DUAL-IN-LINE
HEADERS
SERIES 162, 862 • GULL WING SHRINK DIP HEADERS & STRIPS, SMT SOLDER TAIL
B
.019 DIA.
.335
.142
.110
.110
.335
.104
•
Surface mount Gull Wing DIP headers & strips
for adapters and board stacking applications
with .070” lead spacing
.193
•
Gull wing terminals provide maximum
.018
.136 PAD
.089
.165
.100
strength and permit easy visual inspection of
solder joints
See page 208 for details
.032
862...180
•
Series 162 and Series 862 use MM #6218 pins.
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
Data, see page 264 for details
.031
.020 DIA.
.039
.140
162...180
.200
See page 132 for Insulator Details
•
For Electrical, Mechanical and Environmental
Total number
of pins
A
B
.070
C
Quantity
per tube
ORDERING INFORMATION
A
0.572
0.992
1.062
1.692
0.712
0.992
1.412
1.482
1.692
1.832
1.972
2.252
2.392
2.252
B
0.3
0.4
0.4
0.4
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.75
C
0.39
0.49
0.49
0.49
0.69
0.69
0.69
0.69
0.69
0.69
0.69
0.69
0.69
0.84
16
28
30
48
20
28
40
42
48
52
56
64
68
64
35
20
18
12
28
20
14
13
12
11
10
9
8
8
162-10-316-30-180000
162-10-428-30-180000
162-10-430-30-180000
162-10-448-30-180000
162-10-620-30-180000
162-10-628-30-180000
162-10-640-30-180000
162-10-642-30-180000
162-10-648-30-180000
162-10-652-30-180000
162-10-656-30-180000
162-10-664-30-180000
162-10-668-30-180000
162-10-764-30-180000
RoHS - 2
PAGE 128 | IC SOCKETS / TO SOCKETS
XX=Plating Code
See Below
A = 1.482 FOR 21 POS.
.104
.070
2011/65/EU
If desired, we will supply any length up to 21 pins.
862-10-021-30-180000
SPECIFY PLATING CODE XX =
Pin Plating
10
10
µ”
Au
SINGLE ROW STRIP SOCKET
21
1.482
---
.104
---
See page 264 for coplanarity
information
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
