For mating with wire contacts only. Suitable for vertical applications up to 25A per pole,
tin plating enhances solderability.
Dimensions
Mating
Loose Piece
-A-
Force
---------------- Part Numbers --------------- inches mm
Minimum Quantity .... 1,000
100
.......................
Low
1377G3-BK 1377G3 2.22 56.40
High
1317G3-BK
1317G3
2.22 56.40
Low
1377G4-BK 1377G4 1.76 44.70
High
1317G4-BK
1317G4
1.76 44.70
Low
1377G13-BK 1377G13 1.17 29.70
High
1317G13-BK 1317G13 1.17 29.70
All Data Subject To Change Without Notice
25A Vertical PCB Contacts Tin Plated
[ 3.1 ]
0.12
Housing end
A
www.andersonpower.com
- 21 -
45A Right Angle and Vertical PCB Contacts Tin Plated
Suitable for right angle or vertical applications up to 45A per pole. Tin plating
enhances solderability. Right angle contacts cannot be mixed with 25A PCB
contacts. For mating with wire contacts only.
Description
Minimum Quantity .............
Vertical
Right Angle Bottom Row
Right Angle Top Row
Loose Piece
----------- Part Numbers -----------
1,000
100 ....................
3-5911P1
1335G1
3-5912P1
1336G1
3-5913P1
1337G1
Vertical
[ 29.7 ]
1.17
REF
[ 7.9 ]
0.31
TYP
[ 5.8 ]
0.23
[ 7.9 ]
0.31
TYP
[ 5.1 ]
0.20
[ 36.5 ]
1.44
[ 28.6 ]
1.13
[ 16.3 ]
0.64
PP15/45 Housings
(1327 Series)
Use mounting staples with right angle
contacts (see accessories).
Right Angle Contact
Horizontal (bottom)
Cat.No. 1336G1
Right Angle Contact
Horizontal (top), Cat.No. 1337G1
45A Premate Ground PCB Contacts
Right angle contacts are suitable for power or ground. Use to mate with 45A
ground wire contacts. Tin plated contacts are rated up to 1,500 mating cycles.
Can be used with other 45A PCB connectors in the bottom row.
Mating
Loose Piece
Force
-------
Part Numbers -------
Minimum Quantity ...................
1000
100 ....
PCB, Bottom Row Low
3-5952P1 1836G1
[ 14.7 ]
0.578
[ 3.6 ]
0.14
[ 45.3 ]
1.78 [ 41.2 ]
1.62
[ 5.6 ]
0.22
[ 7.9 ]
0.31 TYP
[ 8.4 ]
0.33 TYP
Powerpole
®
PP15 to 45
[ 28.1 ]
1.11
Pre-mate wire
[ 7.9 ]
connector
0.31
Mated Pair
SECTION 2
| PP15-45 ULTRASONICALLY BONDED ASSEMBLIES |
Assemblies feature housings that are ultrasonically welded to create a one piece connector unit using an APP special process. After welding, retaining pins are
no longer required to secure the stacked housings to each other. This allows Powerpole
®
15-45 connectors to be used as a durable one piece connector header.
Contact customer service for configurations not shown below.
Single Row 1x2 Assemblies
Circuit Description
Minimum Quantity ................................
DC 2 Wire Standard Housings
DC 2 Wire Reverse Standard Housings
DC 2 Wire Finger Proof
DC 2 Wire Finger Proof Reverse
Housings Only
500
ASMPP30-1X2-RK
ASMPP30-1X2-KR
ASMFP30-1X2-RK
ASMFP30-1X2-KR
Housings with
45A Vertical
PCB Contacts
500
ASMPV45-1X2-RK
ASMPV45-1X2-KR
ASMFV45-1X2-RK
ASMFV45-1X2-KR
Housings with
45A Right Angle
PCB Contacts
500
.....
ASMPR45-1X2-RK
ASMPR45-1X2-KR
ASMFR45-1X2-RK
ASMFR45-1X2-KR
Color & Type
Position Matrix
1
2
RED / STD BLK / STD
BLK / STD RED / STD
RED / FP BLK / FP
BLK / FP
RED / FP
Single Row 1x3 Assemblies
Circuit Description
Minimum Quantity ................................
DC 2 Wire Finger Proof with Ground
AC Single Phase Finger Proof
Housings Only
500
ASMFP30-1X3-KER
ASMFP30-1X3-KEW
Housings with
45A Right Angle
PCB Contacts
500
.....
ASMFR45-1X3-KER
ASMFR45-1X3-KEW
Color & Type
Position Matrix
1
2
3
BLK / FP GRN / GND RED / FP
BLK / FP GRN / GND WHT / FP
Two Row 2x1 Assemblies
Circuit Description
Minimum Quantity ................................
DC 2 Wire Finger Proof
DC 2 Wire Finger Proof Mate
Housings Only
500
ASMFP30-2X1-KR
ASMFP30-2X1-RK
Housings with
45A Vertical
PCB Contacts
500
ASMFV45-2X1-KR
ASMFV45-2X1-RK
Housings with
45A Right Angle
PCB Contacts
500
....
ASMFR45-2X1-KR
ASMFR45-2X1-RK
Color & Type
Position Matrix
1
2
BLK / FP
RED / FP
RED / FP BLK / FP
Two Row 2x2 Assemblies
Circuit Description
Minimum Quantity ................................
AC 3 Phase, 3 Wire Finger Proof
AC 3 Phase, 3 Wire Finger Proof Mate
Housings with
45A Vertical
Housings Only
PCB Contacts
500
500
ASMFP30-2X2-KRWE N/A
ASMFP30-2X2-WEKR N/A
Housings with
45A Right Angle
PCB Contacts
500
.....
N/A
ASMFR45-2X2-WEKR
1
BLK / FP
WHT / FP
Color & Type
Position Matrix
2
3
RED / FP
WHT / FP
GRN / GND BLK / FP
4
GRN / GND
RED / FP
1
1
2
1
2
3
2
Two Row 2x1 Assembly
1
3
2
4
Hood Up
Single Row 1x2 Assembly
Single Row 1x3 Assembly
Two Row 2x2 Assembly
Type
STD = Standard Housing
FP = Finger Proof Housing
GND = Ground Housing
- 22 -
www.andersonpower.com
All Data Subject To Change Without Notice
Powerpole
®
Pak Connectors
- PP15 to PP45
Plug shell
with latch
Snap-in
Powerpole
®
Pak connector shells enclose stacked
groupings of PP15-45 sized housings in a durable black
shell for a finished connector appearance and additional
features. Inline, panel mount, and blindmate configurations
are available. Plug shells offer the option of integral latches
and strain relief to help secure your connection.
• Package Groupings of PP15-45 Connectors
Provides a finished appearance while protecting
the individual
connectors with an outer shell
Allows one connection system to meet multiple needs
Secures your connection and wires
Blindmate
• Inline, Panel Mount, “T” or Blindmate Configurations
Powerpole
®
Pak
SECTION 2
T-Pak
Plug shell
without latch
• Optional Latching and Strain Relief
For environmentally sealed connector shells to hold Powerpole
®
15-180 connectors, see SPEC Pak
®
product series on our
website, www.andersonpower.com
| POWERPOLE
®
PAK ORDERING INFORMATION |
Plug Shell without Latch
Can mate inline with other plug shells with or without latches, or mate to a panel
mount receptacle. For use with Powerpole
®
wire connectors only. Cable Clamp
and Hardware Pak or Retaining Pins must be ordered separately.
Dimensions
-A-
Description
-------------- Part Numbers --------------
inches mm
Minimum Quantity ... 1,000
500
25
.............................
Black, 2-4 Poles
1461G1-BK
-
1461G1 1.24
31.50
Black, 5-6 Poles
-
1461G2-BK 1461G2 1.56
39.62
Black, 7-8 Poles
-
1461G3-BK 1461G3 1.87
47.50
Powerpole
®
housings and contacts are sold separately.
See page 20 for ordering information.
[ 21.59 ]
0.85
[ 53.09 ]
2.09
A
[ 49.28 ]
1.94
Retaining Pin
Side View
Top View
NOTE: Retaining pins are used to secure and position
Powerpole
®
housings in one of three positions in plug shells.
Plug Shell with Latch
Max wire O.D. for 2-4 pole plug shells is 0.60 inches [15.2mm²].
For all other plug shells is 0.63 inches [ 16.0 mm²].
Can mate inline with other plug shells without latches, or mate to a panel mount receptacle. For use
with Powerpole
®
wire connectors only. Cable Clamp and Hardware Pak or Retaining Pins must
