
6
5
MATERIAL NO.
DOCUMENT NO.
SEE CHART
SIZE
A
SD-39750-001
3
2
1
C
THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX
INCORPORATED AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
4
